ESP DigiView 8i User Manual page 12

F248 Digiview8i Manual:Layout 2
LOCAL NETWORK VIEWING - INTERNET EXPLORER
After connecting your DVR to the network, your PC 'Web browser' (internet explorer) can
be used for local or remote viewing.
Step 1
The first time you connect to the DVR from a new PC a security warning message will
pop-up asking whether you accept "web.cab" file. You must to accept in order to be able
to access your DVR.
(If the ''web.cab'' file pop-up fails to show or download, please reduce IE security level or
disable third party pop-up blockers and try again)
Note: If this is the first time you have connected to your DVR from this PC it will
take 4-5 minutes to load
Step 2
Note: You may use this method for future Local network viewing of your DVR.
BASIC WEB OPERATION – CONTROL PANEL BUTTONS
Split
Choose how many camera images you wish to display. For 4 channel DVRs choose 'view
4' or for 8 channel DVRs choose 'view 8' etc.
Playback
Enters playback mode; used for searching and playing back recordings already stored on
the DVR.
Log
Display event log information, if any.
Local Cfg
Operate alarm set up on the web end.
Device Cfg
Right click mouse and select 'Device Cfg'. You can now adjust most of the DVRs Config
settings as if you were at the DVR in person.
DISPLAYS LIST OF AVAILABLE CAMERAS
PTZ controls
Only suitable for PTZ cameras.
Picture adjustment controls
Such as Colour, Contrast etc.
12
29/7/11
Open web browser on a local PC (same premises as DVR), then enter the
DVRs IP address and 'HTTP port' into the address bar. For example, the
IP address of the DVR is 10.10.10.105, and 'HTTP port' number is 5557
then you should enter http://10.10.10.105:5557 on the address bar to
connect.
Login; enter user's name and password, the default Administrator User ID
is admin, and the password is empty (no password).
13:58 Page 12
