PoE Function IP Extender
User Manual
SPO-100

Advertisement

   Related Manuals for Samsung SPO-100

   Summary of Contents for Samsung SPO-100

  • Page 1

    PoE Function IP Extender User Manual SPO-100...

  • Page 2: User Manual

    Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.

  • Page 3

    overview Please read the following recommend safety precautions carefully. y Please do not install the device in a location where the temperature gets higher than 50 °C or lower than -10°C, nor in a location where there is a lot of rain or snow or where humidity is high, nor in a location that is exposed to oil or gas, nor in a location that experiences vibration or shocks, nor in an outside area, nor exposed to direct light, nor in a location close to strong magnetism, high frequency (RF) or power...

  • Page 4: Table Of Contents

    overview Contents ovERvIEw Contents Product Introduction Product Features Application What’s Included Connecting the UTP cable At a Glance InSTALLATIon & Connecting with other Device ConnECTIon APPEnDIx Specification Product Overview 4_ overview...

  • Page 5: Product Introduction

    Each time this device is installed, the maximum transmission distance for Ethernet data is extended by more than 100m. The number of SPO-100 systems that can be added is limited by the rated capacity of the IP camera. A camera with up to 11.7W power consumption can be connected when power is supplied through the PoE HUB.

  • Page 6: Overview

    overview What’s InCluded Please check if your network video encoder and accessories are all included in the product package. Appearance Item Name Quantity Ethernet extender User Manual ConneCtIng the utP Cable Use the cable after checking the 4P UTP cable wiring method. Scheme of TIA / EIA 568B Orange+White Tx +...

  • Page 7

    at a glanCe Front side Item Description Network connection The connection terminal of the IP camera, which uses PoE, terminal acts as a power supply and data port . LED Status Status indication PoE IN YELLOW No Power Linked GREEN Flash Data Active Not Linked...

  • Page 8

    overview rear side Item Description Network connection It receives power through the PoE switching hub / PoE injector / terminal NVR connection terminal and transmits camera data to the NVR. LED Status Status indication 100Mbps Linked YELLOW 10Mbps Linked Linked GREEN Flash Data Active...

  • Page 9: Installation & Connection

    installation & connection ConneCtIng WIth other devICe Connecting the camera CaMera Connect the [ ] terminal of the device and video output terminal of the camera. Camera English _9...

  • Page 10

    & connection Connecting a product Using a switching hub, multiple devices can be connected within the available power range (6.3W - 11.7W) of the SPO-100. supplying the power through the switching hub with built-in Poe function PoE Switching HUB...

  • Page 11

    Maximum extensible distance when using the Poe hub Maximum Camera extensible extender power Available Samsung Cameras (example) distance quantity standards SNB-3002, SNB-5004, SNB-6004, SNB-6003, SNO-7084R, SNO-6084R, SND-3082, SND-7084, SND-7084R, Less than 200m SND-5083, SND-5084, 11.7W SND-5084R, SND-6084, SNF-8010, SNV-6084R, SNV-7084R, SNV-3082...

  • Page 12: Appendix

    appendix sPeCIFICatIon Items Description Data transmission speed 100Mbps(MAX) (TCP Rate) Network Data transmission method Full Duplex Operating Temperature Environmental -10°C ~ +50°C / 0% ~ 90% RH / Humidity Applicable power (MAX.) 6.3W ~ 11.7W Electrical Internal power consumption 1.7W Max. Material Aluminum Mechanical...

  • Page 13: Product Overview

    ProduCt overvIeW Unit : mm (inch) English _13...

  • Page 14

    Samsung Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.

  • Page 15

    SALES NETWORK SAMSUNG TECHWIN CO., LTD. 6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, SEOUL 463-400 Rep. of KOREA Tel : +82-70-7147-8753, 8764 Fax : +82-31-8018-3740 www.samsungsecurity.com SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 2nd Floor, No.
