Taski swingo 1255B Technical Manual page 103

16
S007395
Artikelnr. Bestellnr.
Pos.
Article No. No. de com
No.
Item No. Order No.
101 2178/12 4042280
102 8820/105 4053660
103 2631/084 4100700
104 2631/055 4067920
106 1840/050 4122639
107 17607- - 95 4123751
108 3002/183 4122887
109 8820/10 4028460
110 8820/10 4028460
111 8819/192 4103370
112 8819/192 4103370
113 8820/10 4028460
114 2631/074 4122769
115 8820/10 4028460
118 8821/108 4122625
119 2761/131 4066380
- -
- -
- -
120 17700- - 07 4126924
121 17563- - 33 4095220
122 17560- - 03 4075300
123 17560- - 00 4075280
124 1840/103 4062780
131 17607- - 08 4122833
132 17608- - 85 4126691
133 17603- - 23 4122598
134 1654/118 4083980
135 1004/65 4030840
136 8936/1 4017370
137 4850/101 4100320
TASKI swingo 1255B
Schlauchleitungen
Stck.
Model Piè. Bezeichnung
Qty.
7.00 Schlauchklemme 12- - 22
0.86m 1.00 Schlauch m Draht 12/19
1.00 T- - Reduzierstutzen TRS 10- - 6- - 10
1.00 Y- - Stück 12
1.00 Delta PT- - Schr LK As Torx 60x20
1.00 Ventilgehäuse
1.00 O- - Ring 23,47x2,62
0.10m 1.00 Schlauch m Draht 10/16
0.46m 1.00 Schlauch m Draht 10/16
0.06m 2.00 Schlauch 9/16 spez. Tygon
0.06m 2.00 Schlauch 9/16 spez. Tygon
0.15m 2.00 Schlauch m Draht 10/16
2.00 T- - Schlauchverbinder Ts10
0.26m 1.00 Schlauch m Draht 10/16
1.19m 1.00 Schlauch 5/9 PVC
1.00 Rückschlagventil
1.00 - -
1.00 - -
1.00 - -
1.00 Filter 24V
1.00 Filtersieb 05
1.00 Dichtung
1.00 Filterdeckel
2.00 Delta PT- - Schr LK As Torx 40x25
1.00 Motor 24V 750W 40A Entstört
3.00 Bolzen
1.00 Pulley 7 PJ 28
1.00 Sechskantmutter M12 L
3.00 6Kt- - Schr M6x16
1.00 Sicherungs- - Klebstoff mittel
1.00 Ferrit- - Ringkern 28/16x13
Tubes
Designation
Bride 12- - 22
Tuyau spirale 12/19 le m
Raccord T 10- - 6- - 10
Raccord Y 10- - 11
Vis Delta PT Torx 60x20
Corps de soupape
Joint- - O 23,47x2,62
Tuyau spiralflex 10/16 le m
Tuyau spiralflex 10/16 le m
Tuyau 9/16 Tygon le m
Tuyau 9/16 Tygon le m
Tuyau spiralflex 10/16 le m
T de raccordement TS 10
Tuyau spiralflex 10/16 le m
Tuyau 5/9 le m
Soupape de retenue
- -
- -
- -
Filtre 24V
Filtre
Joint
Couvercle
Vis Delta PT Torx 40x25
Moteur 24 G4482V av.antiparasit
Douille d'appui
Poulie
Écrou à six pans M 12 f.a.g.
Vis à tête six pans M 6x16
Colle p. blocage moyen 50 gr
Self à noyau torique 28/16x13
Tube lines
Description
Hose Clamp 12- - 22
Hose W.Wire Spiral 12/19 P.M.
T- - Nipple 10- - 6- - 10
Y- - Pipe
Screw Delta PT Torx 60x20
Valve Body
O- - Ring 23,47x2,62
Hose Spiralflex 10/16 Per M
Hose Spiralflex 10/16 Per M
Special Hose 9/16 Tygon per M
Special Hose 9/16 Tygon per M
Hose Spiralflex 10/16 Per M
T- - Nipple TS 10
Hose Spiralflex 10/16 Per M
Hose 5/9 Per M
Check Valve
- -
- -
- -
Filter 24V
Filter
Gasket
Cover
Screw Delta PT Torx 40x25
Motor 24 V W.Noise Sup.
Carrying Bracket
Pulley
Hexagon Nut M 12 L.H.Thread.
Hexagon Screw M 6x16
Adhesive Locking Middle 50Gr
Toroidal Choke 28/16x13
