Freestanding Woodstove
Owners &
Installation Manual
www.hampton-fire.com
French Manual: http://bit.ly/1jJpAoo
MODEL:
H300
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
918-214e
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
01/06/15
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY H300
Summary of Contents for HAMPTON BAY H300
- Page 1 Freestanding Woodstove Owners & Installation Manual www.hampton-fire.com French Manual: http://bit.ly/1jJpAoo MODEL: H300 Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 918-214e FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4...
- Page 2 The authority having jurisdiction should be consulted before installation to determine the need to obtain a permit. Hampton H300 Cast Freestanding Woodstove...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY LABEL OPERATING INSTRUCTIONS Copy of Safety Label for H300 ........4 Operating Instructions ..........23 Fan Operation..............23 First Fire ..............23 INSTALLATION Safety Guidelines and Warnings .........24 Draft Control ..............24 Unit Dimensions with Standard Legs......5 Ash Disposal..............25 Unit Dimensions with Optional Short Legs ....6 Creosote ..............26... -
Page 4: Safety Label
À COMBUSTIBLE SOLIDE, CONVENANT AUSSI POUR INSTALLATION DANS UNE MAISON MOBILE MODEL: HAMPTON CAST FREESTANDING WOOD STOVE - H300 MODÈLE : POÊLE À BOIS AUTOPORTANT EN FONTE HAMPTON - H300 TESTED TO: UL-1482, ULC-S627-00 REPORT NO: 219-S-04-2 INSTALL AND USE ONLY IN ACCORDANCE WITH THE MANUFACTURER'S INSTALLATION AND OPERATING INSTRUCTIONS. -
Page 5: Unit Dimensions With Standard Legs
DIMENSIONS UNIT DIMENSIONS WITH STANDARD LEGS Hampton H300 Cast Freestanding Woodstove... -
Page 6: Unit Dimensions With Optional Short Legs
DIMENSIONS UNIT DIMENSIONS WITH OPTIONAL SHORT LEGS Hampton H300 Cast Freestanding Woodstove... -
Page 7: Pre-Installation Assembly
4) Re-assemble side door plug assembly to secure. Latch Side Door Plug Assembly Rear Heat Shield Slide tabs in between washer and bolt. 4) Once rear heat shield is evenly in place, tighten bolts to secure. Hampton H300 Cast Freestanding Woodstove... -
Page 8: Residential Installation
Add to the traditional look of the stove and double as a warming area for your cookstove creations. Side Shelves Short legs Helps in reducing the overall height of the unit to accomodate a variety of installations. Using this option prohibits the use of the ash drawer. Hampton H300 Cast Freestanding Woodstove... -
Page 9: Minimum Clearance To Combustible Materials
"C" Vent single wall pipe is not approved for Mobile Home installations. (Refer to Mobile Home section). Unit (with Heat Shield) From Unit From From Flue Center-Line Corner H300 15" (381 mm) 10" (254 mm) 9" (228 mm) 28" (711 mm) 10" (254 mm) 15" (381 mm) Hampton H300 Cast Freestanding Woodstove... -
Page 10: Minimum Alcove Clearance To Combustible Materials
0" (0 mm) 15" (381mm) to each side of the elbow. max. 9" (228 mm) Note: If side load door is used, floor protection must extend at least 18" (457mm) from the side of the unit. Hampton H300 Cast Freestanding Woodstove... -
Page 11: Floor Protection
8" (203 mm) 46-1/2" 8" (203 mm) (1181 mm) (1181 mm) (1181 mm) (1181 mm) Minimum Overall Width (X) of Floor Protector for all installations: H300 39" (990 mm) - US 43" (1092mm) - Canada Hampton H300 Cast Freestanding Woodstove... -
Page 12: How To Determine If Alternate
Check the Minimum roof or other obstructions for safety and proper to the ceiling level. Recommended Flue Heights (Table draft operation. Hampton H300 Cast Freestanding Woodstove... -
Page 13: Masonry Chimney
There are listed kits available to connect a stove to a masonry fireplace. The kit is an adapter that is installed at the location of the fireplace damper. The existing damper may have to be removed to allow installation. Hampton H300 Cast Freestanding Woodstove... -
Page 14: Combustible Wall Chimney Connector Pass-Throughs
Cover opening with and support chimney section on both sides with 24 gage minimum sheet metal supports. See that the supports are fastened securely to wall surfaces on all sides. Make sure fasteners used to secure chimney flue liner. Hampton H300 Cast Freestanding Woodstove... -
Page 15: Recommended Heights For Woodstove Flue
23.0 20.5 25.5 8000-9000 16.0 17.0 18.5 20.0 24.0 21.0 26.5 9000-10000 16.5 17.5 19.0 20.5 24.5 22.0 27.0 NOTE: No more than two offsets (four elbows) allowed. Two 45 elbows equal one 90 elbow. Hampton H300 Cast Freestanding Woodstove... -
Page 16: Mobile Home Installation
Seal the penetration of the outside of the structure. wall with silicon. Hampton H300 Cast Freestanding Woodstove... -
Page 17: Listed Components For Mobile Home Installation
INSTALLATION LISTED COMPONENTS FOR MOBILE HOME INSTALLATION The Hampton H300 Cast Freestanding unit is approved for installation in a Mobile Home if one of the following pipe systems is used. U.S. Installation* Canadian Installations* AMERI-TECHS Qty.Part # Description 6DCC Connector... -
Page 18: Brick Installation
6) Secure glass retainer using the 12 screws. Do not wrench down on the glass as this may cause the glass to break. 7) Place door back on unit. Remove 12 screws. Bottom part of door fits into slot. Glass Retainer Hampton H300 Cast Freestanding Woodstove... -
Page 19: Optional Short Leg Installation
Ash Drawer. Ash Drawer Cover Plate shown fl ipped and secured in place covering the Ash Plug Hole. 9) Remove the 4 standard legs by undoing the bolt and washer on each leg. Hampton H300 Cast Freestanding Woodstove 01/30/08 918-743... - Page 20 14) Re-install fan, if removed. IMPORTANT Flue center-line dimensions change when using the short leg option. Also note that the Outside Air Kit (Part # 47000) cannot be used with the short leg option. Hampton H300 Cast Freestanding Woodstove 918-743 01/30/08...
-
Page 21: Optional Blower / Fan Installation
An optional blower is available for the Hampton 1) Lift off top. 5) Remove fan cover plate from back shield H300. The blower is factory assembled, wired by undoing 3 screws. and ready for attachment to the stove. 2) Place left and right side air channels on firebox top as shown below. -
Page 22: Side Shelf Installation
2) Remove stove top and place side shelf onto the side of the stove as shown, aligning the bracket with notch at the side of the stove. 5) Use the two screws holding the bracket to the underside of the shelf to make final alignment and adjustments. Hampton H300 Cast Freestanding Woodstove... -
Page 23: Operating Instructions
12) Before opening your door to reload, open open for too long. draft fully for approximately 10 to 15 seconds until fire has been re-established. This will minimize any smoking. How to Light & Maintain a Wood Stove Fire Hampton H300 Cast Freestanding Woodstove... -
Page 24: Safety Guidelines And Warnings
11) Open the draft control fully for 10 to 15 seconds prior to slowly opening the door when refuelling the fire. 12) Do not connect your unit to any air distribu- tion duct. Hampton H300 Cast Freestanding Woodstove... -
Page 25: Ash Disposal
3) To remove the drawer, slide it out. When the drawer is completely out, slide the cover plate over the ash drawer and carry away. Pull out Ash Drawer Hampton H300 Cast Freestanding Woodstove... -
Page 26: Creosote
(3mm/1/8" or more) it should be removed to reduce the risk of a chimney fire. Cleaning & Maintaining Your Wood Stove Hampton H300 Cast Freestanding Woodstove... -
Page 27: Front Door Gasket
2) Fit new door handle (front or side) over latch and screw it in to place. Assembly shown below. Refer to the Side Load Door Handle section for step by step installation. Place beside front Remove washer. end washer. Hampton H300 Cast Freestanding Woodstove... -
Page 28: Top Baffle Replacement
2) Remove the five (7/16) socket 1/4 x 1" hex bolts from the Firebox Top Assembly and lift off. Top Baffle Removed 5) Replace the Top Baffle 6) Reverse steps 4 to 1. Hampton H300 Cast Freestanding Woodstove... -
Page 29: Annual Maintenance
Use only high temperature anti seize lube. (ie. never seize) Check glass for cracks Replace if required. Clean blower motor Disconnect power supply. Remove and clean blower. *DO NOT LUBRICATE* Inspect and clean chimney Annual professional chimney cleaning recommended. Hampton H300 Cast Freestanding Woodstove... -
Page 30: Parts List
44) 220-065 Rear Heat Shield - Top 220-325 Front Vents - Timberline Brown 45) 942-110 Ash Plug 46) 820-249 Ash Plug Tool Handle 47) 220-086 Ash Drawer Holder Cover Plate 48) 948-157 Primary Air Handle Hampton H300 Cast Freestanding Woodstove... - Page 31 PARTS LIST PARTS LIST Hampton H300 Cast Freestanding Woodstove...
-
Page 32: H300 Door Assembly
78) 220-089N Latch Door - Nickel Plated 79) 948-155 Hinge Pin - Bottom 80) 948-156 Hinge Pin - Top 220-546 Front Door Handle/Latch Assembly complete (not shown) 220-532 Side Door Handle/Latch Assembly complete (not shown Hampton H300 Cast Freestanding Woodstove... -
Page 33: H300 Firebrick
Brick Partial - 4.5" x 8.5" 91) 802-148 Brick Partial - 4.5" x 4.5" 92) 802-158 Brick Partial - 2" x 8.5" 93) 802-159 Brick Partial - 4.5" x 8.5" (cut angle) 94) 802-160 Brick Partial - 2.25" x 7" Hampton H300 Cast Freestanding Woodstove... - Page 34 NOTES Hampton H300 Cast Freestanding Woodstove...
-
Page 35: Warranty
The Warranty: Limited Lifetime H200 / H300: Firebox castings on all Hampton Wood burning Appliances are covered against manufacturer defects for a period of three (3) years parts and subsidized labour* and a further two (2) years, parts only. Stainless steel baffl es are covered against manufacturer defects for a period of three (3) years parts and subsidized labour* and parts only thereafter. - Page 36 Register your Regency warranty online ® www.regency-fire.com Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notification of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
