SARA
24/24, 24/24 F, 24/24 T
NORA
24/24, 24/24 F, 24/24 T,
24, 24 A, 24 F, 24 AF
ES
Caldera mural de gas
Instrucciones de Funcionamiento
Limpieza y Mantenimiento
para el USUARIO
GB
Wall-mounted gas boiler
Operating, Cleaning and
Maintenance Instructions
for the USER
FR
Chaudière murale à gaz
Instructions de Fonctionnement,
de Nettoyage et Maintenance
pour l'UTILISATEUR
SARA 24/24 F
NORA 24/24 F
NORA 24 AF
NORA 24 F
14. 809. 00
DE
Gasbetriebener Wandheizkessel
Betriebs-, Reinigungs-
und Wartungsanleitung
für den BENUTZER
IT
Caldaie a gas da parete
Istruzioni di Funzionamento,
Pulizia e Manutenzione
per l'UTENTE
PT
Caldeira mural de gás
Instruções de Funcionamento,
Limpeza e Manutenção
para o UTILIZADOR
SARA 24/24
NORA 24/24
NORA 24 A
NORA 24
NORA 24/24 T
SARA 24/24 T
