ADC Adtemp ULTRA 417 Use, Care & Maintenance page 5

Display Window
Installing and replacing the Batteries:
The thermometer uses one 2032Li 3V Coin Battery.
To install/replace, first switch OFF the device:
1. Remove the battery cover by sliding it up.
2. Press the latch holding the battery to remove it from the housing.
3. Firmly attach the battery to its place; make sure polarity is correct (positive (+) side up).
4. Slide the battery cover back into place. Make sure the latch is firmly closed.
IMPORTANT: It is recommended you remove the battery from the thermometer when it will not be used for
a long period of time.
WARNING: Do not dispose of batteries in fire, recharge, put in backwards, disassemble, or mix with used
or other battery types – they may explode or leak and cause injury. Waste batteries should be disposed of in
accordance with local or national environmental regulations.
Specifications
Weight: 0.4903 oz. (13.90 gr) including battery
Display: LCD, Liquid Crystal Display - 15.9*18.6mm
Battery: 2032Li 3V Coin Battery
Battery Life: Minimum 1000 full duty cycles over a 24 month period
Measurement Time: Oral 2* Seconds / Rectal 2 Seconds /Axillary 2 Seconds
Measurement Range: 95°F - 107.6°F (35°C - 42°C)
Accuracy: +/- 0.1°C/0.2°F between 37°C - 39°C/98.6°F - 102.2°F
Measurement Mode: Predictive measurement
Audible Alarm: 1 beep at start-up. Continuous beep at measurement completion
Auto Turn Off: 60 seconds
Memory Feature: Stores last temperature taken
Operation Environment: 60.8°F - 104°F (16°C - 40°C)
Storage Environment: -4°F - 122°F (-20°C - 50°C)
Standards:Complies with ASTM E1112-00(2011) standard requirements
Parts and Assembly
Mode Button
Size: 5"L x 3/4"W x 3/8"H (12.7cm L x 1.905cm W x .9525cm H)
Humidity: 15-95% (noncondensing)
Humidity: 15-95% (noncondensing)
*2 second response time achieved in water bath test.
Battery Cover (reverse side)
Flexible
Probe Tip
Multi-Function Button
