8.9

Converting the connection for the milk hose

The milk hose can be connected on the left or right side of the outlet.
42
Fig. 22: Turning the inlet
Proceed as follows to convert the outlet:
1. Pull the milk hose off the appliance.
2. Push the outlet (6) down as far as it will go.
3. Press the locking mechanism (42) of the milk unit (39) together using
two fingers of one hand and pull the milk unit downwards off the outlet.
4. Pull the milk distributor (40) upwards out of the milk unit.
5. Turn the inlet (41) by 180°.
Installation is carried out as described in reverse order.
Information
To install, push the milk unit (39) onto the outlet (6) with both hands. Make
sure that the locking mechanism (42) audibly engages on both sides.
6
40
39
42
42
Changing basic settings
41
42
39
