Appendix II
List of error messages
During the splice operating process, if the error messages are shown on the
screen, please follow the solution precisely as shown in the list below. If it is not
possible to solve the problem, the splicer may require service by a qualified service
center. In this case, please contact sales agents.
Error Message
Left Fiber Place Error
Right Fiber Place Error
Press Motor Distance
Over Limit
Press Motor Error
Search Fiber Endface
Failed
Arc Failure
Align Motor Distance
Over Limit
Search Fiber Clad Failed
Fiber Border Position
Wrong
Reason
The fiber endface is placed
beyond the electrode centerline.
The fiber is not set correctly at the
bottom of the V-groove, which
results in that the fiber offsets
beyond motor formation range.
The motor might be damaged.
The fiber is not set correctly at
the bottom of the V-groove.
Arc discharge does not occur.
The fiber is not set correctly at
the bottom of the V-groove.
The fiber is not set correctly at
the bottom of the V-groove.
Dust on the fiber surface.
Solution
Press RESET button, and reload
the fibers to make sure that
fiber endface is placed between
V-groove and the centerline of
electrodes.
Press RESET button, and
reposition the fiber at the bottom
of the V-groove.
Consult your nearest sales agent.
Press RESET button, and
reposition the fiber at the bottom
of the V-groove.
Confirm the electrodes in
the proper position; replace
electrodes.
Press RESET button, and
reposition the fiber at the bottom
of the V-groove.
Press RESET button, and
reposition the fiber at the bottom
of the V-groove.
Re-prepare the fiber; clean the
lens; redo [Dust Check].
