A. SAFETY INSTRUCTIONS ˙ Read all cautions/warnings and obtain proper instruction on use of the machines prior to using. Use appropriate positioning and controlled movements. ˙ Assemble and operate the strength on a solid, level surface. Do not use outdoors or near water.
Page 3
B. Introduction Side frame Badge, rear Badge, front Front cover (B) Right grip Usage sticker Back cushion Rear cover Left grip Seat cushion and Cord seat cushion Stack fork adjustment handle Hydraulic shock Pedal push rod assembly Front cover (A) Pedal push rod assembly-right Foot pad...
Page 4
C. List of Parts 1. One side frame. 2. One support frame 3. One pedal push rod assy 4. One pedal push rod 5. One grip 6. Four hex socket head bolts M8 x P1.25 x L30, for the pedal push rod assembly and pedal pushing rod ( right and left 7.
Page 5
D. STEP BY STEP INSTRUCTION: 1. Tighten the pedal pushing rod with screws as shown in Fig.1. Fig.1 2. Tighten the grip with screws as shown in Fig.2. Fig.2...
Page 6
3. Tighten the pedal push assembly and both left and right push rods together with screws as shown in Fig. 3. Fig.3 4. Assemble the belt and secure the screws tightly as shown in Fig. 4. Fig.4...
Page 7
5. Please check the machine to see if both sides are level after assembly. Padding either post with cardboard or wood plank to make both sides at the same level. Then check the tightness of inserting the stack fork. Note: If you feel too tight or too loose when you insert the stack fork between the weight stacks, it means the machine is not level so padding the post with the stuff is required.
E. BELT ADJUSTMENT: 1. If the belt is too tight or too loose, first loosen nut A as shown then adjust nut B. If the belt length is too long, adjust downward; if the belt length is too short, adjust upward.
Page 9
HOW TO USE THE MINOR WEIGHT STACK 1. To adjust the minor weight stack, insert the upper pin to add 3.5Lbs/1.5kgs or the lower pin to add 6.5Lbs/3kgs. 2. Pull the pin to release the weight. (See Fig. 7) 3.5Lbs/1.5kgs 6.5Lbs/3kgs Fig.7...
Page 10
G. STORAGE TRAY ASSEMBLY Applicable strength products include that these products have the frame as following shape. Step 1: Remove the existing screw and washer from tubing. Step 2: Place storage tray onto tubing and tighten with the. screw and washer that you just removed from step.
H. Maintenance Information 1. Lubricate guide rods every four months as follows. (a) Place silicone lubricant on a clean, dry, lint-free cloth. Wipe guide rods thoroughly. (B) Operate the unit and inspect for smoothness. (c) Repeat steps (a) and (b) 2~3 times. 2.
I. Important Safety Information 1. We recommend replacing belts once a year. 2. For safety, after one year of use, inspect the following at least once a month: A. the belt area; B. the belt fibers. In particular, inspect for cracks in the belt and for exposed fibers or other abnormalities.
J. MAINTENANCE SCHEDULE (A915) Maintenance Schedule Clean. Unit exterior Inspect for looseness. Screws Tighten if necessary. Wipe clean with a damp cloth. Cushions Inspect for wear. Replace Belt every four years. Clean, then lubricate. Guide rods Extension Clean, then lubricate.
K. MAINTENANCE TASK LIST (STRENGTH PRODUCTS): Like cars, fitness products require maintenance. Regular maintenance extends product life, and failure to maintain products can void the manufacturer's warranty. Copy the maintenance log sheet, and record maintenance work for each fitness product. Daily tasks 1.
