Iberital 2 Groups Instruction And Operation Manual

Espresso coffee maker electronic/semiautomatic series
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTION
AND OPERATION
MANUAL
ESPRESSO COFFEE MACHINE
ELECTRONIC / SEMIAUTOMATIC SERIES: 2 / 3 GROUPS
IBERITAL DE RECAMBIOS, S.A.
RIERA BLANCA, 49 08028 BARCELONA (SPAIN)
Tel. 34 93 632 64 55
Fax 34 93 632 71 33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2 Groups and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Iberital 2 Groups

Summary of Contents for Iberital 2 Groups

  • Page 1 INSTRUCTION AND OPERATION MANUAL ESPRESSO COFFEE MACHINE ELECTRONIC / SEMIAUTOMATIC SERIES: 2 / 3 GROUPS IBERITAL DE RECAMBIOS, S.A. RIERA BLANCA, 49 08028 BARCELONA (SPAIN) Tel. 34 93 632 64 55 Fax 34 93 632 71 33...

  • Page 3: Table Of Contents

    IBERITAL DE RECAMBIOS, S.A. TABLE OF CONTENTS IMPORTANT INDICATIONS 1.- INSTRUCTIONS FOR THE USER (TURN ON) 1.1.- Description 1.2.- Preparation. Turn on 1.3.- Programming the dose 1.4.- Hot water output 1.5.- Steam output 1.6.- Daily cleaning operations 1.7.- Water softener 1.8.- Display operation (optional)
  • Page 4 The installation of the appliance must respect the local safety standards in force and must be carried out, following the manufacturer's instructions, by technically qualified persons authorized by IBERITAL DE RECAMBIOS, S.A. The manufacturer accepts no responsibility for situations caused by or arising from the incorrect installation of this appliance.
  • Page 5 8) In case any anomalies or irregular running, switch off the machine to attempt personal maintenance operations. Contact a technically qualified person authorized by IBERITAL. Any eventual repair work should be carried out by the manufacturer or by an authorized after sales service center using original spare parts.
  • Page 6 11) The power cable must not be replaced by the user, if damage to the cable is noticed, disconnect the machine from the mains and contact a technically qualified person authorized by IBERITAL. 12) Whenever the machine is not to be used for extended periods make sure it is disconnected from the mains.
  • Page 7 455 mm 783 mm 3 Groups 568 mm 455 mm 953 mm Important: Specifications are subject to change without notice. Contact the nearest IBERITAL representative for any question related to the new specifications. Página 5 de 30 MANUAL NEW IBERITALINGLES 11/05/2007...

  • Page 8: Instructions For The User (Turn On)

    IBERITAL DE RECAMBIOS, S.A. 1.- INSTRUCTIONS FOR THE USER (TURN ON) 1.1.- DESCRIPTION 1) Coffee feed control buttons CPU 14) ON/OFF red light 2) Feed button, one espresso coffee 15) Element working. Green light 3) Feed button, two espresso coffees...

  • Page 9: Preparation. Turn On

    IBERITAL DE RECAMBIOS, S.A. 1.2.- PREPARATION - TURN ON a) Turn on the water stopcock (20) at the mains. b) Switch on the power at the mains (12). c) Turn the switch (13) to the position 1 and wait for the automatic water level control to finish filling up the boiler.
  • Page 10 IBERITAL DE RECAMBIOS, S.A. In the position 2, it is possible to do coffees (erogations). But it is recommended to begin doing coffees (erogations) when the machine is warm. II. ADJUSTING THE TOUCH PATH DOSING. Press the continuous button of the right hand group (group 1) during 5 seconds and the continuous LED will light on.
  • Page 11 Please check the volumetric counter, in case there would be any dust from the water supply. III. ADJUSTMENT OF THE ELECTRONIC PRE-INFUSION (FOR THE IBERITAL WITHOUT DISPLAY MODEL ONLY) The pre-infusion can be enable and disable, as follows: To enable this function:...

  • Page 12: Hot Water Output

    IBERITAL DE RECAMBIOS, S.A. • Failure in the volumetric counter (5 seconds) The LED of the erogation being used (1 short coffee, 2 long coffee ...) is winking due to some failure in the volumetric counter. At the same time, this erogation does not stop.

  • Page 13: Daily Cleaning Operations

    IBERITAL DE RECAMBIOS, S.A. 1.6.- DAILY CLEANING OPERATIONS Cleaning the spray filters Every evening or at least once a day it is necessary to carry out the following: Rinse the filters and filter bowls in hot water every evening or at least once during the day. Further still allow them to soak overnight in water which is initially hot in order to dissolve the fat deposited by the coffee.

  • Page 14: Water Softener

    IBERITAL DE RECAMBIOS, S.A. 1.7.- WATER SOFTENER The water softener eliminates calcium from the water therefore preventing the build up of inlays. The water softener degenerates through use and must be regenerated. Regeneration is the procedure which returns them to the original state. The presence of inlays in the boiler, through lack of regeneration, will nullify all guarantees in force.

  • Page 15: Clock Adjust

    IBERITAL DE RECAMBIOS, S.A. Clock adjust Hour HH.MM.xxxxxxx Minutes xxxxxxx: Week day buttons to adjust HOUR and confirm with the OK button, then adjust the Press the MINUTES and the DAY. After confirming the DAY, you will enter automatically in the...
  • Page 16 IBERITAL DE RECAMBIOS, S.A. Showing the number of cycles until now (total pushing dosing selections made). Press the MENU button and the display will show: Total coffees xxxxxx Showing the total number of coffees made until now. Press the MENU button and the display will show: zzzzz: 1 espresso, 1 coffee, etc.
  • Page 17 IBERITAL DE RECAMBIOS, S.A. And the display will show: lavage Following the machine will proceed 7 times this cycle: o 15 seconds brewing o 2 seconds stand-by At the end of the “WASHING CYCLE” the machine will come back to the beginning MENU.
  • Page 18 IBERITAL DE RECAMBIOS, S.A. The display will show the “Name 2” (lower line of the display) where you will begin in the 1 position of the line (Line length: 16 characters). Press the buttons to select any of the characters (black space, !, “, #, $, %, &, etc.) and press the OK button to confirm that character, and passing to the following line position.

  • Page 19: Service Phone

    IBERITAL DE RECAMBIOS, S.A. Where you can program the “Name 2” (lower line of the display) in the same way as described for “Name 2”. Once you have finished all the line positions, press the MENU button and pass to the following...
  • Page 20 IBERITAL DE RECAMBIOS, S.A. The display will show the “DOSES SETTING”. If you select ENABLE you will be able to program dosing in any option (1 short coffee – espresso, 1 log coffee, etc). If you select DISABLE, you will not be able to program dosing, and you will have always the same settings.
  • Page 21 IBERITAL DE RECAMBIOS, S.A. The display will show the “PREBREWING” (pre-infusion) option. Pres buttons t to DISABLE or ENABLE this option. If you select “ENABLE”, press the MENU button. The display will show: Pre-brew. 1 espresso xxxx The display will show the “PRE-INFUSION ON” time for any dosing selections (1 espresso, 1 coffee, etc.).

  • Page 22: Water Filter

    IBERITAL DE RECAMBIOS, S.A. The display will show the “SERVICE CYCLES” option. Press to select the number of cycles (number of times that you have pushed a dosing button). Once you have finished this procedure, press MENU button to pass to the following option:...
  • Page 23 TURN ON (position 1). B. EXCEEDING BOILER TEMPERATURE. (NO available for the IBERITAL Model with pressure boiler control by “Pressure Switch”). The display will show the temperature alarm of the boiler when this temperature will pass over 140ºC during more than 5 seconds.
  • Page 24 IBERITAL DE RECAMBIOS, S.A. C. TEMPERATURE PROBE CUT-OFF. When this probe notices a temperature of 0ºC during 5 seconds, the LEDS of the dosing buttons will wink and the display will show: T. probe / unconnect This alarm will disappear when the boiler temperature will come back to normal value.
  • Page 25 IBERITAL DE RECAMBIOS, S.A. Following the display will show: Filter reset F. MAINTENANCE ALARM. When the display shows: Service xxxxxxx xxxxxxx will show the “SERVICE PHONE” (selected in the TECHNICAL’S MENU), pointing out that we have exceeded the number of service cycles selected in the TECHNICAL’S MENU option.
  • Page 26 IBERITAL DE RECAMBIOS, S.A. Total coffees In order to erase to ZERO “0” value, press the “2 long coffees” and the “2short coffees” at the same time in the GROUP 1 (left hand group), following the display will show: Total cafés Total reset WARNING: The individual counter for each dose (1 short coffee- espresso, 1 long coffee, etc.)

  • Page 27: Instructions For The Technician

    NSF silicone. 2.1.- DESCRIPTION OF THE INTERNAL COMPONENTS 29) Pump 30) Boiler 2 groups 14 liters 3 groups 20 liters 31) Spring loaded safety valve 32) Pressure eliminating valve (Empty valve)

  • Page 28: Electrical Connection

    IBERITAL DE RECAMBIOS, S.A. 2.3.- ELECTRICAL CONNECTION IMPORTANT: This equipment is to be permanently cord connected. The machine is fitted with heating and other electric elements of either 110V, 220V or 240V depending on the version. A circuit breaker, with an adequately rated fuse, must be fitted between the appliance and the mains.
  • Page 29 IBERITAL DE RECAMBIOS, S.A. 380V THREEE PHASE WITH NEUTRAL (TWO AND THREE GROUPS MACHINES) The machine can be connected in three phases 380V with neutral. In this case the black wire and the Red wire must be connected to one of the three phases, and the White wire to the neutral wire. The green conductor/wire must be connected to ground.

  • Page 30: Feed Unit

    IBERITAL DE RECAMBIOS, S.A. 2.4.- FEED UNIT GROUP. 44) Gasket 46) Spray head 47) Water drainage system 49) Solenoid valve The feed unit consists of a hot press brass block in which the infusion chamber has been set. Pressing the coffee feed button turns on the pump (29) and activates the solenoid valve (49).

  • Page 31: Spring Loaded Safety Valve

    IBERITAL DE RECAMBIOS, S.A. 2.5.1.- SPRING LOADED SAFETY VALVE In the case of anomalies in the heating control pressure system the spring loaded safety valve (31), located on the boiler guarantees the integrity of the boiler by releasing the excess pressure when the boiler reaches 1.8 bar.

  • Page 32: Product Certifications

    Directive 73/23/EEC and 93/68/EEC. (Electric Safety). Under demand, IBERITAL DE RECAMBIOS, S.A. may supply equipments conforming other standards. CAUTION: Changes or modifications to the equipment not expressly approved by IBERITAL DE RECAMBIOS, S.A., could result in violation of the product certifications. Product marks.
  • Page 33 Esta declaración quedará sin efecto en caso de que se realice cualquier tipo de modificación del aparato que no haya sido explícitamente autorizada por la empresa. This declaration shall not apply to machines modified without IBERITAL approval. Marcas comerciales: “IBERITAL”...
