- Page 1 ® AVerDiGi SEB5108/5116 series SEB5108 Lite/SEB5116 Lite/SEB5116 Quick Installation Guide...
- Page 3 CONSIDERED FOR REFERENCE ONLY WARNING TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE WARRANTY VOID FOR ANY UNAUTHORIZED PRODUCT MODIFICATION Copyright © 2009 AVerMedia INFORMATION, Inc All rights reserved Reproduction without permission is prohibited...
-
Page 5: Table Of Contents
Content Table Package Contents ..............1 SEB5108 Lite ................1 SEB5116 Lite ................1 SEB5116 ................2 Optional Accessories............... 2 Hardware Installation ..............3 SEB5108 Lite ................6 SEB5116 Lite ................7 SEB5116 ................8 Fist Time to Use DVR System ............ 9 Using the Virtual Keyboard ............ -
Page 7: Package Contents
(2) Quick Installation Guide depending on the standard power outlet of (3) Software CD (User Manual included) the country where it is sold) (4) AVerMedia USB optical mouse (7) SATA cable x 2 (5) Power adaptor (8) Screws for HDD installation... -
Page 8: Seb5116
(2) Quick Installation Guide depending on the standard power outlet of (3) Software CD (User Manual included) the country where it is sold) (4) AVerMedia USB optical mouse (7) SATA cable x 2 (5) Power adaptor (8) Screws for HDD installation... -
Page 9: Hardware Installation
AVerMedia® does not guarantee or provide warranties, explicitly, implied or statutory with respect to the reliability of the hard disk function or its compatibility. In no event AVerMedia® shall be liable for damages, with respect to any business interruption of clients, lost profits, loss of programs or other data on your information handling system or otherwise. - Page 10 Loosen the screws of holder to make hard Loosen all the screws of hard disk plate. disk install more easily. The hard disk plate can be installed up to Turn the plate and hard disk over carefully 3 hard disks. User can choose the position and secure the hard disk on the plate.
- Page 11 Screw tight the plate within hard disk Plug the power cable into hard disk inside the DVR unit Plug the SATA cable into SATA connector 10. Plug another side of SATA cable into hard on the PC board disk 11. Screw the holder 12.
-
Page 12: Seb5108 Lite
B. Device Connection SEB5108 Lite – All connected devices have their own power supply are necessary. – Pen drive and external hard disk must be FAT32 format. -
Page 13: Seb5116 Lite
SEB5116 Lite – All connected devices have their own power supply are necessary. – Pen drive and external hard disk must be FAT32 format. -
Page 14: Seb5116
SEB5116 – All connected devices have their own power supply are necessary. – Pen drive and external hard disk must be FAT32 format. -
Page 15: Fist Time To Use Dvr System
Fist Time to Use DVR System Connect the cameras Connect the mouse to DVR unit(through USB port on front panel) Power on the DVR unit. The preset screen (color bar) will show up and wait for preview screen to display (about 60 seconds). - Page 16 b. Click System → System and click Next. c. Click Refresh button to detect the installed hard disk. d. Select the hard disk that user wants to format it. e. And then, click Format to start formatting. Setup the date and time in order to have correct system time and date. Following the below steps to setup date and time: a.
- Page 17 Setup the Schedule to record. a. Click → Setting → Schedule → System b. Select the date and type of record (Weekly, Month, or None). c. And then, select the week day (Sun. ~ Sat.) and hours (00 ~ 23) by click the week day and hours table.
-
Page 18: Using The Virtual Keyboard
g. And then, select the week day (Sun. ~ Sat.) and hours (00 ~ 23) by click the week day and hours table. a. Click Save and OK to complete the record schedule setting. To start recording, click (record) button. Using the Virtual Keyboard Use the Virtual Keyboard and mouse to configure the DVR system. -
Page 19: Familiarizing The Buttons In Preview Mode
Familiarizing the Buttons in Preview Mode (SEB5116 series) Name Function (1) Login Click to select reboot the DVR system or re-login in different account. (2) Status Display recording date and time (3) Hard disk capacity Display the hard disk usage of capacity (4) Record Start/stop video recording. -
Page 20: To Playback The Recorded File
To Playback the Recorded File To switch in Playback mode, click (Playback) button at the bottom right corner of Preview mode user interface. And then, select the date, hour, and minute that user wants to playback from Calendar Search. Click OK to start playback. -
Page 21: Familiarizing The Buttons In Playback Mode
Familiarizing the Buttons in Playback Mode (SEB5116 series) Name Function (1) Status Display the recorded date, time and playback speed. ı : Move at the beginning of the recorded video file. (2) Playback Control ı: Go back to the previous frame. Buttons : Play the recorded video file at the speed of 1/2X, 1/4X, 1/8X, or 1/16X. -
Page 22: Playback Backup Video
Playback Backup Video You can playback the backup files and output video segment by using QPlayer applications on the PC. When you back up the recorded file, QPlayer applications are automatically included in the backup folder. With QPlayer, it is the same as in Playback mode and supports 6 different split screen types to view all the video at the same time. - Page 23 Name Function (3) Hour Buttons Select and click to playback the recorded video file on the specific time frame. The Hour buttons represent the time in 24-hour clock. The blue bar on top of the hour button indicates that there is a recorded video file on that period of time. While the red bar indicates that you are currently viewing the recorded video file.
- Page 24 Name Function Keep a portion of the recorded video. (11) Segment Following the below steps to Cut and Save the Wanted Portion of the Recorded Video 1. Use the Playback Control buttons or drag the bar on the playback progress bar and pause on where you want to start the cut. Then, click Segment to set the begin mark.
-
Page 25: Using The Remote Programs
Using the Remote Programs User can use Microsoft Internet Explorer to access DVR system by entering the IP address. To use this feature, make sure that your PC and DVR server both are connected to the internet and the Network feature is enabled. Accessing this feature for the first time you will be prompted by your browser to install WebCamX.cab, allow the installation and you should be able to connect and login afterwards. -
Page 27: Familiarizing The Webviewer Buttons
Familiarizing the WebViewer Buttons Right-clicking on the WebViewer video screen, enables you to start video recording, change video quality, switch camera and enable/disable DirectDraw. Name Function Enhance the video quality. (1) DirectDraw Not all graphic cards can support this function. If you can not see the screen display correctly or screen is messed, please check with VGA card vendor. - Page 28 Name Function Change the DVR server settings (9) Remote setup Initiate PTZ camera controller (10) PTZ Control Capture and save the screen shot in *.bmp format. (11) Snapshot Use the entire area of the screen to only display the video. (12) Full screen To return, Right-click or press ESC on the keyboard.
- Page 29 P/N: 300AC2A9-C55 March. 2009...
