- Page 1 IST 03 F 012 - 01 INSTALLATION AND MAINTENANCE MANUAL Desertus FA_ Savan FA_ Electrified aluminium radiator with heat transfer fluid...
-
Page 2: Table Of Contents
Dear customer: Thank you for choosing our product. Read this manual carefully before installing your radiator, as it provides useful information for installation, use and proper maintenance of the appliance. Remember that this manual must accompany the radiator should it be moved to a different installation location. THIS PACKAGE INCLUDES: Aluminium radiator equipped with a thermostat with electronic regulation, kit made up of three mounting brackets with wall plugs, instruction manual. -
Page 3: Characteristics
On the left-hand side there is a receptacle for water used to humidify the environment (see picture). NB: All Fondital radiators are supplied fitted with an identifying label which guarantees their traceability. This label certifies that the appliance complies with European directives and electrical standards. -
Page 4: Warnings
3. WARNINGS There is a label on the side of the radiator which contains the symbol shown on the left. The meaning of this symbol is: In order to avoid overheating the appliance, DO NOT COVER THE RADIATOR with clothing, pieces of cloth or other objects. The radiator must never be: - partially or totally covered;... - Page 5 4.1 Mounting the radiator on a wall The radiator can be mounted on a wall using the mounting brackets included with the appliance. The mounting system consists of: White White M6x50 RAL9010 ø When mounting the appliance, follow the steps illustrated below: 15 mm ø...
- Page 6 max 70 kg max 70 kg max 140 kg...
-
Page 7: Electrical Connections
The step shown in illustration 9 can only be considered finished when the lower screw has been completely tightened and the radiator is firmly attached to the wall, with no possible movement. Recommended installation dimensions (in mm): 190÷220 Number of sections Dimension A Dimension B Dimension C... -
Page 8: Regulation And Programming
DETAILS OF BATHROOM INSTALLATION The appliance must be installed according to current regulations and laws in force in the country of use. The radiator is class II and has IPX4 electrical protection. In bathrooms, it can be installed in areas 2 and 3 (see figure 1) on condition that the control device is not within reach of people using the shower or bathtub. - Page 9 Comfort Mode This function allows the user to regulate the room temperature. This is the normal mode for using the radiator to keep the room temperature at the programmed level. The programmed temperature depends on the position of the temperature control. As an indication, the programmed temperature and the numbers shown on the control correspond to the values shown in pic.
-
Page 10: Cleaning The Radiator
7. CLEANING THE RADIATOR For safety reasons, disconnect the power supply before cleaning the appliance. Cleaning must be done when the radiator is turned off and is cold. Do not use abrasive or corrosive products to clean the heating appliance: use soapy water, for example and dry the body with a soft cloth. Clean plastic parts, controls and the humidifier with a dry cloth only and avoid contact with chemicals or alcohol. -
Page 11: Declaration Of Conformity
RADIATORS Models Desertus FD_ ; Savan FD_ manufactured by FONDITAL S.p.A. are manufactured in accordance with European directives. - DIRECTIVE 2006/95/EC of 12 December 2006 on the harmonisation of the laws of Member States relating to Electrical Equipment designed for use within certain voltage limits (low voltage) DIRECTIVE 2004/108/EC, for electromagnetic compatibility. - Page 12 Tel. +39 0365/878.31 - Fax. +39 0365/878.576 e mail: fondital@fondital.it - www.fondital.it The manufacturer reserves the right to modify the products as it deems necessary and useful, without affecting their basic features. Uff. Pubblicità Fondital IST 03 F 012 - 01 Settempre 2009 (09/2009)
