60cm Built In Ceramic
Cooktop
Installation and User manual
Content
Safety instructions---------------------------------- 2
Product description--------------------------------- 4
Installation---------------------------------------------5
Start using your appliance--------------------------8
Maintenance and troubleshooting----------------13
Warranty------------------------------------------------ 14
For warranty service call 1300 373 199(Australia)
or 0508 123108(New Zealand) to connect you to
the nearest authorised service centre
20141225 issue 1
BDCM604T
BDCM604T-F
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bellini BDCM604T
Summary of Contents for Bellini BDCM604T
-
Page 1: Table Of Contents
Installation and User manual Content Safety instructions---------------------------------- 2 Product description--------------------------------- 4 Installation---------------------------------------------5 Start using your appliance--------------------------8 Maintenance and troubleshooting----------------13 Warranty------------------------------------------------ 14 For warranty service call 1300 373 199(Australia) or 0508 123108(New Zealand) to connect you to the nearest authorised service centre BDCM604T BDCM604T-F... -
Page 2: Safety Instructions
Safety instructions This manual explains the proper installation and use of your appliance, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. In case of failure, only the Authorized Technical Service may repair this hob. - Page 3 Young children should be supervised to ensure that Safety when cleaning they do not play with the appliance. For cleaning, the appliance must be switched To avoid small children and pets unintentionally off and cooled down. switching the appliance on, we recommend For safety reasons, the cleaning of the activation of the child safety device.
-
Page 4: Product Description
Product description 1. max. 1000/2200 W zone 2. max. 1200 W zone 3. max. 1100/2000 W zone 4. max. 1200 W zone 5. Glass plate 6. Control panel 1. Heating zone selection controls 2. Power slider touch control 3. Dual zone control 4. -
Page 5: Installation
Installation Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. - Page 6 Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. Fix the hob on the work surface by screw four brackets on the bottom of hob (see picture) after installation. screw bracket Screw hole...
- Page 7 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.
-
Page 8: Start Using Your Appliance
Start using your appliance Description Explanation Power setting of the zones, from 0 to 9, for example, this display shows power selected at level 5 Control to Increase/decrease power Touch it to lock keys(display show “Lo”) and press and hold for a Child lock while to unlock. - Page 9 Start cooking Power on the unit After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the ceramic hob has entered the state of standby mode. Place a suitable pan on the cooking zone that you wish to use. Make sure the bottom of the pan and the surface of the cooking zone are clean and dry.
- Page 10 Double Zone Function • The function only work in 1# and 3# cooking zone • The dual cooking zone has two cooking areas that you can use a central section and an outer section. You can use the central section (A) independently or both sections (B) at once. Zone 1# Zone 3# Activate the double zone (e.g.
- Page 11 To unlock 1. Make sure the ceramic hob is turned on. 2. Touch and hold the child lock key for a while. 3. You can now start using your ceramic hob. When the hob is in the lock mode, all the controls are disable except for the ON/OFF, you can always turn the ceramic hob off with the ON/OFF control in an emergency, but you shall unlock the hob first in the next operation Over-Temperature Protection...
- Page 12 Touching the”-“ and “+” together, the timer is cancelled, and the”--“ will show in the minute display. 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will flash for 5 seconds. 6.
- Page 13 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator flash for 5 seconds. NOTE: The red dot next to power level indicator will illuminate indicating that zone is selected. Setting the timer to turn more than one cooking zone off 1.
- Page 14 Cooking tips: Heat setting Suitability • delicate warming for small amounts of food 1 - 2 • melting chocolate, butter, and foods that burn quickly • gentle simmering • slow warming • reheating 3 - 4 • rapid simmering • cooking rice •...
- Page 15 Choosing the right Cookware Do not use cookware with jagged edges or a curved base. Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob –...
-
Page 16: Maintenance And Troubleshooting
Maintenance & Troubleshooting Caution: Before maintenance or cleaning is carried out, the range hood should be disconnected from the main power supply. Ensure that the range hood is switched off at the wall socket and the plug removed. Spills and splashes will not harden and stick to the glass, as it hardly heats up. ... -
Page 17: Warranty
Consumer until the expiry of two (2) year (Warranty Period). If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform to the Company’s specifications as a result of some defect in materials, components or workmanship (Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini product free of charge. - Page 18 1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensure it is safely disconnected by a qualified tradesman and securely packed and insured. The Company does not accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company or its service agent.
