8. With the help of a second person, hold the con-
sole assembly near the right Handrail (84) and
the left Handrail (not shown).
See the inset drawing. Connect the Upright
Wire (81) to the console wire. The connectors
should slide together easily and snap into
place. If they do not, turn one connector and try
again. IF YOU DO NOT CONNECT THE CON-
NECTORS PROPERLY, THE CONSOLE MAY
BECOME DAMAGED WHEN YOU TURN ON
THE POWER. Then, remove the wire tie from
the Upright Wire.
9. Set the console assembly on the Handrails (84).
Make sure that no wires are pinched. Insert
the excess Upright Wire (81) into the Right
Upright (90).
Attach the console assembly to the brackets
on the Handrails (84) with the four 1/4" x 1/2"
Screws (2) that you removed in step 7 and four
1/4" Star Washers (26). Do not tighten the
Screws yet.
8
Console
Assembly
Console
Wire
84
9
Console Assembly
84
81
26
2
90
11
81
Console
Wire
Wire
Tie
81
26
2
84
