ProScan PSB3751 Instruction Manual page 4

MOUNTING
Metal Bracket
1. Follow the figure 1 above to determine the positions where the screws should be mounted.
Make sure the two brackets are mounted in the same level.
Fixing Plug
Metal Bracket
Screw
2. Insert the fixing plugs into the screw holes and insert screws to fix the metal bracket onto the
wall.
1
734 mm
+/- 3 mm
2
3
Metal Bracket
Fixing Plug
Metal Bracket
Screw
