When all of your connections are made, the status LEDs on the front of your Motorola IAD Gateway
will light, according to the following diagram:

Front View

Power -
Green
when power is on.
Red
if device malfunctions; flashes
red
when updating embedded software.
Ethernet 1, 2, 3, 4 -
Solid
green
when connected.
Flash
green
activity on the LAN.
WPS -
Solid
green
6
when there is
when WPS is successful.
Internet -
Green
when device is
connected. Flashes
for activity on WAN port.
DSL -
Flashes
green
when training.
Solid
green
when trained.
Wireless -
Flashes
green
when there is
activity on the wireless LAN.
