Johnson & Starley
COMBI
SERIES
High Efficiency
Combination
Boilers
USERS INSTRUCTIONS
Natural Gas G20:
Reno HE30C - GC No: 47-416-01
Reno HE37C - GC No: 47-416-02
Propane G31 Variants:
Reno HE30CP - GC No: 47-416-04
Reno HE37CP - GC No: 47-416-03
R E L I A B I L I T Y Y O U C A N T R U S T
www.johnsonandstarley.co.uk
BS EN ISO 9001 : 2000
www.energysavingtrust.org.uk
Publication No. ZZ 1184-6 October 2008
Product Identification No: 87B 074
The Johnson & Starley Reno range has an
energy rating A on a scale of A to G.
For more information see
www.boilers.org.uk
This is a certification mark.
Advertisement
Table of Contents
Related Manuals for Johnson & Starley Reno HE30C
Summary of Contents for Johnson & Starley Reno HE30C
-
Page 1: Users Instructions
