PREMOS 18"
Models:
Premos 18" Inset
Premos 18" with Thermobox
(LPG models prefixed with the letters LPG)
Fuel Effect Options:
Coal Effect
Pebble Effect
Beachcomber Effect
Shoreline Effect
All available on NG & LPG
Control Options:
Manual BM Control
Upgradeable Manual Control
Remote Control (Response-S)
Optimum Control
Trim Switch Control
Total Control
For use on Natural Gas (G20) at a supply pressure of 20mbar
or Propane (G31) at a supply pressure of 37mbar in GB and IE (Dependent upon model)
Users,
Installation & Servicing
Instructions
MUST BE LEFT WITH THE USER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Premos 18" Inset and is the answer not in the manual?

Questions and answers

Summary of Contents for Magiglo Premos 18" Inset

  • Page 1 PREMOS 18” Models: Premos 18” Inset Premos 18” with Thermobox (LPG models prefixed with the letters LPG) Fuel Effect Options: Coal Effect Pebble Effect Beachcomber Effect Shoreline Effect All available on NG & LPG Control Options: Manual BM Control Upgradeable Manual Control Remote Control (Response-S) Optimum Control Trim Switch Control...
  • Page 2 Any claims under this warranty must be made through the retailer from whom the product was purchased. As the purchaser’s contract of sale is with the retailer, Burley Magiglo are unable to enter into discussions with the purchaser until the retailer has inspected any claim and deemed it to be valid.
  • Page 3: Table Of Contents

    Contents Checklist ....................32     3.9. Installation Procedure (Thermobox Model) .............. 33     3.9.1. Burley Magiglo Thermobox Installation Instructions .......... 33     3.9.2. Preparing for Installation ..................33     3.9.3. Installation of the Thermobox ................34  ...
  • Page 4     3.10.5. Commissioning ....................40     3.10.6. Checking for Spillage ..................41     3.10.7. Instructing the User .................... 41     Servicing Instructions ..................... 42     4.1. General Requirements ..................... 42     4.2. Servicing Instructions ....................42  ...
  • Page 5: General Information

    Only approved imitation fuel, available from Burley Magiglo., should be used with this appliance. 4. It is recommended that a fire guard complying with BS 8423 be fitted for the protection of young children, the elderly or infirm.
  • Page 6: Important Note About Ods Pilot

    Under no circumstances should it be adjusted or put out of action by the installer or the user. In case the pilot needs replacing, only the approved part (available from your supplier or Burley Magiglo.) should be fitted. Note: if any part of the pilot assembly becomes faulty the complete assembly will need replacing.
  • Page 7: Fire Fret Dimensions

    1.2. Fire Fret Dimensions All models can be used with the Burley Magiglo range of frets or any other fire fret that falls within the dimensions shown below The fireplace opening must be suitable in size to accommodate the fire being installed.
  • Page 8 This page is left intentionally blank Page 4...
  • Page 9: User Instructions

    2. U NSTRUCTIONS 2.1. Lighting Procedure Your fire will be fitted with one of the following different types of gas control valves. Identify the control system on your fire as shown and follow the appropriate operating instructions in the appropriate section. Control Valve Operation Control Type...
  • Page 10: Lighting Procedure (Manual Bm Control)

    2.1.1. Lighting Procedure (Manual BM Control) 1. Ensure that the arrow on the control arrow is in the OFF position, then knob is pointing towards the OFF release. position as shown in Figure 2. Press in the knob and slowly turn anti-clockwise until a click is heard.
  • Page 11: Lighting Procedure (Manual Mertik Control)

    2.1.2. Lighting Procedure (Upgradeable Manual Control) 1. Whilst pushing the IGNITION KNOB in (see Figure 6), turn it anticlockwise to Ignition knob the pilot flame position as shown in Figure 7. During this process, the spark ignition will have operated and lit the pilot flame.
  • Page 12: Lighting Procedure (Remote Control)

    2.1.3. Lighting Procedure (Remote Control) 1. Press the bottom button on the remote 9. The fire can safely be left in this position handset until clicking is heard on the times, however prevent valve, and the gas rate adjustment knob unauthorised or accidental use (say by is at the off position.
  • Page 13: Lighting Procedure (Optimum Control And Trim Switch Control)

    2.1.4. Lighting Procedure (Optimum Control and Trim Switch Control) 1. Ensure the main burner is off by pressing IGNITION KNOB to the pilot flame position turning degrees the button on the trim marked clockwise. To turn the pilot off, turn the (‘small flame/dot’) until clicking is heard IGNITION KNOB fully clockwise.
  • Page 14: Lighting Procedure (Total Control)

    2.1.5. Lighting Procedure (Total Control) 1. Ensure that gas is available at the valve and the ON/OFF switch in the ON ON/OFF Switch position (–). 2. Simultaneously press and hold the Manual Knob (red circle) and (large flame) buttons until a short acoustic signal confirms the start sequence has begun, then release the buttons (see Figure Gas Rate...
  • Page 15: Manual Operation (Total Control Model)

    2.1.6. Manual Operation (Total Control Model) In emergency the appliance can be operated manually as follows:- 1. Turn the Gas Rate Adjusting knob fully clockwise to the OFF position. A clicking sound will be audible, but this is perfectly alright. 2.
  • Page 16: Battery Replacement (Remote Control & Total Control)

    2.2. Battery Replacement (Remote Control & Total Control) 2.2.1. Handset 1. On the reverse of the handset remove the battery cover by pressing down at the top of the cover and sliding down. Press here and 2. Remove and unclip the old battery and slide down replace with a new PP3 9V battery.
  • Page 17: Battery Replacement (Optimum Control)

    2.3. Battery Replacement (Optimum Control) 1. The battery pack is mounted inside the wall-mounting box behind the wall switch plate. blue blue 2. To change the batteries remove the two brown small screws securing the wall plate brown HIGH using a small screwdriver. LOW/OFF SWITCH SWITCH...
  • Page 18: Fuel Effect Layout

    2.5. Fuel Effect Layout You fire has been supplied with either Coal, Pebble, Beachcomber or Shoreline effect fuel bed. Please refer to the relevant section for instructions on how to arrange the imitation fuels. It is recommended that the imitation fuel be left alone once the desired flame pattern has been achieved.
  • Page 19: Coal Effect Layout

    2.5.1. Coal Effect Layout This fire is supplied with different sizes of ceramic coal. Small Square Coals Random Coals Small random coals Rear Matrix Matrices LH Middle RH Middle Proceed with the coal layout as follows: - Matrix Matrix Burner Board 1.
  • Page 20 Large Random Small Coals Random Coals Figure 27 Figure 28 Page 16...
  • Page 21: Pebble Effect Layout

    2.5.2. Pebble Effect Layout The fire is supplied with ceramic pebble sets as follows: Rear Matrix Large Pebbles (A, B & K) Medium Pebbles (C, D & F) LH Middle RH Middle Matrix Matrix Small Pebbles (E & J) Burner Board Matrices Spikes Figure 29...
  • Page 22 Some sooting on the pebbles may be observed. This is perfectly normal. Periodically operating the Fire at various rates will burn this soot away. excessive sooting is observed, this is an indication that the pebbles are laid incorrectly – please refer to instructions. Page 18...
  • Page 23: Beachcomber Effect & Shoreline Effect Layout

    2.5.3. Beachcomber Effect & Shoreline Effect layout The Beachcomber effect consists of ceramic pebbles and driftwood as follows:- Pebbles Large Pebbles (A, B & K) Medium Pebbles (C, D & F) 9 Small Pebbles (E/J) Matrices Driftwood 2 X D Figure 34 Note: All pebbles and driftwood are marked with identifying lettering except for driftwood...
  • Page 24 5. Place the E, G and J driftwood pieces as shown in Figure 37 ensuring correct orientation. 6. Continue placing pebbles driftwood as shown in Figure 38 to Figure 40. 7. After the appliance has been allowed to warm up, small adjustments (using a small pair of tongs) may be made to the Figure 37 top layer to achieve the desired flame...
  • Page 25: Fitting The Trim (Thermobox Only)

    2.6. Fitting the Trim (Thermobox Only) 1. Most trims are coated with a protective film. This must be removed by peeling off before fitting the trim. 2. The trim is held on by four magnets. Magnets These will either be attached to the trim or supplied loose in a separate envelope.
  • Page 26: Cleaning And Care Instructions

    2.8. Cleaning and Care Instructions CAUTION: Ensure that the appliance is off (including the pilot light) and has completely cooled (off for at least 2 hours) before carrying out any cleaning or maintenance. RCF Advice: This product may use Components (Coals, Pebbles, Driftwood & Ceramic backs) containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.
  • Page 27: Cleaning The Pilot

    2.8.2. Cleaning the Pilot The oxygen depletion sensing pilot fitted to your Burley Magiglo fire is a highly reliable safety device which causes the fire to shut down in the unlikely event of a reduction of oxygen in the room where the fire is fitted.
  • Page 28: Brass Or Chrome Surfaces

    Minor surface scuffs may be treated using a water based touch up stain available at Burley Magiglo fire retailers. Extreme care should be taken when handling and installing products containing ceramic interiors, so as not to cause damage.
  • Page 29: Installation Instructions

    3. I NSTALLATION NSTRUCTIONS Before installation, ensure that the local distribution conditions (identification of the type of gas and pressure) and the adjustment of the appliance are compatible 3.1. General Safety Requirements Before commencing installation, ensure that the intended installation will comply with details in General Information on Page 1.
  • Page 30: Technical Data

    6. The flue must serve only one appliance. 7. If any terminals, cowls or chimney pots are fitted on the flue, ensure that they are suitable use with a decorative gas fire and do not restrict the cross sectional area of the flue. Please consult the manufacturer of the terminal/cowl/chimney pot for guidance.
  • Page 31: Burner Tray Layouts

    3.5. Burner Tray Layouts Pressure Test Point Valve Figure 44 - Standard Model Pressure Test Point Receiver/ Batteries Valve Figure 45 – Remote, Optimum and Trim Switch Control Models Pressure Test Point Receiver Valve Figure 46 - Total Control Model Page 27...
  • Page 32: Appliance Location

    225mm above the floor; or the manufacturer’s instructions state that a hearth is not required. Burley Magiglo would recommend that a hearth or physical barrier be installed with this appliance. However, should you decide not to follow our recommendation and do not fit a hearth or subsequently decide to remove the hearth / physical barrier, then consideration as to the safety of the occupants of the room should be given.
  • Page 33: Floor Level And Raised Fireplace Openings

    3.6.1. Floor Level and Raised Fireplace Openings Inset Model Thermobox Model 480 – 570mm 555 – 570mm 450mm 460 – 525mm 210 - 230mm A minimum of 265mm A minimum of A minimum of 750mm 750mm Must project a Must project a minimum of minimum of 300mm in front...
  • Page 34: Physical Barrier

    3.6.2. Physical Barrier Any physical barrier should meet All Premos Models following requirements: Must project a minimum of 150mm either side of any naked 1. Provide at least the equivalent level of flame or incandescent material warning to the approach of an open fire, Must project a minimum of to that of a hearth.
  • Page 35 Figure 54, Figure 55, Figure 56 and Figure 57 show examples of how the requirements for the physical barrier may be met. 50mm Figure 56 – Example of physical barrier Figure 54 – Example of physical barrier (dimensions as stated in Table 3 – Protected Area) (dimensions as stated in Table 3 –...
  • Page 36: Ventilation

    3.7. Ventilation For this model a minimum of 100cm of ventilation is required in the room that the fire is fitted. In GB reference should be made to BS 5871:Part 3, and in IE, reference should be made to the current edition of I.S.813 which makes clear the conditions that must be met to demonstrate that sufficient ventilation is available.
  • Page 37: Installation Procedure (Thermobox Model)

    Before commencing installation, ensure that the intended installation will comply with details in General Information on Page 1. The Burley Magiglo Premos 16 is designed to be inset into a 16” fireplace opening. Any surround that is to be installed with this appliance must be rated at Carefully unpack the contents of the carton and check them against the checklist given on the previous page.
  • Page 38: Installation Of The Thermobox

    Apply the sealing strip around the rear edge of the Thermobox flange (see Figure 58). If fitting the Optimum Control model install the cable and Seal wall switch prior fitting Thermobox. Figure 58 3.9.3. Installation of the Thermobox 1. Slide the box centrally into the opening. 2.
  • Page 39 Page 35...
  • Page 40: Installation Procedure (Inset Model)

    3.10. Installation Procedure (Inset Model) If applicable, carefully unpack the contents of the carton and check them against the checklist given in Section 3.8. Make sure that the fireplace opening is suitable for the installation of the fire and prepare the fireplace to suit the dimensional requirements given in sections 3.2, 3.4and 3.6(i.e.
  • Page 41: Continuation Of Installation - Remote Control

    3.10.1. Continuation of Installation - Remote Control 1. Unpack the box containing the Receiver and the Hand Set. 2. Fit four AA (1.5V) batteries into the receiver unit and the PP3 (9V) battery into the transmitter (hand set). 3. Feed the cable from the receiver unit heat shield to the spade terminals on the control valve, keeping the cable clear of the underside of the tray.
  • Page 42: Continuation Of Installation - Optimum Control Model

    3.10.2. Continuation of Installation - Optimum Control Model 1. Find a suitable position for the wall Any plaster/cement used to switch, a maximum of 5 metres of cable secure the wall box must be is supplied. completely cured (dry) before installing the batteries or fixing 2.
  • Page 43: Continuation Of Installation - Trim Switch Control

    3.10.3. Continuation of Installation - Trim Switch Control 1. Unpack the battery pack and connect to 5. Proceed Section 3.10.4 the battery connection on the cable. commission the appliance. 2. Fit the connectors on the cable to the drive motor ensuring correct polarity. The cable connectors must be matched appropriately sized...
  • Page 44: Commissioning

    3.10.5. Commissioning 1. Turn on the gas supply to the fire and purge the gas line. Check all the gas joints for gas soundness. 2. Remove the pressure test point screw located as shown in Figure 44 to Figure 46 and connect a pressure gauge. 3.
  • Page 45: Checking For Spillage

    3.10.6. Checking for Spillage 1. Close all doors and windows. 2. Turn the fire on to its full rate and leave it burning for 5 minutes. 3. Test for spillage using a smoke match (in a ‘Blume tube’) at the top of the appliance, fireplace opening or under the canopy at the centre, with the smoke match being approximately 25mm under...
  • Page 46: Servicing Instructions

    4. S ERVICING NSTRUCTIONS 4.1. General Requirements All repairs and servicing must be carried out by a qualified registered gas installer (e.g. member of Gas Safe in GB) in accordance with the current Gas Safety (Installation and Use) Regulations and these instructions. Before any servicing is carried out ensure that the gas and electrical supply (where applicable) have been isolated.
  • Page 47: Replacing Parts

    4.3. Replacing Parts For any spare parts that are required, please contact either your supplier or the manufacturer directly. You will need the model name i.e. model number, the gas type, the type of control and serial number. Only approved parts should be used. 4.3.1.
  • Page 48: Motor Replacement (Remote Control / Optimum Control Models / Trim Switch Models)

    4. Refit the new valve in reverse order 5. Roll up the excess length of HT lead and ensuring that the valve spacers (on secure it to the rolled up thermocouple Mertik valve) are in place. cable with a new tie wrap. 4.3.4.
  • Page 49: Control Valve Replacement (Total Control Model)

    4.3.5. Control Valve Replacement (Total Control Model) Referring to Figure 71: 1. Remove al the gas connections on the valve including the pilot feed pipe. Valve 2. Remove the thermocouple connection securing from the interrupter block at the rear of Screw the valve.
  • Page 50: Installation And Operational Troubleshooting

    4.4. Installation and Operational Troubleshooting The table below is intended for problems related to the fire and its gas controls. It is a guide only and does not take into account every eventuality. Servicing must be carried out in accordance with the current Gas Safety (Installation and Use) Regulations, by a competent person.
  • Page 51 Remote Control, Trim Switch, Optimum and Total Control Models Symptom Cause Remedy Main burner will not Ignition knob incorrectly set Set the ignition knob at the come on when 9 o’clock position. required even though the drive motor is heard to be operating Motor not functioning Flat hand set battery Replace battery (1 X PP3)
  • Page 52 Burley Magiglo fires are protected by UK patents 2193802, 2240620 and 2256920 Other Patents Pending Magiglo is a registered trademark of Burley Appliances Ltd. Burley Magiglo, Lands End Way Oakham, Rutland, LE15 6RB Tel: 01572 725570 Fax: 01572 724390 www.magiglo.co.uk Email: info@magiglo.co.uk...
