Konica Minolta bizhub 554E Quick Reference Manual

bizhub 554e/454e/364e/284e/224e QUICK REFERENCE 1/4
How to use the system – Panel
Interrupt
a copy job
Status indicator
Touch screen
Energy Safe
Mode on/off
Switch to Scan/Fax function*
Switch to Copy function*
* This is a Register key. In the Administrator Settings it can be assigned to any function.
Touch screen – Main menu
Display total number of printed pages
Adjust the touch screen /
configure touch screen operation
Message display
Change to the functions
of the shortcut key
* Up to 24 shortcut keys assigned to any function can be displayed here.
By default, the main menu shows Copy, Scan/Fax, User Box, Sound Setting, and Utility. Utility is always displayed.
Switch to Enlarge
Open Help screen display mode
Login/logout
Display keypad*
Display active or standby jobs
Toner supply indicator
Shortcut key area*
Configure settings/
display use status
Operating the touch screen*
1. Tap to select or determine
a menu.
Switch to main
menu
Keypad KP-101
(option)
Voice Guide (not in use
for European market)
Input a value or a
2. Double-tap to retrieve
number
detailed information
or enlarge a thumbnail
Clear a value
image.
Proof one copy set
3. Drag to move a display
position on an application
Reset the settings
or preview screen.
Stop a process
Start a process
4. Flick to scroll an ad-
dress or job list and feed
thumbnail-view pages.
5. Long-tap to display the
icon related to the docu-
ment.
* Available touch functions vary depending on displayed screen.
6. Drag & Drop to move a
document to the intended
place.
7. Pan to move a displayed
image.
8. Pinch-in/Pinch-out to
enlage or reduce a preview
image.
9. Rotate two fingers to rotate
a preview image.
