CAMERA INSTALLATION + SETUP

CAMERA MOUNTING

1 Secure the multi-position 2
camera stand to a stable
surface, ceiling or wall.
NOTE: Cameras are IP66 rated for indoor/outdoor use. For outdoor use it is recommended to install
camera under shelter to protect from direct exposure to sunlight and other environmental elements. Avoid
pointing a camera directly at any bushes or tree branches or objects that may naturally move due to winds.
SMART DEVICE SETUP
From your smart device, DOWNLOAD and
1
INSTALL the free ALC SightHD App.
2
Plug camera into an electrical outlet (allow the
camera up to 60 seconds to boot up).
3 Tap ADD camera on screen for direct wireless
connection of camera to App.
4
Smart device will scan and detect camera. Once found,
the screen will show a LIVE VIEW brie y before moving on
to a set up screen.
5
Enter a NAME for your camera and provide a PASSWORD;
the DID code from your system is automatically detected
and automatically lled.
6
Tap Wi-Fi SETTING to proceed to the next step.
Select your local Wi-Fi network and enter your Network
7
password to complete the connection.
NOTE: Screen shots and icons may vary due to continuous updates to App and software development.
LIVE VIEW RECORDING
on microSD CARD*
1
Lift cover and insert a microSD card into
the rear of camera.
microSD Card Slot*
*microSD card (not included) is
required to record video to camera.
2
Manually RECORD video from Live View by
tapping Record icon. Recording will stop
after 1 minute.

Motion Recording

To set MOTION ACTIVATED RECORDING,
Go to Advanced Features in App >
SENSITIVITY SETTINGS to select options.
NOTE: Do not submerge in water, monitor near water. STRANGULATION HAZARD: Infants have STRANGLED in power cords.
Keep power cords more than 3 feet away from cribs. When using your equipment, always follow basic safety precautions to reduce
the risk of re, electric shock and injury to persons. Illustrations are for reference only. Actual product speci cations may vary.
For additional precautions and product information, please see owner's manual at www.atomslabs.com/support
Loosen the T-Bolt on the camera 3 Align hole on bottom of camera
stand and adjust viewing angle using with T-Bolt to install camera.
the Thumb Screw to rotate position. Screw antenna into rear of camera.
REMOTE VIEWING
Camera 2
SightHD
FREE APP DOWNLOAD
PLAYBACK
1
Tap CAMERA SETTING icon
2
Select the TIME INTERVAL for the event list.
3
Tap the FILE that you want to playback from the list.
Select event lter
4 Plug into electric outlet when
ready to install App (Step 2 in
REMOTE VIEWING section).
Camera 2
ASAU-xxxx-xxxx-xxxx
******
and then EVENT LIST icon
Camera 2 (Live Video)
Connected
1280x720
P2P, N=1, 15.00FPS
For detailed installation and setup, please refer to the
Model AWF51 complete User's Guide available on our website:
www.atomslabs.com/support
Surface Mount
Recommendations for
best system performance:
• iOS 6.0 or above.
• Android: 1.5G dual core processor or
above / 960x540 pixel or above.
• Storage: Class 10 microSD memory card
(up to 32 GB).
• Bandwidth: 1Mbps or above
upload/download speed suggested.
LIVE VIEWING

LIVE VIEW

Camera 2 (Live Video)
1
Tap preview PICTURE
Connected
1280x720
P2P, N=1, 15.00FPS

SNAP SHOT

Tap to CAPTURE screen images in
Live View. Images automatically
save to smartphone's camera roll
or gallery.
Tap to RECORD. One-minute recordings
save to microSD card slot on the rear of
camera, see diagram page for location
(microSD card not included).
ADVANCED FEATURES
SETTINGS
Camera 2 (Live Video)
Connected
Wireless
Made Simple.
AtomsLabs.com
Tap to turn volume ON/OFF
in the in Live View mode.
Tap to RETURN to the
main page.
Tap SETTINGs icon to see
Advanced Feature options
• Sensitivity Setting
(Motion Recording)
• Email Setting
• SDCard Setting
• Recording Setting
SCAN
TO VIEW
COMPLETE
USER'S GUIDE
