User Manual
®
The Motorola Netopia
2247-N8
DSL Gateway
4-port Ethernet, 802.11b/g/n Wi-Fi

   Summary of Contents for Motorola 2247-62-10NA - Netopia 2247-62 Wireless Router

  • Page 1

    User Manual ® The Motorola Netopia 2247-N8 DSL Gateway 4-port Ethernet, 802.11b/g/n Wi-Fi...

  • Page 2

    (such as translation, transformation or adaptation) without written permission from Motorola, Inc. Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3

    Checklist ® Thank you for selecting the Motorola Netopia 2247-N8 DSL Gateway. This guide will help you set up and configure your network. Check your package contents. It should contain the items shown here: Motorola Gateway CD & User Manual...

  • Page 4

    Connect the power supply to the power jack on the back panel of the Gateway. Then, plug the power supply into an electrical outlet. Turn on the Power switch. Power LED should light solid green. ® Insert the Motorola Netopia CD into your CDROM drive. ® The Motorola Netopia Installa-...

  • Page 5: Rear View

    When all of your connections are made, your network may look like this: Rear View Ethernet Ports Pushbutton DSL Port Power Switch DC Power Enable Wireless Protected Setup (WPS) on your Wi-Fi devices. Adding wireless clients to your network is easier using Wireless Protected Setup (WPS). Older, non-WPS clients can still be added to the network by configuring them the stan- dard way with WPA-PSK.

  • Page 6: Front View

    When all of your connections are made, the status LEDs on the front of your Motorola IAD Gateway will light, according to the following diagram: Front View Power Activity Ethernet 1, 2, 3, 4 Internet Wireless Behavior Green when power is on.

  • Page 7

    Behavior Solid green when WPS is successful. Not currently used. Flashes green when training. Solid green when trained. Green when device is connected. Flashes green for activity on WAN port. Internet Off = The device is not powered or the broadband connection is not present; Activity Flashing green = Inbound Internet activity seen from the broadband connec-...

  • Page 8

    Device Configuration You can access the configuration pages at any time as follows: Run a Web browser, such as Firefox, Safari, or Microsoft Internet Explorer, and enter http://192.168.1.254 in the URL Address text box. Press Return. (If your ISP’s Configuration Worksheet tells you to use an IP address other than 192.168.1.254 to log in, enter http://<...

  • Page 9

    This user name and password are separate from the user name and password you might use to access the Internet. You may change them later. You will be challenged for this Admin username and password any time that you attempt to access the Motorola Neto- ®...

  • Page 10

    Should you require additional information, the “FAQs” on page 14 of this Guide contain Fre- quently Asked Questions (and Answers) and “Basic Troubleshooting” on page 16 gives Basic Troubleshooting tips. The latest Administrator’s Handbook with advanced configuration instruc- tions is also available on-line at: http://broadband.motorola.com/consumers/support/default.asp?supportSection=blank...

  • Page 11

    Client Configuration Your Gateway serves Dynamically-assigned IP addresses by default. Be sure to configure each computer connected to your Gateway to accept a Dynamically-assigned IP address, commonly referred to as DHCP. Microsoft Windows: Step 1. Navigate to the TCP/IP Properties Control Panel. Windows 98, 2000, and ME versions follow a path like this: Start menu ->...

  • Page 12

    Windows Vista is set to obtain an IP address automatically by default. You may not need to configure it at all. To check, open the Networking Control Panel and select Internet Protocol Version 4 (TCP/IPv4). Click the Properties button. The Internet Protocol Version 4 (TCP/IPv4) Properties window should appear as shown.

  • Page 13

    Macintosh Mac OS 9 or Mac OS X: Step 1. Access the TCP/IP or Network control panel. a. Mac OS 9 follows a path like this: Apple Menu -> Control Panels -> TCP/IP Control Panel b. Mac OS X follows a path like this: Apple Menu ->...

  • Page 14

    Q: I forgot my password, how can I access my Motorola Netopia Gateway? A: If you don't have a password, the only way to access the Motorola Gateway is the fol- lowing: Referring to the following diagram, find the round Reset Switch opening.

  • Page 15

    Note: By default, your Motorola Netopia Gateway has an Ethernet IP Address of 192.168.1.254. ® Q: What is the default user name and password of the Motorola Netopia Gateway? ® A: Motorola Netopia Gateways are not distributed with a default password. Upon initial...

  • Page 16

    Basic Troubleshooting This section gives some simple suggestions for troubleshooting problems with your Gateway’s initial configuration. Before troubleshooting, make sure you have • plugged in all the necessary cables (see “Connections” on page 4); and • set your PC’s TCP/IP controls to obtain an IP address automatically (see “Client Configu- ration”...

  • Page 17

    LED Function Summary Power Internet Unlit No power No signal Not connected Solid Green Power on DSL line synched with Connected to the Inter- the DSLAM Flashing Green Activity on the DSL Transmitting or receiv- cable ing data on the WAN port Solid Red System malfunction...

  • Page 18

    If a status indicator light does not look correct, look for these possible problems: If LED is Possible problems not Lit • Make sure the power switch is in the ON position. • Make sure the power adapter is plugged into the DSL Gateway properly. Power •...

  • Page 19

    • Make sure you are using the Ethernet cable, not the DSL cable. The Ether- net cable is thicker than the standard telephone cable. • Make sure the Ethernet cable is securely plugged into the Ethernet jack on the PC. •...

  • Page 20

    Answers to many frequently asked product-related questions, as well as full product documen- tation with advanced configuration instructions, are also available on-line at: http://broadband.motorola.com/consumers/support/default.asp?supportSection=blank Note the serial number (SN:) of your Gateway. It is located on the label on the bottom of the Gateway below the model number.

  • Page 21

    If collection systems are not available, call Motorola Customer Service for assistance. For instructions on recycling please visit: http://www.motorola.com/recycle Recycling bei Geräten von Motorola Umweltschutz durch Recycling Bitte entsorgen Sie dieses Produkt nicht als gewöhnli-...

  • Page 22

    électriques et électroniques mis au rebut. Veuillez contacter vos autorités locales pour vous informer des pratiques instaurées dans votre region. Si aucun système de collecte n'est disponible, veuillez appeler le Service clientèle de Motorola qui vous apportera son assistance.
