INSTALLATION DU FILTRE
Installez le filtre suff-
isamment profondément.
Retirez
le filtre
Boîte
à poussière
Filtre
préliminaire
Fixez le godet à pous-
Filtre
sière dans le corps prin-
cipal de l’aspirateur.
ENTRETIEN DU FILTRE
Lavez légèrement àl’eau,
Remarque: Après avoir procédé à l’entretien du fil-
tre, si l’aspirateur ne retrouve pas sa puissance
suspendez et laissez bien
d’aspiratin, procédez comme suit.
sécher.
Retirez le godet à pous-
sière.
Replacez-le dans sa posi-
tion originale.
Retirez le filtre.
ATTENTION
Replacez toujours le filtre; faute de
quoi, le moteur peut être abîmé.

ASSEMBLY INSTRUCTIONS

Before assembling your vacuum cleaner, be
CONNECTING FLOOR
sure you have all parts shown in PARTS
NOZZLE
AND FEATURES.
Insert large end of wand onto floor nozzle.
WANDS
Make sure connection is pressed firmly
Insert small end of lower wand into large end
together.
of upper wand then insert
Hose
hose handle onto upper
Lower
Handle
wand. Make sure connec-
Wand
tions are pressed firmly
together.
Nozzle
Upper
Wand
CONNECTING HOSE
Lower
Wand
To connect the hose, insert it into the hose
inlet and then turn it clockwise until it locks
into place.

HOSE ASSEMBLY

Insert hose handle and hose connector onto
the hose supporter at each end of the hose
until the raised tab clicks into the attachment.
Hose
Hose
Handle
Raised
Hose
Tabs
Connector
Do not bend, pull or step on vacuum hose
assembly.
