Controls

Right click the mouse anywhere on screen to activate the control menu selections.
Selecting main menu will automatically show the SYSTEM LOGIN screen. The default
settings are
User Name:
Password:
Once logged in you may now right click again to access your menu selections. An
opportunity to change the password is provided within the settings menu. Please note
if an incorrect password is entered three times the DVR alarm will activate. If a wrong
password is entered five times the system will lock out. To reset the system turn the
main power off and back on after 5 minutes.
SHORTCUT MENU
Selecting main menu will take you through to the shortcut menu where most regularly
used settings can be found. Explanations of functions are displayed by hovering the
mouse over each icon.
Record
Alarm
System
Advanced
Info

Making a recording

RECORD CONFIGURATION
This section allows you to configure the recording capability of the DVR to your precise
requirements by each channel / camera.
Channel
Redundancy Select if double ( backup ) recording is required when two hard drives are
Length
Pre-Record
Mode
SCHEDULE RECORDING
Week
Period 1-4
Regular
Detect
Alarm
29/7/11
Admin
leave blank
Record set up / record playback / record back up
Motion detection and alarm event settings
Time and date / network settings / on-screen display settings
Hard disk management / password settings / network settings
Hard Drive status / system usage log / version details
Select 1–4 (all other settings now effect the specific channel selected)
fitted
The record time captured when using motion or alarm trigger detection
The system can automatically archive up to 30 seconds of recording prior
to a motion or alarm trigger
Selects the recording preference either by schedule or to stop and start
recording manually
You now have the ability to specify the recording requirements by each
day ( select all if all days are the same )
Each day can be segmented into 4 specific recording periods
Simply records constantly within the selected period
Only records by motion detection within the selected period
Only records by alarm trigger within the selected period
