Taski swingo 1255B Technical Manual page 91

4
S007389
Artikelnr. Bestellnr.
Pos.
Article No. No. de com
No.
Item No. Order No.
101 17620- - 47 4128231
102 17620- - 48 4128232
103 1132/186 4065050
104 17620- - 50 4128234
105 2804/105 4128743
106 2511/107 4126535
107 1142/175 4126662
108 17620- - 89 4128598
109 17608- - 76 4126609
110 17701- - 55 4127926
111 17620- - 51 4128235
112 17620- - 49 4128233
113 2913/148 4058370
114 2807/007 4128597
115 1721/7 4031060
116 17620- - 52 4128236
117 8936/1 4017370
118 8906/106 4122242
TASKI swingo 1255B
Düsenabsenkung
Stck.
Model Piè. Bezeichnung
Qty.
1.00 Düsenarm lang
1.00 Achse
2.00 Zyl- - Schr I- - 6Kt M8x12
2.00 Bolzen
1.00 Druckfeder 5,6/33,6x66
6.00 Gleitlager 8/10/15x5.5
1.00 Zyl- - Schr I- - 6Kt M10x40
1.00 Gleitlager 28/32/42x14
1.00 Distanzscheibe 10.5/42
1.00 Fusshebelschutz
1.00 Düsenarm
2.00 Achse
4.00 Sicherungsscheibe Welle 6x0,7
1.00 Zugfeder 2.8/20/95.8
1.00 Sicherungsmutter M10
1.00 Buchse
1.00 Sicherungs- - Klebstoff mittel
1.00 Getriebefett OKS 427, 1Kg
Dispositif remontèe suceur
Designation
Bras de pivotement long
Axe
Vis cyl. à trou 6 p. M 8x12
Goujon
Ressort de pression 5,6/33,6x66
Coussinet 8/10/15x5,5
Vis cyl. à trou 6 p. M 10x40
Coussinet 28/32/42x14
Disque 10.5/42
Pédale
Bras de pivotement
Axe
Anneau de sûreté p. arbre 6
Ressort de tension 2.8/20/95.8
Écrou de sureté M 10
Douille
Colle p. blocage moyen 50 gr
Graisse - - engrenage,palier 1Kg
Squeegee lowering
mechanism
Description
Swinging Arm Long
Axle
Socket Head Cap Screw M 8x12
Bolt
Pressure Spring 5,6/33,6x66
Slide Bearing 8/10/15x5,5
Socket Head Cap Screw M 10x40
Slide Bearing 28/32/42x14
Washer 10.5/42
Foot Lever
Swinging Arm
Axle
Circlip For Shaft 6
Tension Spring 2.8/20/95.8
Self- - Locking Nut M 10
Bush
Adhesive Locking Middle 50Gr
Lubricant - - Gear,Bearing 1 Kg
