Johnson & Starley Quantec 24S User Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

sustainable solutions under one roof
H E A T I N G
QUANTEC SYSTEM
High Efficiency Boiler
USER'S INSTRUCTIONS
Quantec 24S
ErP
-
These instructions are to be left with the User
H O T W A T E R
G.C. No. 41-416-16
V E N T I L A T I O N
ErP
www.johnsonandstarley.co.uk
Publication No. ZZ 1435-5
February 2016

Advertisement

Table of Contents
loading

Related Manuals for Johnson & Starley Quantec 24S

Summary of Contents for Johnson & Starley Quantec 24S

  • Page 1 H O T W A T E R V E N T I L A T I O N Publication No. ZZ 1435-5 February 2016 QUANTEC SYSTEM High Efficiency Boiler USER’S INSTRUCTIONS Quantec 24S G.C. No. 41-416-16 These instructions are to be left with the User www.johnsonandstarley.co.uk...

  • Page 2: Table Of Contents

    CONTENTS The Benchmark Scheme General Information User’s Important Information Safety Information Boiler Control Panel To Light The Boiler Setting CH Water Temperature Operating Functions Operating the Domestic Hot Water Operating the Central Heating Display Codes To Shut Down the Boiler Frost Protection Loss of System Water Pressure How to Re-Pressurise...

  • Page 3: General Information

    GENERAL INFORMATION WARNING: THIS APPLIANCE MUST BE EARTHED STATUTE LAW DEFINES THAT ALL GAS APPLIANCES MUST BE INSTALLED BY COMPETENT PERSONS, i.e. GAS SAFE REGISTERED INSTALLERS. GAS SAFE MEMBERSHIP ENQUIRIES TEL: 0800 408 5500 IN ACCORDANCE WITH THE GAS SAFETY (INSTALLATION AND USE) REGULATIONS (CURRENT EDITION). FAILURE TO COMPLY WITH THESE REGULATIONS MAY LEAD TO PROSECUTION.

  • Page 4: Boiler Control Panel

    BOILER CONTROL PANEL ITEM DESCRIPTION Reset CH - Central Heating + Summer/Winter mode CH - Central Heating - Installer function only Installer information Installer function only CENTRAL HEATING TEMPERATURE Showing standby mode DISPLAY TIME CONTROL (Optional) FUNCTION MODES INSTALLER RESET MODE BUTTON FIGURE 1.

  • Page 5: To Light The Boiler

    TO LIGHT THE BOILER Switch the mains power ON and the boiler LED display will show “AP”. This puts the boiler into the Air Purge Mode. See Figure 2. Press the reset button “K4” twice. The boiler will go onto standby. This is the winter mode.

  • Page 6: Loss Of System Water Pressure

    LOSS OF SYSTEM WATER PRESSURE The pressure gauge indicates the central heating system pressure. If the pressure is seen to fall below the original installation pressure of 1-2 bar over a period of time then a water leak may be indicated. In this event conduct the re-pressurising procedure as shown.

  • Page 7: Trouble Shooting

    TROUBLE SHOOTING ERROR CODES Check other gas appliances work Ignition lockout Reset boiler Contact installer False flame lockout Contact installer Fill system to 1.0bar Bleed radiators Overheat lockout Check radiator valves are open Reset boiler Contact installer Fan fault Contact installer Flame circuit failure Contact installer Valve feed back ERROR...

  • Page 8: Fault Codes

    FAULT CODES Fill system to 1.0bar Bleed radiators Exhaust sensor fault Check radiator valves are open Reset boiler Contact installer Turn power on and off Remote reset lockout Press Reset Contact installer Fill system to 1.0bar Bleed radiators Low water pressure Check radiator valves are open Reset boiler Contact installer...

  • Page 9: Energy Rating Erp Fiche Technical Data

    ENERGY RATING ErP TECHNICAL DATA FICHE Ecodesigns energy related products directive requires our appliance to be fully compliant with the ErP regulations. Our unit has a label which shows the level of efficiency for the boiler, CO & NOx emissions and db noise emissions. This will help the householder understand the energy efficiency within the home and help reduce energy consumption.

  • Page 10: Keep Yourself Safe

    KEEP YOURSELF SAFE Throughout the year it’s important to make sure that your gas appliances, such as a warm air heater, gas fire, cooker and boiler are working safely and correctly. Did you know Gas Safe Register is the only official list of engineers who are legally allowed to do work on gas and the gas appliances in your home? By law, all gas engineers must be on the Gas Safe Register.

  • Page 11: Energy Saving Tips

    HOW TO SAVE ENERGY We all wish to make savings on our energy bills and at the same time be warm and cosy in our homes. As fuels costs rise, having an efficient and cost effective heating system is vital. You have made your first step in reducing your carbon dioxide emissions now look at other ways to help you make extra saving on those fuel bills.
  • Page 12 Johnson & Starley Ltd Rhosili Road, Brackmills, Northampton NN4 7LZ sales@johnsonandstarley.co.uk marketing@johnsonandstarley.co.uk Reception/Customer Service 01604 762881 01604 767408 Anniversary 1922 - 2012 In the interest of continuous developement Johnson & Starley reserve the right to change specifications without prior notice.
