TOUCH-UP
SPRAY GUN
160-240ml/min
INSTRUCTION MANUAL
SPECIFICATIONS
Max Air Pressure:
50psi (3.4Bar)
Av. Air Consumption:
56-170l/min (2-6cfm)
Nozzle Size:
ø1.5mm
Spray Width:
40-70mm
Flow Rate:
160-240ml/min
Feed Type:
Suction
Paint Pot Size:
200ml
Air Inlet:
1/4" BSP
Weight (tool only):
0.4kg
ozito.com.au
WHAT'S IN THE BOX
Spray Gun
Paint Pot
ASG-PRO
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ozito ASG-PRO
Summary of Contents for Ozito ASG-PRO
-
Page 1: Spray Gun
INSTRUCTION MANUAL SPECIFICATIONS Max Air Pressure: 50psi (3.4Bar) Av. Air Consumption: 56-170l/min (2-6cfm) Nozzle Size: ø1.5mm Spray Width: 40-70mm Flow Rate: 160-240ml/min Paint Pot Feed Type: Suction Paint Pot Size: 200ml Air Inlet: 1/4” BSP Weight (tool only): 0.4kg ozito.com.au ASG-PRO... -
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION TOUCH UP SPRAY GUN 1. ASSEMBLY 1 Nozzle 5 Tightening Collar 2 Nozzle Collar 6 Variable Trigger WARNING! ENSURE THE TOOL IS DISCONNECTED FROM 3 Fan Adjustment Dial 7 Spray Regulation Dial THE AIR SUPPLY BEFORE PERFORMING ANY OF THE FOLLOWING OPERATIONS. -
Page 3: Operation
OPERATION 2. PREPARATION 3. ADJUSTING THE SPRAY GUN Variable Trigger NOTE: FOR BEST RESULTS, SURFACE PREPARATION AND PAINT THINNING ARE THE TWO MOST IMPORTANT AREAS. ENSURE 1 Press the variable trigger ALL SURFACES ARE FREE OF DUST, DIRT AND GREASE. to allow fluid to be sprayed. - Page 4 2. Maintain the same speed throughout each pass. 3. Always allow a coat to completely dry before adding another coat. 4. Avoid stopping and starting in the middle of workpiece as this can lead to a patchy finish. ASG-PRO...
-
Page 5: Cleaning Procedure
Check with your local council authority for recycling advice. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the spray gun by an unauthorised person or by Recycling packaging reduces the need for landfill and raw materials. - Page 6 SPARE PARTS How To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any further questions, please contact Ozito Customer Service on: Australia: 1800 069 486 New Zealand: 0508 069 486...
-
Page 7: Spray Gun Safety Warnings
GENERAL AIR TOOL SAFETY WARNINGS WARNING! WARNING! Read all safety warnings and all instructions. Failure to follow the warnings In the event that an air line is cut or broken, the air supply must be turned off at the and instructions may result in electric shock, fire and/or serious injury. compressor. -
Page 8: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0414...
