Summary of Contents for Sartorius Signum: Option Y2 SIWR
- Page 1 Installation Instructions and Safety Information Sartorius Signum: Option Y2 Models: SIWR | SIWA | SIWS Complete Scales for Use in Zone 2 and 22 Hazardous Areas 98648-016-49...
-
Page 2: Table Of Contents
Contents English General View of the Equipment ..2 In cases involving questions of Intended Use ....3 Warnings and Safety Information . . . 3 interpretation, the German-language version shall prevail. -
Page 3: Warnings And Safety Information
Sartorius. port when not in use, or prior to ship- ment. This will protect the data interface or from vapors, moisture and dust or dirt. -
Page 4: Installation Instructions
Installation Instructions Setting up the Scale Choose a suitable location where your scale will not be exposed to drafts, heat radiation, moisture or vibrations. Use a spirit level when adjusting the °C weighing platform. Make sure to read these operat- ing instructions carefully before connecting the scale to power. -
Page 5: Getting Started
Getting Started § Use the connecting cable from the weighing platform to connect the display and control unit. Note: The cable gland is installed at the factory. Please use extreme caution when performing any work on the equipment that affects this cable gland. Use a torque wrench and tighten the cable gland to 5 Nm. -
Page 6: Ground (Earth)
If the voltage specified on the label does not match the rating or standard you use, please contact your local Sartorius office or dealer. Make sure to observe the safety instructions. § Connect the equipment to AC power. -
Page 7: Care And Maintenance
It is a good idea to save the nearest Sartorius Service Center or the box and all parts of the packaging for International Technical Support Unit future storage or shipment of the based in Goettingen, Germany. -
Page 8: Recycling
Sartorius AG will not take back equip- equipment on its own. ment contaminated with hazardous materials (ABC contamination) – either In countries that are not members for repair or disposal. -
Page 12: Safety Instructions
Non-hazardous area Zone 2 or zone 22 hazardous area Gas group IIC, temperature class T4 Dust: surface temperature ma x. 80°C Ambient temperature: -10°C to +40°C 1. Power connection Use EX plug Plug provided with standard equipment Alternative connections Secure plug (standard equipment supplied) s o that it cannot become accidently disconnected. - Page 13 3. Connecting analog weigh cells for reference scale (Option A15) Non-hazardous Zone 2 or zone 22 hazardous area area Gas group IIC, temperature class T4 Dust: surface temperature ma x. 80°C Ambient temperature: -10°C to +40°C Complete scale SIW..-.-..-... with Option Y2 and A/D converter output with bridge supply voltage...
- Page 14 These safety instructions apply to the installation, operation, maintenance and repair of the equipment The equipment may be used zone 2 and 22 hazardous areas. In zone 22, the device is approved for use only in the presence of non-conductive dusts. The permissible ambient temperature is –10°C to +40°C (14°F to 104°F).
- Page 15 To use non-Sartorius equipment in Zone 2, be sure they have the appropriate gas and temperature classes; for Zone 22, make sure they do not exceed the maximum surface temperature. The outputs must have Ex nA electrical circuits.
- Page 16 Sartorius AG Weender Landstrasse 94–108 37075 Goettingen, Germany Phone +49.551.308.0 Fax +49.551.308.3289 www.sartorius-mechatronics.com Copyright by Sartorius AG, Goettingen, Germany. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior written permission of Sartorius AG.
