NETWORK PORT
DEFINITION
Lot 26 (801/2013/EU)
for bizhub black/white products
Status: 12.2016
Version: 1.0
NETWORK PORT
DEFINITION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the bizhub 758 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Konica Minolta bizhub 758

Summary of Contents for Konica Minolta bizhub 758

  • Page 1 NETWORK PORT DEFINITION Lot 26 (801/2013/EU) for bizhub black/white products Status: 12.2016 Version: 1.0 NETWORK PORT DEFINITION...

  • Page 2: Table Of Contents

    NETWORK DEFINITION PORT for bizhub black/white products Index • bizhub 758/PRO 958 ..................... 3 • bizhub 558/458/368/308 ....................5 • bizhub 654e/754e......................7 • bizhub 554e/454e/364e/284e/224e ................9 • bizhub 306/266 ......................10 • bizhub 367/287/227..................... 11 • bizhub 4750/4050......................12 •...

  • Page 3: Bizhub 758/Pro 958

    NETWORK DEFINITION PORT for bizhub black/white products bizhub 758/PRO 958 Name Description Finisher Connector Connect the cable of the Finisher. Filter Used to collect toner powders inside the main unit. Power Cord Used to supply power to this machine. Heater Power Switch Used to turn Heater operations on or off.
  • Page 4 NETWORK DEFINITION PORT for bizhub black/white products Name Description Network Connector Connect to this port when using this machine as a network printer or network (10Base-T/100Base- scanner. TX/1000Base-T) USB Port (Type A) Used to connect the Fax Kit (line 2) cable. USB2.0/1.1 USB Port (Type A) Used to connect the Fax Kit (line 1) cable.

  • Page 5: Bizhub 558/458/368/308

    NETWORK DEFINITION PORT for bizhub black/white products bizhub 558/458/368/308 Name Heater Power Switch Power Cord Telephone Jack 4 (LINE PORT4) Telephone Jack 3 (LINE PORT3) Jack for connecting a telephone (TEL PORT1) Telephone Jack 1 (LINE PORT1) Telephone Jack 2 (LINE PORT2) USB Port (Type A) USB2.0/1.1 Network Connector (10Base-T/100Base-TX/1000Base-T) USB Port (Type B) USB2.0/1.1...
  • Page 6 NETWORK DEFINITION PORT for bizhub black/white products Declaration The network ports, which we declare in the sense of Lot 26 (801/2013/EU), are No.9 and No.10. With this network port, the machine has low energy consumption in networked standby mode. The network ports are activated when cables are inserted to the ports.

  • Page 7: Bizhub 654E/754E

    NETWORK DEFINITION PORT for bizhub black/white products bizhub 654e/754e Name Description Finisher Connector Connect the cable of the Finisher. Filter Used to collect toner powders inside the main unit. Telephone Jack 3 (FAX3) Used to connect a general telephone subscriber line. Telephone Jack 4 (FAX4) Used to connect a general telephone subscriber line.
  • Page 8 NETWORK DEFINITION PORT for bizhub black/white products Name Description USB Port (Type B) Connect to this port when using this machine as a USB-connected printer. USB2.0/1.1 USB Port (Type A) Used to connect Authentication Unit AU-102 or Authentication Unit AU-201. USB2.0/1.1 Jack for connecting a Used to connect a telephone cord.

  • Page 9: Bizhub 554E/454E/364E/284E/224E

    NETWORK DEFINITION PORT for bizhub black/white products bizhub 554e/454e/364e/284e/224e Name Description Power Cord Used to supply power to this machine. USB Port (Type A) Used to connect Authentication Unit AU-102 or Authentication Unit AU-201. USB2.0/1.1 Network Connector Connect to this port when using this machine as a network printer or network (10Base-T/100Base- scanner.

  • Page 10: Bizhub 306/266

    NETWORK DEFINITION PORT for bizhub black/white products 10 bizhub 306/266 Declaration The network ports, which we declare in the sense of Lot 26 (801/2013/EU), are "Network nonnector (10 Base-T/100 Base-TX)" and "USB port (type B) for USB 2.0". With this network port, the machine has low energy consumption in networked standby mode. The network ports are activated when cables are inserted to the ports.

  • Page 11: Bizhub 367/287/227

    NETWORK DEFINITION PORT for bizhub black/white products 11 bizhub 367/287/227 Name Description Power Cord Used to supply power to this machine. USB Port (Type B) Connect to this port when using this machine as a USB-connected printer. USB2.0/1.1 Network Connector Connect to this port when using this machine as a network printer or network (10Base-T/100Base- scanner.

  • Page 12: Bizhub 4750/4050

    NETWORK DEFINITION PORT for bizhub black/white products 12 bizhub 4750/4050 Name Power Connection Power Switch USB Printer Port (Type B) Ethernet (LAN) Port (1000Base-T/100Base-TX/10Base-T) LINE (telephone line) Jack TEL (telephone) Jack Declaration The network ports, which we declare in the sense of Lot 26 (801/2013/EU), are No.3 and No.4. With this network port, the machine has low energy consumption in networked standby mode.

  • Page 13: Bizhub 4020

    NETWORK DEFINITION PORT for bizhub black/white products 13 bizhub 4020 Name Description Printer power cord socket Connect the printer to a properly grounded electrical outlet. Power switch Turn the printer on or off. Ethernet port Connect the printer to an Ethernet network. EXT port Connect additional devices (telephone or answering machine) to the printer and the telephone line.

  • Page 14: Bizhub 3320

    NETWORK DEFINITION PORT for bizhub black/white products 14 bizhub 3320 Name Description Printer power cord socket Connect the printer to a properly grounded electrical outlet. Power switch Turn the printer on or off. Ethernet port Connect the printer to an Ethernet network. EXT port Connect additional devices (telephone or answering machine) to the printer and the telephone line.

  • Page 15: Bizhub 4700P/4000P

    NETWORK DEFINITION PORT for bizhub black/white products 15 bizhub 4700P/4000P Name Description USB port Attach an optional wireless network adapter. USB printer port Connect the printer to a computer. Ethernet port Connect the printer to an Ethernet network. Power switch Turn on or turn off the printer.

  • Page 16: Bizhub 3301P

    NETWORK DEFINITION PORT for bizhub black/white products 16 bizhub 3301P Name Description USB port Attach an optional wireless network adapter. USB printer port Connect the printer to a computer. Ethernet port Connect the printer to a network. Parallel port Connect the printer to a computer. Power switch Turn on or turn off the printer.

  • Page 17: Bizhub 226

    NETWORK DEFINITION PORT for bizhub black/white products 17 bizhub 226...
  • Page 18 NETWORK DEFINITION PORT for bizhub black/white products 18 Name Output Tray Front Cover Tray1 1st Side Cover Release Button Bypass Tray Extension Bypass Tray Auto Duplex Unit 1st Side Cover USB Port (Host:Scan to USB) Jack for connecting a telephone (TEL PORT) Telephone Jack (LINE PORT) USB Port (Type B) USB 2.0/1.1 Network Connector (10 Base-T/100 Base-TX)
