Remote Control; Mode Button; Clock Button; Battery Installation - ProScan PSB3751 Instruction Manual

Remote Control

1
2
3
4
5
6
7
8
9
1.MODE Button
2. Standby Button
3. FM SCAN Button
4. TUN - Button
5. M+ ( Preset recall) Button
6. EQ Butt on

BATTERY INSTALLATION

- Before installation
Remove and discard the insulation tab.
-Replace battery for the remote control
1. Push and slide out the battery holder as Figure 1 below.
2. Replace the battery with a new CR2025 button cell with the polarity (+) side upward.
3. Slide into the battery holder.
Battery precautions
• Never recharge the batteries, apply heat to them or take them apart.
•Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
• Do not throw the batteries in fire!
• Attention should be drawn to the environmental aspects of battery disposal.
• If the remote control is not going to be used for a long time, remove the battery
to avoid damage caused by battery leakage corrosion.
MODE
TUN- TUN+
FM SCAN
M+ EQ
CLOCK
VOL- VOL+
BASS- BASS+
TREBLE- TREBLE+
7. VOL- (Volume-) Button
8. BASS- Button
9. TREBLE- Button
10. Mute Button
11. TUN+ Button
12. CLOCK Button
6
10
11
12
13
14
15
16
13. VOL+ (Volume+) Button
14. BASS+ Button
15. Play/Pause Button
16. TREBLE+ Button
