Summary of Contents for Maxon PM160
- Page 1 PM160 User Manual...
- Page 3 PM160 This product is marked with: 0168 ! in accordance with the Class II product requirements specified in the R+TTE Directive, 1999/5/EC. "We hereby declare that the above named product is in conformity to all the essential requirements of Directive 1999/5/EC".
-
Page 4: Table Of Contents
AUDIBLE MESSAGES ......7 USING THE PM160 ......7 “RECEIVE ONLY”... -
Page 5: Introduction
INTRODUCTION KEY FEATURES • State of the art microprocessor control • 99 fully synthesised channels • 3 LEDs instantly shows the status of a channel • Full scanning features with priority scan • Front panel speaker • Standard vehicle DIN mounting size •... -
Page 6: Descriptionof Radio
DESCRIPTION OF RADIO 1 On/Off Volume Switch 2 Channel Up/Down 3 TX LED 4 Busy LED 5 Call LED 6 2 Digit LED Channel Display 7 Scan Button 8 Scan Indicator LED 9 Monitor Button 10 Option Button 11 Priority Button 12 Priority Indicator LED 13 Microphone Socket 14 Antenna Socket... -
Page 7: Notes To The User
For service or repair always return your radio to an authorised Maxon dealer. • Maxon Sewon Europe Ltd. draw your attention to the provisions within the UK Highway Code, Section 43: `You MUST exercise proper control of your vehicle at all times. -
Page 8: Controls And Indicators
Releasing the button switches the radio back to normal, clear, mode (see VOICE PRIVACY). (11) Priority button: activates/deactivates priority scanning (12) Priority indicator LED: illuminates when PM160 is in Priority Scan mode (13) Microphone socket: plug the fist microphone in here. -
Page 9: Status Led
Your radio controller will be able to give you details of the alerts used in your system. USING THE PM160 Note: The availability of the functions described in this section is dependent on the set-up of your radio. Please consult your Dealer or Supervisor for further information. -
Page 10: Receiving A Call
RECEIVING A CALL On receipt of a call, the Busy LED (4) will illuminate yellow. Wait until the incoming message has finished before starting your own transmission. Press and hold the fist microphone PTT button (located on the side of the microphone) while making a transmission – speak clearly with the microphone approximately 5 to 8 cms away –... -
Page 11: Transmit Lock-Out
This may assist clarity if the radio is operating at the limit of its range. CHANGE CHANNEL The PM160 can access a maximum of 99 channels. Select the channel using SCANNING & PRIORITY LOOKBACK Note: Your radio may or may not be configured for scanning. -
Page 12: Additional Information
ADDITIONAL INFORMATION ACCESSORIES A full range of Maxon accessories are available to use with this product. Please contact your Maxon Reseller for more information or visit www.maxon.co.uk VOICE PRIVACY Your radio may be upgraded with one of two voice privacy options which provide protection against unauthorised eavesdroppers. - Page 13 SOP55-01 FIXED SELCALL MODULE If your radio has been upgraded with the SOP55-01 Selcall Module, a range of additional signalling options is available. These features can reduce the time spent receiving messages meant for other radios and makes better use of the radio channel.
- Page 15 ©2002 By Maxon Europe Ltd. All Rights Reserved UM-PM160-44...
