Johnson & Starley
SYSTEM
SERIES
High Efficiency
System
Boilers
USERS INSTRUCTIONS
Natural Gas G20:
Reno HE16S - GC No: 41-416-05
Reno HE25S - GC No: 41-416-02
Reno HE31S - GC No. 41-416-04
Propane G31 Variant:
Reno HE16SP - GC No: 41-416-09
Reno HE25SP - GC No: 41-416-12
Reno HE31SP - GC No. 41-416-08
R E L I A B I L I T Y Y O U C A N T R U S T
www.johnsonandstarley.co.uk
BS EN ISO 9001 : 2000
www.energysavingtrust.org.uk
Publication No. ZZ 1187-4 March 2008
Product Identification No: 87B 074
The Johnson & Starley Reno range has an
energy rating A on a scale of A to G.
For more information see
www.boilers.org.uk
This is a certification mark.
Advertisement
Table of Contents
Related Manuals for Johnson & Starley Reno HE16S
Summary of Contents for Johnson & Starley Reno HE16S
- Page 1 High Efficiency System Boilers USERS INSTRUCTIONS Natural Gas G20: Reno HE16S - GC No: 41-416-05 Reno HE25S - GC No: 41-416-02 Reno HE31S - GC No. 41-416-04 Propane G31 Variant: Reno HE16SP - GC No: 41-416-09 Reno HE25SP - GC No: 41-416-12 Reno HE31SP - GC No.
- Page 2 SYSTEM SERIES High Efficiency System Boilers www.johnsonandstarley.co.uk...
- Page 3 1. SYMBOLS ON THE USER PANEL ˚ Temperature of the central heating flow. Fan is running. Pump is running. Ignitor is sparking. Pressure in heating circuit. Central heating off mode. Anti-cycle feature is in operation. Flame modulation. ˚ Outside temperature, when an OTC sensor is connected. Opentherm boiler management system is connected.
- Page 4 CONTROL PANEL The flip door at the bottom of the boiler is held in the closed position by a concealed latch that has a push and release mechanism and is located on the upper edge of the door in the centre. To gain access to the control panel, take hold of the side of the panel at the corners and pull panel towards you, allowing the door to drop into the open position.
- Page 5 INITIAL LIGHTING If turning on the boiler for the first time carry out the following steps: Check that the electrical supply to the boiler is ON at the external isolator. Ensure all hot taps are closed. Set any remote controls as required. Turn the CH to the minimum setting.
- Page 6 WATER SYSTEM PRESSURE The water system pressure is shown in the bottom right hand of the display. If the pressure drops below 1.0 bar it will begin to flash indicating the system needs to be topped up by a competent person. If the pressure continues to drop and reaches 0.6 bar, an ER:37 error code will appear in the centre of the display and all heat demands will be blocked.
- Page 7 14. NOTES Telephone: 01604 762881...
- Page 8 Johnson & Starley Johnson & Starley are the leading UK & European manufacturers of a complete range of Domestic Warm Air Heaters. All the heaters suit both Replacement and Upgrade needs and are compliant with the new (2006) amendments to Part L of the Building Regulations.
