INNO VIEW 5 User Manual page 49

Fiber Axis Align Failed
Fiber is Dirty
Fat Splicing Point
Thin Splicing Point
Appendix II
Too large axial offset (>4.0㎛).
The motor is not calibrated.
Dust or dirt on the fiber surface.
The lenses are covered with dust.
[Clean Arc Time] is too short.
It is difficult to identify the fiber
core by using the method of core
alignment to splice.
[Overlap] is too much.
The motor is not calibrated.
Arc power is too low.
The level of pre-discharge is
too high.
Insufficient [Overlap].
Re-prepare the fibers.
Perform [Motor calibration].
Prepare the fiber again.
Perform [Dust check] after
cleaning the lenses.
Set [Clean Arc Time] to 180ms.
Use MM splice mode (clad align-
ment) to splice the unidentified
fiber core.
Adjust [Overlap] parameter.
Perform [Motor Calibration].
Perform [Arc Calibration].
Decrease pre-discharge or pre-
discharge time.
Adjust [Overlap] parameter.
48
