Instructions for Using
Johnson & Starley
Publication ZZ1184/1
Product Identification No: 87B 074
Reno
High Efficiency Combination Boiler
Model: HE30C
GC No: 47-416-01
User's Instructions
Tel: 01604 762 881
www.johnsonandstarley.co.uk
Advertisement
Related Manuals for Johnson & Starley Reno HE30C
Summary of Contents for Johnson & Starley Reno HE30C
- Page 1 Johnson & Starley Publication ZZ1184/1 Product Identification No: 87B 074 Reno High Efficiency Combination Boiler Model: HE30C GC No: 47-416-01 User’s Instructions Tel: 01604 762 881 www.johnsonandstarley.co.uk...
- Page 2 Symbols on the user display: Temperature of the central Temperature of the domestic heating flow. hot water Pump is running. Ignitor is sparking PRE- Pre-heat is selected. Summer mode HEAT Anti-cycle feature is in operation Flame modulation Outside temperature, when OTC Opentherm boiler management sensor is connected.
- Page 3 Control P P anel The flip door at the bottom of the boiler is held in the closed posision by a concealed latch that has a push and release mechanism and is located on the upper edge of the door in the centre. To gain access to the control panel, apply light pressure on the upper edge of the flip door at the centre, the latch will then release allowing the door to drop into the open position.
- Page 4 Operation o o f D D omestic Initial L L ighting Hot W W ater If turning on the boiler for the first time carry out the following steps: The domestic hot water temperature • Check that the electrical supply is adjustable between 30°C and 65°C to the boiler is ON at the by the control knob P2.
- Page 5 Flame L L oss Service a a nd M M aintenance Should the flame signal be lost 5 It is recommended that a full mainte- times in any 4 minute period then nance check be carried out annually on the boiler will lockout and an error the appliance.
- Page 6 Analogue t t ime c c ontrol ( ( if f f itted) Digital P P rogrammer ( ( if f f itted) Setting the time Button Description • Rotate the dial clockwise, by hand, until the indicator Time/Automatic Run mode selection arrow is pointing to the current time.
- Page 7 Selecting A A M/PM o o r 2 2 4 h h our c c lock Programming 2 2 4 h h o o r 7 7 d d ay S S chedules After pressing reset the display may show AM, numbered It may be helpful to write out the programme schedules days will be flashing on and off.
-
Page 8: Troubleshooting
Johnson & Starley Continuous o o peration Changing a a n E E vent Select the event to be changed with the Prog key. A new While in the run mode, press the key twice to turn set of days may be selected with Day key just as in initial the output to permanently on.
