- Page 1 High-Fidelity Ceiling Speakers Models HFCS1 & HFCS1LP Off-white HFCS1B & HFCS1LPB Black Installation and Use Manual © 2006 Bogen Communications, Inc. All rights reserved. Specifications subject to change without notice. 54-2091-01E 1302...
-
Page 2: Product Description
The HFCS1LP uses a smaller, low-profile back can that allows for a greater range of installations. The speakers are available with off-white finish or black finish (B versions). -
Page 3: Product Diagrams
Product Diagrams Front Drawing (grille removed) 1. Coaxial Driver Assembly 2. Bass Tuning Vents (x2, HFCS1; x1, HFCS1LP) 3. Grille Retention Groove 4. Power Tap Selection Switch 5. Mounting Clamp Screws (x4) Front Drawing (grille removed) Rear Drawing 6. Metal Back Can 7. -
Page 4: Installation
The HFCS1(B) requires a minimum of 11" of vertical clearance between the • FRONT of the mounting surface and any other structure for the speaker to fit. The HFCS1LP(B) requires a minimum of 6-¾" of vertical clearance. • Before cutting the full hole, use a smaller exploratory hole to determine if there are any obstructions. -
Page 5: Speaker Wiring
Eyelets are provided on the terminal covers to provide a means of securing the speaker to the structure. It is important that all 4 terminal cover screws be installed in this application. A Bogen Model CK10 cable will accomplish this. - Page 6 Selecting Power Levels The front-mounted selector switch is used to set the appropriate power level or impedance for your system. Using a small, flat-blade screwdriver, turn the knob until the slot points to the power level you require. 70V/100V Systems Both power setting scales for 70V and 100V systems are labeled on the speakers.
-
Page 7: Specifications
Specifications SPECIFICATIONS HFCS1 HFCS1LP Frequency Response (-10 dB) * 65 Hz to 19 kHz 78 Hz to 19 kHz LF Driver 6-1/2" (165mm) Polypropylene Cone HF Driver 3/4" (20mm) Polycarbonate Cone Sensitivity (1W/1m) 89 dBspl (Average 100 Hz - 10 kHz) -
Page 8: Limited Warranty; Exclusion Of Certain Damages
Bogen has been advised of the possibility of such damages or losses. Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
