Octava HDMX44-V1.3 Installation Manual

4x4 hdmi matrix seitch
Hide thumbs Also See for HDMX44-V1.3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Enlarged version
Description
Model
HDMI Inputs
HDMI Outputs
Version
HDCP
IN/Out Connectors
RS-232 control port
Display Selection
Video Resolution
Video Data Rate
Deep Color Support
Vertical Frequency Scan Rate
Dimension
DC adapter (included)
Rackmount capable
Remote control (IR)
For Questions and support:
Email :
info@octavainc.com
URL: www.octavainc.com
Copyright© 2009 Octava Inc. All rights reserved.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LL.C
All trademarks are the sole property of their respective companies
Specifications
HDMX44-V1.3
4
4
1.3
Yes
19 pin HDMI female type-A
1
Remote, Manual, Smart Scan
480 P, 720 I/P, 1080 I/P
6.75 Gbps
Yes
24 / 50 / 60 Hz
14.93 x 6.30 x 1.67 inch
(379.2 x 160.1 x 42.3 mm)
9VDC, 2.0A
1RU, Rack mounts included
Infrared, Discrete code
Rev. C
V 1.3
Deep Color
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDMX44-V1.3 and is the answer not in the manual?

Questions and answers

Related Manuals for Octava HDMX44-V1.3

Summary of Contents for Octava HDMX44-V1.3

  • Page 1 For Questions and support: Email : info@octavainc.com URL: www.octavainc.com Copyright© 2009 Octava Inc. All rights reserved. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LL.C All trademarks are the sole property of their respective companies...

  • Page 2: Table Of Contents

    Table of contents 1. Application Diagram 2. Installation 3. Clear EYE 4. Smart Scan 5. Configuring Smart Scan 6. Description 7. Features 8. Short Cuts 9. Remote Control Guide 10. RS232 Controls 11. RS232 Command Table 12. 1 RU Rackmount 13.

  • Page 3: Application Diagram

    Application Diagram Installation: 1) Connect the Monitor to the HDMI OUT A 2) Connect the second monitor/projector to HDMI OUT B 3) Connect the HDMI sources to the HDMI INPUTS 4) Turn On your HDTV and at least 1 HD source 5) Connect the DC power adapter Clear EYE Our proprietary Clear EYE...

  • Page 4: Smart Scan

    Smart Scan feature. Description: The Octava 4x4 HDMI Matrix Switch allows you to route 4 HD sources to any 4 HD displays! The 4x4 HDMI matrix allows 256 viewing combination of 4 HD sources on 4 HDTVs. You can create Picture By Picture or even have the SAME picture on all 4 HD screens.

  • Page 5: Features

    1 RU Rackmount : Features:  The Octava 4x4 HDMI Matrix Switch can be installed in a 1 RU rack by simply Watch ANY 4 HD programs simultaneously on 4 Displays!  installing the rack mounts included. V1.3, 1080P ...

  • Page 6: Short Cuts

    Short Cuts: RS232 Command Table: The Octava 4x4 HDMI Matrix Switch offers several “short cuts” with the Output A Control remote control for the most common scenarios. Output-Input ASCII Function Selection <STX>211<ETX> Select OUT A to Input port 1 <STX>212<ETX>...

  • Page 7: Remote Control Guide

    Source 1,2,3,4 Selects the corresponding numbered source. Turns ON/OFF the LED light. Turns ON/OFF the HDMI switch Other Not used Octava’s Remote control uses discrete code so can be easily integrated with most Universal Remote Controls such as Logitech’s Harmony.

  • Page 8: Rs232 Controls

    Use the remote control to select the Display that you wish to control followed by the Input (DVD, Settop) that you wish to watch. The Octava 4x4 HDMI Matrix Switch can be easily integrated with Party control systems via RS232 control. The following shows the control protocol for controlling the HDMX44.
