Rear Panel
3
5
No. interface
1 VIDEO IN
2 GND
3 VIDEO OUT
4 AUDIO-IN
5 AUDIO-OUT
6 OFF/ON
7 NET/LAN
8 RS485
9 DC-12V
10 VGA
11 USB
12 ALARM
NB. To obtain best quality on screen display It is highly recommended to connect
a monitor via the VGA output using a quality VGA lead.
Alarm input and output connections
1
29/7/11
1 4
ID Description
Video input BNC connectors x 8
Ground column
Video output BNC
Audio in
Audio out
Power switch
Network Interface
RS485 Interface
12V Power Input from power supply
VGA display output
USB interface for back up or mouse control
Alarm input and output interface (see Alarm Interface specific description)
8-Channel Alarm Terminal
1
2
3
4
2 3
4
5
5
NB. Output port is normally open
13:58 Page 5
2
11
7
10
Alarm input 1– 8
GND
232 termination
Alarm Output
RS485 Interface
6
12
8
9
5
