Konica Minolta bizhub 364e Specification & Installation Manual

Konica Minolta bizhub 364e/284e /224e
Specification & Installation Guide
bizhub 364e/284e/224e Specifications
Type Monochrome Printer/Copier/Scanner
Document holder Stationary (mirror scanning)
Photoconductor OPC
Luminous source LED light-source illumination
Copying system Laser electrostatic copy method
Developing system Dry-2 component developing method
Fusing system Belt Fusing
Resolution Scanning: 600 x 600 dpi
Printing: 1200 x 1200 dpi
Document holder Types: Sheets, books (2-page spreads),
three-dimensional objects
Size: Maximum 11" x 17"
Weight: 4.4 lb.
Paper Thin Paper (14 lb. to 15.5 lb.)*
Plain Paper (16 lb. to 24 lb.)
Thick Paper 1 (24.25 lb. to 32 lb.)
Thick Paper 1+ (32.25 lb. to 41.75 lb.)
Thick Paper 2 (42 lb. to 55.5 lb.)
Thick Paper 3 (55.75 lb. to 68 lb.)
Thick Paper 4 (68.25 lb. to 79.75 lb.)**
Recycled Paper (16 lb. to 24 lb.)
Special Paper (16 lb. to 24 lb.)
Letterhead (16 lb. to 24 lb.)
Color Paper (16 lb. to 24 lb.)
1-Sided Special Paper (16 lb. to 24 lb.)
Banner Paper** (34 lb. to 55.5 lb.)
OHP Transparencies**, envelopes**,
label sheets**, tabs**, postcards**
*Cannot be fed through the bypass tray.
**Can only be fed through the bypass tray.
Copy sizes 1st Tray:
11" x 17" to 8.5" x 11", 5.5" x 8.5", 8" x 13"*
2nd Tray:
12.25" x 18" to 8.5" x 11", 5.5" x 8.5", 8" x 13"*
Bypass Tray:
12" x 18" to 5.5" x 8.5", 12.25" x 18", 4" x 6",
8" x 13"*, Banner Paper
* There are six Foolscap sizes: 220 x 330mm (L),
8.5" x 13.5", 8.5" x 13" (L), 8.25" x 13 (L),
8.12" x 13.25" (L) and 8" x 13" (L). Any one of these
sizes can be selected. For details, please consult with
your authorized Konica Minolta Service representative.
Paper tray 1st Tray and 2nd Tray:
capacity Thin Paper/Plain Paper/Recycled Paper/
Special Paper/Letterhead/Color Paper/
1-Sided Special Paper: 500 sheets;
Thick Paper 1/1+/2/3: 150 sheets
Paper tray Bypass Tray:
capacity (cont.) Plain Paper/Recycled Paper/Special Paper/
Letterhead/Color Paper/1-Sided Special
Paper: 150 sheets; Thick Paper 1/1+/2/3/4/
OHP Transparencies/Postcards/Tabs: 20
sheets; Envelopes: 10; Banner Paper/Label
Sheets: 10 sheets
Copy exit tray Thin Paper: 100 sheets
capacity Plain Paper: 250 sheets
Thick Paper: 10 sheets
Overhead Projection
Transparencies*: 1 sheet
*Can only be fed through the bypass tray.
Warm-up time Less than 20 seconds
(at room temperature/73.4° F)
Image loss width Leading Edge: 0.165"
Trailing Edge: 0.118"
Rear Edge: 0.118"
Front Edge: 0.118"
Thin Paper: 0.197"
First copy 364e: 5.3 sec. or less
284e: 5.9 sec or less
224e: 6.9 sec or less
Print speed*: bizhub 364e:
(Simplex/Duplex) Plain paper: 36 sheets/min.
Thick 1/Thick1+/Thick 2/Thick 3/Thick 4:
18 sheets/min.
bizhub 284e:
Plain paper: 28 sheets/min.
Thick 1/Thick 1+/Thick 2/Thick 3/Thick 4:
14 sheets/min.
bizhub 224e:
Plain paper: 22 sheets/min.
Thick 1/Thick1+/Thick 2/Thick 3/Thick 4:
14 sheets/min.
Print speed (ppm)*: Single Sided/Plain Paper:
Size
11" x 17"
8.5" x 14"
8.5" x 11"P
8.5" x 11"L
5.5" x 8.5"L
8" x 13"L
*Using 1st Tray
Print speed (ppm)*: Double Sided/Plain Paper:
Size
continued
11" x 17"
8.5" x 14"
8.5" x 11"P
8.5" x 11"L
5.5" x 8.5"L
8" x 13"L
*Using 1st Tray
Magnification 1.0 (full size: 1.00+_0.5% or less)
ratios Enlarge: 121.4%, 129.4%, 154.5%, 200%
Reduce: 78.5%, 73.3%, 64.7%, 50.0%
Minimal: 93%
Stored Zoom Ratios: 3
"Minimal" zoom ratio (90% to 99.9%)
10/25/2013
364e 284e 224e
18 14 14
20 16 16
36 28 22
26 20 20
36 28 22
20 16 16
364e 284e 224e
18 14 14
20 16 16
36 28 22
25 20 20
36 28 22
20 16 16
continued
