Summary of Contents for Solo 113
- Page 1 113/114 Electric trimmer Instruction manual Important! Read this instruction manual carefully before first operation and strictly observe all safety regulations! 9 113 103 english 01/2008...
- Page 2 Introduction Symbols Dear Customer, The following symbols are used in this manual and on the product: Congratulations for choosing this SOLO quality product. Always handle this power tool with SOLO's equipment design incorporates the Iatest particular care technology to provide trouble free, extended service Read these operating instructions life.
-
Page 3: Table Of Contents
Index Page 1. Safety regulations ........................4 Correct use / General safety instructions Working clothes When transporting the equipment Mains supply and extension cable Before connection to the mains supply Working with the machine Maintenance, cleaning and repairs 2. Standard delivery ........................6 3. -
Page 4: Safety Regulations
Safety regulations 1. Safety regulations 1.1 Correct use / General safety instructions The electric trimmer must only be used to cut grass, reeds, weeds and wild growth at ground level. The brushcutter must not be used for any other purposes (see chapter 5.1 "Scope of Application"). Read the operating instructions carefully before taking this equipment into service and keep them in a safe place. -
Page 5: Mains Supply And Extension Cable
Safety regulations 1.4 Mains supply and extension cable • Only extension cables approved for outdoor use with a minimum Cable length up Minimum cable cross- cross-section as shown here are permissible as mains extension section cable. 1,2 mm DIN 57282/H07 RN-F 15 m 1,6 mm The cable connectors must be made from rubber or must... -
Page 6: Standard Delivery
Standard delivery ; Control and function elements 2. Standard delivery • Electric brushcutter partially assembled; the following components are supplied separately and require assembly • Handle and all parts required to complete the assembly • Guard, Guard bar, line trimmer and all parts required to assemble the shield •... -
Page 7: Preparing The Equipment For Use
Preparing the equipment for use 4. Preparing the equipment for use Please note: Never start the brush cutter without fitted line trimming blade. For shipping purposes, the brushcutter is partly To replace the line head, unwind it, with the drive disassembled and has to be reassembled prior to shaft blocked, by rotating it anti-clockwise. -
Page 8: Connection To The Mains Supply
Preparing the equipment for use ; Using your brushcutter Fig. 9 4.4 Connection to the mains supply Fig. 7 Always secure the extension cable on the cable retainer (23) on the motor housing. To isolate the equipment, always pull the mains With your thumb, initially press the locking button plug from its socket, i.e. -
Page 9: Troubleshooting
Using your brushcutter ; Specification Several times, tip down the equipment with lengths will be trimmed to size by the line trimming rotating nylon head onto covered ground. This blade. dispenses nylon line in steps. Per release, approx. 30 mm line length will be dispensed. Excess line 5.4 Troubleshooting Fault Possible cause... -
Page 10: Operating And Maintenance Instructions
Operating and maintenance instructions 7. Operating and maintenance instructions 7.1 General operating and maintenance instructions The maintenance and the repair of modern machines as well as their safety-relevant assemblies require qualified specialised training and a workshop equipped with special tools and test equipment. -
Page 11: Guarantee
Guarantee ; Parts subject to wear and tear 8. Guarantee 9. Parts subject to wear and tear The manufacturer guarantees trouble-free quality Various parts are subject to application-specific or and will cover the cost of replacing parts which are normal wear and must be replaced in good time, found to be faulty in material or workmanship when required. - Page 12 SOLO SOLO Postfach 60 01 52 P.O.Box 60 01 52 D 71050 Sindelfingen D 71050 Sindelfingen Germany Tel. 07031-301-0 Phone+49-7031-301-0 Fax 07031-301-130 +49-7031-301-149 info@solo-germany.com export@solo-germany.com...
