PITTS 30CC V2
ASSEMBLY MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PITTS 30CC V2 and is the answer not in the manual?

Questions and answers

Related Manuals for arf PITTS 30CC V2

Summary of Contents for arf PITTS 30CC V2

  • Page 1 PITTS 30CC V2 ASSEMBLY MANUAL...

  • Page 2: Introduction

    By the act of using the final assembled model, the purchaser/operator accepts all resulting liability. ARF MODELS WARRANTY AND RETURN POLICY We guarantee that the plane is in perfect condition at purchase. The warranty will be voided after modifications and usages. If you have any questions or find any issues, please contact the distributors in your area.

  • Page 3: Features

    Features: 01.Newly designed structure 02.Two pieces removable wings 03.PVC canopy 04.Carbon fiber wing tube 05.Larger aileron and elevator design for excellent 3D aerobatic flying. 06.Anodized aluminum Long servo arms included. 07.Servo extension safety connector clips. 08. igh performance cap head screws. 09.Flat nylon hinges for better flying strength.
  • Page 4 10.High quality ball link assemblys. 11.Dual Fiberglass horn assembly. 12.Carbon fiber tail wheel assembly. 13.High-quality durable rubber wheels. 14.Two options for landing gear: Anodized 6061 Aluminum or Carbon fiber. Anodized 6061 Aluminum landing gear. Carbon fiber landing gear. 15.Canopy quick release mechanism.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Introduction -------------------------------------------------- ----- ------ ----- Features ------------------------------------------------------------------------ Wing Assembly----------------------------------------------------------------- Aileron Control Horns ---------------------------------------------------------- Aileron Servo Installation ------------------------------------------------------ Elevator Assembly ------------------------------------------------------------- Stab and Elevator Installation ------------------------------------------------ Elevator Servo Installation --------------------------------------------------- Rudder Assembly -------------------------------------------------------------- Rudder Horns and Hinges ------------------------------------------------------ Rudder Servo Installation ------------------------------------------------------ Tail Wheel Installation --------------------------------------------------------- Fin And Stab Cable Tensioning ---------------------------------------------...

  • Page 6: Wing Assembly

    Wing Assembly Aileron Control Horns 2.5mm bit 1 1 . 1 2 . 1.Scuff the horns with sand paper to ensure a good glue bond.Drill 2.5mm holes in the horns and install the M2. 5mm ball link with the screw. 2.Pre- hinged control surface...

  • Page 7: Aileron Servo Installation

    Aileron Servo Installation Minimum Required Servo:180 in.oz / Metal Gear / Digital 1.Use the provided safety clips to secure the servo and servo extension leads. 2.The covering of the servo location had been remove as shown.Put the end of the servo extension in the servo location.And then pull the extension l e a d t h r o u g h t o t h e r o o t o f t h e wing.Taping servo lead to the inside...
  • Page 8 5 . M o u n t t h e s e r v o a r m a n d t h e extension arm with M2*8mm screws and locking nuts as shown.Then turn on the transmitter and plug the servo into receiver.

  • Page 9: Elevator Assembly

    8.Apply 30 minute epoxy inside the other wing pre-cut slot and coat the wing batten with epoxy , Insert it into the pre-cut slot. 9. Coat the wing rib with epoxy ,put wing together. Wipe away excess glue with rubbing alcohol. 10.

  • Page 10: Stab And Elevator Installation

    Stab and Elevator Installtion 1.Insert the stab into the fuselage tail. Measure the stab to find the middle. 2 2 . 2 1 . 2. Mark the stab with a pen when the stab is symmerical. Trace around the fuselage with a knife and remove the covering below to expose the board.
  • Page 11 5 1 . 5 2 . 5. Install the two horns with M3*16mm screw and locking nut. Apply 30 minute epoxy inside the pre-cut slots and coat the horns with epoxy, Insert them into the pre-cut slots. . Insert the hinge into the elevator hinge-holes.

  • Page 12: Elevator Servo Installation

    Elevator Servo Installation Minimum Required Servo:180 in.oz / Metal Gear / Digital 1 1 . 1 2 . 1.Remove the covering below to expose the pre-cut sevro hole with a knife.Use the provided safety clips to secure the servo and servo extension leads.

  • Page 13: Rudder Assembly

    5.Turn on the transmitter. Make sure the servo is in the neutral position. Install the servo arm. Position the servo arm 90 degrees to the servo,and tighten the arm screw. 5mm latest nylon Anodized ball link assembly Long servo arm 110mm Black steel Pre- adjustable...

  • Page 14: Rudder Horns And Hinges

    Rudder Horns and Hinges 1 1 . 1 2 . 1.Trace around the fuselage with a knife and remove the covering below to expose the board. Take care not to scratch the board. 2.Remove the covering below to expose the pre-cut slots with a knife. 3.

  • Page 15: Rudder Servo Installation

    . Insert the hinge into the rudder hinge- holes. Stick the hinge to the rudder first . Insert the hinge into thehinge- holes. Use a drop of thick CA glue to stick the stab and elevator . . . 2 2 2 1 1 1 Rudder Servo Installation Minimum Required Servo:180 in.oz / Metal Gear / Digital 1.
  • Page 16 Double-sided tape 3.Drill 2.5mm holes in the AL long arm for installing 2.5mm ball links and 3mm bit screws.Drill 2mm holes in the servo arm and mount it with M2* 8mm screws and nuts. 2mm bit 1mm bit 4 1 . 4 2 .

  • Page 17: Tail Wheel Installation

    Pull - pull Connector Crimp Al anodized 5mm latest nylon ball link assembly Long servo arm Tail Wheel Installation .Install the carbon fiber tail wheel bracket with M5mm locking nut and M5 permanent seat AL screw. Grate 2 2 . 2 1 .
  • Page 18 Centerline 3. Draw a centerline on the fuselage tailwith a pen. 2mm bit M3*12mm tapping screw 4 1 . 4 2 . 4. Use the tail wheel bracket as a template and drill 2mm holes .Install the tail wheel bracket with three M3* 12mm tapping screws. 4mm bit 5 1 .

  • Page 19: Fin And Stab Cable Tensioning

    Fin And Stab Cable Tensioning 1 1 . 1 2 . 1.Find the hole mark on the fin and stab.Drill the 3MM holes. 2 1 . 2 2 . 2.Bend the metal plate with a pliers. 3 2 . 3 1 . 3 Check you have full elevator deflection before fasten the stab with cable.

  • Page 20: Main Landing Gear Installation

    Main Landing Gear Installation Landing Gear Installation Straight edge to Front of fuse 1 2 . 1 1 . . Install the landing gear in the pre NOTE: the correct edge in mounting drilled holes with the supplied M4*25mm hex socket screws. All screws should be secured with Blue Loctite.Don’t over tighten and crack the carbon fiber.

  • Page 21: Pants Installation

    Align axle screw with front of gear 3.Tighten the M8 locking nut against the landing gear strut.(for some planes) Pants Installation 1.Install the inner wheel collar on the axle. screw and tighten the wheel collar in place. Adjust wheel collars in or out until wheel turns freely. 2.And then install the wheel pant with two M2.

  • Page 22: Firewall Holes Assembly

    Firewall holes Assembly NOT INCLUDED 1.Do not use Blue Loctite on engine mounting screws until final assembly. The engine will need to be removed to fit the throttle pushrod and fuel line. 2 1 . 2 2 . 2. Tape a piece of 90*70mm paper to the side of the engine mounting with the double- sides tape.And stamp for the engine mounting on the paper with a pencil.

  • Page 23: Throttle Servo Installtion

    Throttle Servo Installation 1 1 . 1 2 . 1. Drill 1mm holes in the throttle servo mounting and epoxy it. 2 2 . 2 1 . 2.Mount servo mounting with M2*12mm tapping screws epoxy.Turn transmitter. And then install servo.Position the servo arm 90 degrees to the servo. 3 1 .

  • Page 24: Fuel Tank And Fuel Line Assembly

    Fuel Tank and Fuel line Assembly ..1 1 1 1 2 1.Fuel tube interface type has been originally marked. 2 1 . 2 2 . 2.The tank bottom and cabin connect to the tank places had originally sticky connected to the VELCRO tie.Untie the velcro and install the fuel line on the copper pipe.

  • Page 25: Ignition Module And Battery Assembly

    4 1 . 4 2 . 4. Drill a 6mm hole on the side of the fuselage.And then let 6mm pumping fuel line pass through the hole.Install the M5mm screw to seal the fuel line. 5 2 . 5 1 . .

  • Page 26: Cowling Installation

    4mm bit 2 1 . 2 2 . .Position the ignition module on the side of the engine mounting box and mark the location of the nylon tie holes as shown. Use a 4mm bit to drill the ignition module mounting holes. 3.Thread nylon tie through mounting h o l e s .
  • Page 27 1.Measure the distance between the fuselage and the ignition plug(and exhaust). 2.Measure the same distance on the cowling and mark it. EXTRA300LP Cowling 3 1 . 3 2 . 3. Use a rotary cutting tool and sanding drum to cut out the openings in the cowl.

  • Page 28: Wing Final Assembly

    5.Measure the distance of the blind nut on the cowling and mark it. 6 1 . 6 2 . 6. Drill two 4mm holes in place. And install the cowling with four M3*16mm screws with washers. Wing Final Assembly Φ20* 620mm carbon fiber tube .

  • Page 29: Canopy Assembly

    3 1 . 3 2 . 3.Install the AL wing bracing to the fuselage with M3*16 screws. 4 2 . 4 1 . 4.Install the upper wing with the wing bracing and locking nuts. Canopy Assembly New nylon bolt M3* 16mm 1 1 .

  • Page 30: Flight Preparation

    Flight Preparation C.G Location 1. Measure the CG from the leading edge of under wing is 13MM. 2. Adjust the battery location.The CG can be moved around to fit your personal taste. Symmetry Control Adjust the aircraft and make sure both sides are symmetrical.Like the diagram shown.So that the plane is ready for flight.

  • Page 31: Control Throws

    Control Throws Engine Debugging Trial run the engine to check its stability at high speed and low speed to ensure there are no problems with vibration on the model. Run the motor at high speed about 30 seconds.Check the engine and make sure the temperature is below the prescription of manufacturer.
