INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Installation Manual
Installation and Appliance Setup
Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ION-V7 and is the answer not in the manual?

Questions and answers

Related Manuals for Heatilator ION-V7

Summary of Contents for Heatilator ION-V7

  • Page 1 See Table of Contents for location of additional Commonwealth gases, unless a certified kit is used. of Massachusetts requirements. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 2: Table Of Contents

    C. Install Appliance Outer Wrap (On-Wall Installation) ..33 D. Install Appliance Into Outer Wrap (On-Wall Installation) . . 35  = Contains updated information. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 3: Installation Standard Work Checklist

    Comments: Further description of the issues, who is responsible (Installer/ Builder/ Other Trades, etc) and corrective action needed _____________________________________________________________________________________ _________________________________________________________________________________________________ Comments Communicated to party responsible ____________________ by ______________________on ___________ (Builder / Gen. Contractor/) (Installer) (Date)  = Contains updated information. 2276-982 8/14 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 4: Product Specific And Important Safety Information

    ION-S7 (0-2000 FT) 18,950 10,800 1.25 mm (LP) ION-H7 (0-2000 FT) 24,000 12,700 (NG) ION-H7 (0-2000 FT) 20,000 10,850 0.053 in. (LP) Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 5: Requirements For The Commonwealth Of Massachusetts

    (1/2) in. in size, “GAS remain with the appliance or equipment at the completion VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 6: Getting Started

    Electric drill: 1/2 in. bit, 1/4 in. masonry bit (masonry wall installation only) Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws Caulking material (300ºF minimum continuous exposure rating) Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 7: Installation Methods:on-Wall Or In-Wall

    SHEETROCK/COMBUSTIBLE IN-WALL TUB FACING MATERIAL FRAMING FRAMING + IN-WALL TUB + APPLIANCE NON-COMBUSTIBLE BOARD APPLIANCE INSTALLED 4 IN. TO FINISHED FLOOR FINISHED INSTALLATION   Figure 2.1 On-Wall Installation Method Figure 2.2 In-Wall Installation Method Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 8: Framing And Clearances

    Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3 and Section 5. ION-V7 Appliance Dimensions Table Location Inches Millimeters 36-1/8 16-5/8 19-1/4 6-1/8 28-1/2 9-5/8 6-5/8 4-1/4 6-3/8 7-7/8 Figure 3.1 Appliance Dimensions - ION-V7 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 9 ION-S7 Appliance Dimensions Table Location Inches Millimeters 33-5/8 21-1/8 21-3/8 25-3/4 28-1/2 6-1/4 14-1/4 6-5/8 4-5/16 6-3/8 7-7/8 Figure 3.2 Appliance Dimensions - ION-S7 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 10 ION-H7 Appliance Dimensions Table Location Inches Millimeters 29-1/8 35-5/8 38-1/4 6-1/8 21-1/2 19-1/8 6-5/8 4-3/16 6-3/8 7-7/8 Figure 3.3 Appliance Dimensions - ION-H7 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 11 See Section 10.A, 10.B, 10.C, and 11.C for facing and finishing detail. FOUR SQUARE DECORATIVE FRONTS (DF-FSV7, DF-FSH7, DF-FSS7) 36-5/8 IN. 27-5/8 IN. 36-29/32 IN. 39-1/2 IN. 32-11/16 IN. 46-15/16 IN. Figure 3.4 Appliance Dimensions - Four Square (DF-FSV7, DF-FSH7, DF-FSS7) Decorative Fronts Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 12: Clearance To Combustibles

    27-1/16 IN. (511 mm) (687 mm) Note: The ION-V7 is the only ION appliance that can be vented with a 45 degree elbow directly off the back positioned horizontally. See Section 4.F. Figure 3.6 Appliance Locations Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 13: Constructing The Appliance Chase

    If the appliance is being installed on a cement surface, a layer of plywood may be placed underneath to prevent conducting cold up into the room. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 14: Clearances (On-Wall And In-Wall)

    E** = The appliance outer wrap can attach directly to combustible material, i.e. sheetrock. F*** = See Section 10.D and 10.E for combustible and non-combustible mantel legs. Figure 3.7 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 15: Clearances - Venting With An Elbow Directly Off The Back Of Appliance

    Note: The firestop shield will need to be trimmed when venting with a 90 degree elbow directly off the back of the appliance. See Figure 3.10. Figure 3.11 Ceiling Penetration Framing Requirements See Section 5 for information regarding ceiling firestop. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 16: Termination Location And Vent Information

    Over 14/12 to 16/12 ..........6.0 Over 16/12 to 18/12 ..........7.0 Over 18/12 to 20/12 ..........7.5 Over 20/12 to 21/12 ..........8.0 * 3 foot minimum in snow regions Figure 4.1 Minimum Height From Roof To Lowest Discharge Opening Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 17: Chimney Diagram

    • Vinyl protection kits are suggested for use with vinyl siding. Figure 4.3 Minimum Clearances for Termination Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 18: Approved Pipe

    4-1/4 SLP12 8-1/2 SLP24 SLP36 25-1/2 SLP48 1219 SLP6A 3 to 6 76 to 152 2-1/8-4-1/4 54-108 SLP12A 3 to 12 76 to 305 2-1/8-8-1/2 54-216 Figure 4.4 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 19: Measuring Standards

    • Horizontal runs of vent do not require vertical rise; horizontal runs may be level. • Horizontal termination cap should have a 1/4 inch downward slant to allow any moisture in cap to be released. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 20 Horizontal Termination H = 12 in. (305 mm) Maximum No Elbow Figure 4.6 One 45º Elbow Note: This vent configuration is not allowed with the ION-S7 or ION-H7 models. H Maximum 12 in. (305 mm) Not allowed Not allowed Figure 4.7 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 21 = 40 ft. (12.2 m) Maximum = 1 ft (305 mm) Minimum * : ION-S7 & ION-H7= 14 ft. (4.3 m) Maximum Total : ION-V7 = 12 ft. (3.7 m) Maximum Figure 4.9 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 22 = 40 ft (12.2 m) Maximum = 2 ft (610 mm) Minimum * : ION-S7 & ION-H7= 14 ft. (4.3 m) Maximum Total : ION-V7 = 12 ft. (3.7 m) Maximum Figure 4.11 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 23 = 2 ft (610 mm) Minimum Total * : ION-S7 & ION-H7= 14 ft. (4.3 m) Maximum Total : ION-V7 = 12 ft. (3.7 m) Maximum Figure 4.12 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 24 2-1/8 in. 2-1/8 in. 1-5/8 in. 30 ft. or more 1 in. 2 in. 2 in. 1-1/2 in. ADJUSTMENT SCREW(S) BAFFLE OPENINGS Note: The ION-H7 will have two adjustment screws and a fixed center baffle opening. Figure 4.14 Baffle Settings Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 25 • One vertical termination cap. CLEARANCE TO COMBUSTIBLES REQUIREMENTS DV-46DVA-GCL 3 IN. Exhaust Vent Pipe 5 IN. CAUTION! DO NOT use any flue restrictor when vent- ing with the DV-46DVA-GCL adapter and LINK-DV30B kit. This may result in poor flame appearance, sooting, pilot malfunction, or overheating. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 26 DIRECT VENT FIREPLACE 4 IN. MIN. HEARTH FLOOR Minimum 10 ft. 3.05 m 0 ft. 0 mm Maximum 40 ft. 12.2 m 2 ft. 610 mm Figure 4.18 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 27: Vent Clearances And Framing

    • The opening must be framed on all four sides using the same size framing materials as those used in the wall construction. Figure 5.2 Wall Penetration Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 28: Ceiling Firestop/Floor Penetration Framing

    Figure 5.3 Installing Ceiling Firestop INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 5.4 Installing the Attic Shield Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 29: Appliance Preparation

    (4 SIDES) leak. The ION may be installed in the wall or hung on the wall. APPLIANCE OUTER WRAP For In-Wall installations, see Section 11. CAULK Figure 6.2. Firestop - Interior View Figure 6.1. Firestop - Exterior View Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 30: Install Appliance Corrugated Template

    = VENT ACCESS = GLASS VIEWING AREA GLASS VIEWING AREA = GAS & ELECTRICAL ACCESS 4 IN. MINUMUM TO FINISHED FLOOR GAS ACCESS ELECTRICAL LOCATION ACCESS LOCATION Figure 6.4 Corrugated Template Layout Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 31 2-1/4 IN. 1-5/16 IN. 3 IN. 6-3/16 IN. 3 IN. 3-3/16 IN. 7/16 IN. 2-3/16 IN. 5-9/16 IN. 3-1/2 IN. GAS ACCESS ELECTRICAL ACCESS LOCATION LOCATION Figure 6.6 Corrugated Template Dimensions - ION-S7 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 32 29-3/16 IN. 10-3/16 IN. 17 IN. 2-1/4 IN. 6-1/16 IN. 3 IN. 3 IN. 2-3/16 IN. 7/16 IN. 3-3/16 IN. 1-3/16 IN. 3-1/2 IN. 10-7/16 IN. Figure 6.7 Corrugated Template Dimensions - ION-H7 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 33: Install Appliance Outer Wrap (On-Wall Installation)

    + APPLIANCE OUTER WRAP + APPLIANCE OUTER WRAP + HOLE CUT REMOVE CORRUGATED TEMPLATE PRIOR TO INSTALLING SHEET ROCK OR PRIOR TO INSTALLING APPLIANCE OUTER WRAP Figure 6.9 Install Appliance Outer Wrap Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 34 SEE FIGURE 6.11(B) 4 = VERTICAL STUD ATTACHMENT HOLES NOTICE: A minimum of two screws must be attached to the vertical wall studs 5 = OPTIONAL ATTACHMENT HOLES Figure 6.12 Outer Wrap Mounting Feature Identification Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 35: Install Appliance Into Outer Wrap (On-Wall Installation)

    6.13. Reinstall screws using Figure 6.8 as a reference. DO NOT GRAB, LIFT, OR CARRY THE APPLIANCE BY THE TOP HEAT SHIELD OR COMPONENT TRAY. LOCATION NOTCH TAB AND TAB BENT NOTCH ENGAGED OUTWARD Figure 6.13 Install Firebox On Appliance Outer Wrap Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 36: Venting And Chimneys

    Use care when remov- ing termination cap from slip pipe. If slip section seals are broken during removal of the termination cap, vent could leak. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 37: Installing Slip Sections

    • Only outer pipes are sealed, sealing the inner flue is not required. • All unit collar, pipe, slip section, elbow and cap outer flues shall be sealed. Figure 7.6 Securing Horizontal Pipe Sections Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 38: Disassemble Vent Sections

    • Rotate either section (see Figure 7.7) so the seams on both pipe sections are aligned as shown in Figure 7.8. • Pull carefully to separate the pieces of pipe. Figure 7.7 Rotate Seams for Disassembly Figure 7.8 Align and Disassemble Vent Sections Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 39: Vertical Termination Requirements

    • Caulk the perimeter of the flashing where it contacts the roof surface. See Figure 7.10. • Caulk the overlap seam of any exposed pipe sections that are located above the roof line. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 40 (supplied) through the pilot holes in the outer collar of the cap into the outer flue of the pipe (see Figure 7.12). Termination Cap (1 of 3) Screws Storm Collar Caulk Figure 7.12 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 41: Horizontal Termination Requirements

    Termination Cap Specification Chart (Depth without using additional pipe sections) SLP-TRAP1 can adjust 2-3/8 in. (4-1/8 in. to 6-1/2 in.) SLP-TRAP2 can adjust 4-1/2 in. (6-1/2 in. to 11 in) Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 42: Electrical Information

    Wiring for optional Hearth & Home Technologies approved accessories should be done now to avoid reconstruction. Follow instructions that come with those accessories. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 43: Wiring Requirements

    6 volt transformer connected control valve which operates on a 6 volt/1.5 AMP system. to permanent electrical service. FLAME IGNITER SENSE TO JUNCTION BOX (110V) MODULE FLAME MODULATION RC200 Figure 8.2 Intellifire™ Plus Ignition (IPI) Wiring Diagram Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 44: Gas Information

    4500 feet (1370 m). • If substituting for these components, please consult local codes for compliance. Check with your local gas utility to determine proper orifice size. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 45: Air Shutter Setting

    Note: The air shutter is shipped set between 3/8 in. and full open. Adjust shutter to maximize flame appearance. NOTICE: If sooting occurs, provide more air by opening the air shutter. SHUTTER SLEEVE SHUTTER SCREW Figure 9.1 Air Shutter Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 46: Finishing (On-Wall Installation)

    Overlapping materials could ignite and will interfere with proper operation of doors. DO NOT BLOCK CONVECTION VENTS REMOVE CLIPS WITH FINISHING MATERIAL Figure 10.2 Remove Finishing Strip After Installation of Finishing  Material Figure 10.1 Convection Vent Location Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 47 MATERIAL (TOP ONLY) APPLIANCE APPLIANCE 0 IN. CLEARANCE (BOTTOM AND SIDES) 4 IN. MAX THICKNESS (ALL 4 SIDES) NOTE: MEASURE CLEARANCES FROM APPLIANCE OUTER WRAP  Figure 10.3 Non-Combustible Facing Diagram Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 48: Mantel Projections (All Fronts)

    OF APPLIANCE OUTER WRAP APPLIANCE OUTER WRAP SHEETROCK APPLIANCE OUTER WRAP SHEET ROCK *1/2 IN. GAP IS NEEDED FOR DECORATIVE FRONT INSTALLATION AND REMOVAL. Figure 10.4 Minimum Vertical and Maximum Horizontal Dimensions of Non-Combustibles Figure 10.3 Minimum Vertical and Maximum Horizontal Dimensions of Combustibles Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 49: Mantel Leg And Wall Projections

    Figure 10.5 Combustible Mantel Leg or Wall Projections (Acceptable on both sides of outer wrap) Non-Combustible Mantel Legs or Wall Projections MOUNTED FLUSH WITH WALL DRYWALL 4 IN. TOP OF APPLIANCE OUTER WRAP UNLIMITED 6 IN. MIN. MANTEL LEG OR PERPENDICULAR WALL Figure 10.6 Non-Combustible Mantel Leg or Wall Projections (Acceptable on both sides of outer wrap) Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 50: In-Wall Installation

    FOR CLEARANCE WALL - FRAMED (TOP) ZERO CLEARANCE (BACK) FINISHED FLOOR OPTIONAL SEE DIMENSION A C=4 IN. MIN. FINISHING FOR CLEARANCE STRIPS ZERO (SIDE) CLEARANCE (BOTTOM) Figure 11.1 Framing Dimensions and In-Wall Tub - Clearances Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 51 TERMINATION VERTICAL STUDS BOTTOM STUD ACCESS ELECTRICAL ACCESS GAS ACCESS ELECTRICAL ACCESS CORRUGATED TEMPLATE FLUSH WITH BOTTOM STUD AND CENTERED LEFT TO RIGHT BETWEEN VERTICAL STUDS Figure 11.2 In-Wall with Corrugated Template Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 52 REMOVE TOP FINISHING STRIP FROM APPLIANCE BEFORE INSTALLING IN TUB.  SEE FIGURE 11.9. NON-COMBUSTIBLE NON-COMBUSTIBLE NON-COMBUSTIBLE BOARD BOARD BOARD APPLIANCE FIRESTOP/ OUTER WRAP INSTALLED OUTER WRAP INSTALLED 4 IN. TO INSTALLED FINISHED FLOOR Figure 11.3. In-Wall Tub Installation Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 53 Additional screws may be installed to ensure the tub CAP EXTENSION CAULK PERIMETER SLP-TRAP1 CAP (EDGE) EXTENSION CAULK EXTENSION PERIMETER INSTALLED TO ELIMINATE 2 X 6 WALL CAP EXTENSION INSTALLED Figure 11.4 Cap Extension Installation Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 54: In-Wall - Minimum Combustible Facing Clearances

    2 X 6 HEADER TUB ASSEMBLY BEFORE AFTER TOP VIEW WITH TUB INSTALLED INSULATION ZONE 3-1/2 IN. 1/2 IN. MAX. 2 IN. TUB ASSEMBLY THICKNESS Figure 11.6. In-Wall Tub Installation - Top View Figure 11.8. In-Wall Tub Installation - Sheet Rock Thickness Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 55: In-Wall - Minimum Non-Combustible Facing Clearances

    THICK MAX. DO NOT BLOCK CONVECTION VENTS SHEET ROCK DECORATIVE FRONT NOTE: FINISHING STRIPS CAN BE USED TO MAINTAIN PROPER CLEARANCE. SEE FIGURE 11.5 FOR INSTALLATION. Figure 11.10 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 56: In-Wall Mantel And Wall Projections

    BEHIND SHEETROCK/ MEASUREMENTS FROM TOP COMBUSTIBLE OF APPLIANCE OUTER WRAP FACING MATERIAL APPLIANCE OUTER WRAP SHEETROCK 1/2 IN. MAX. THICKNESS 1/2 IN. MAX.  Figure 11.14 Minimum Vertical and Maximum Horizontal Dimensions of Non-Combustibles Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 57: In Wall - Finishing

    Bend the tabs and insert them into the slots on the splatter guard. See Figures 11.16 and 11.17. COMPONENT TRAY ACCESS PANEL Figure 11.17 Component Tray Access Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 58: Appliance Setup

    WARNING! Risk of Fire! Close the ball valve before in- stalling the splatter guard to prevent accidental lighting. Remove the splatter guard before lighting the appliance. Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 59: Reference Materials

    220 mm 305 mm 8-11/16 in. 1-1/2 in. 5-1/2 in. 12 in. 220 mm 38 mm 305 mm 146 mm SLP-WS SLP-FS Wall Shield Firestop Ceiling Firestop Figure 13.1 SLP Vent Components Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 60 8 in. (128 mm) (203 mm) DVP-HSM-B SL-2DVP Extended Heat Shield Adapter 14-7/16 in. 367 mm 2-5/16 in. 14-7/16 in. 59 mm 367 mm SLP-WT-BK Wall Thimble-Black Figure 13.2 SLP vent components Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 61 3/8 in. (10 mm) 1 in. (25 mm) 13-1/2 in. 343 mm 7-3/4 to 10-3/8 in. (197 to 264 mm) DVP-FBHT SLK-SNKD Horizontal Snorkel Termination Cap Termination Cap Figure 13.3 SLP vent components Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 62 (229 mm) 2-3/4 in. (318 mm) (70 mm) 11-1/2 in. (292 mm) 12-1/4 in. (311 mm) 16 in. (406 mm) PVK-80 (Not approved for use with ION-V7.) Figure 13.4 SLP vent components Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 63 6 inch minimum vertical vent section is required before installing first elbow. DVP-HRC-SS DVP-HRC-ZC-SS HORIZONTAL TERMINATION CAP COAXIAL to COLINEAR VENTING LINK-DV30B 768-380A DV-46DVA-GCL Flex Liner Kit Stainless Steel Flex Pipe Coaxial/Colinear Appliance Connector DVP-2SL Adapter Figure 13.5 DVP vent components Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
  • Page 64 Note: A PVLP-HS heat shield is available and sold separately. 100 FT PV Wire Harness PVI-WH100 Use if the PVLP-SLP is installed in a high traffic area. PVLP-HS PVLP-BEK Heat Shield Brick Kit Figure 13.6 PVLP-SLP Vent Components Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...

  • Page 65: Accessories

    Please contact your Heatilator dealer with any questions or concerns. For the location of your nearest Heatilator dealer, please visit www.heatilator.com. Printed in U.S.A. - Copyright 2015 Heatilator • ION-V7, ION-S7, ION-H7 Installation Manual • 2276-980 Rev. E • 5/15...
