Select the parameters to be edited.
Deleting heat mode
Select [Heater Mode] menu.
•
Select [Delete Heat Mode].
•
Select the heat mode to be deleted.
•
Note: The gray modes (20mm, 30mm) are the system preset initial heat modes
which cannot be deleted.
Heat mode parameters
Parameter
Template
Name
Note
Heater
Control
Heat Temperature
Heater Time
Cooling Time
Chapter 6 Heater Mode
Set sleeve type. List of all heat modes are displayed. Selected mode will be
copied to a user-programmable area.
Title for a heat mode.
Title of the heat mode displayed in the upper right corner of the monitor
during splicing or heating process. Max number of character used is 5.
Set the length of heat-shrink sleeve.
Long: protection sleeves over 30mm.
Short: 30mm protection sleeves or below.
Set heating temperature.
Set heating time from the beginning to the heating completed.
Operating time of cooling fan.
Description
34
