SPECIFICATION
Wingspan :
1,580mm.
Length
: 1,265 mm.
Weight
:
2.5kg.
Parts Listing required (not included).
Radio :
4 channels.
Servo :
5 servos.
Glow Engine : 46-55 cu.in. 2 stroke.
Instruction Manual book
Electric Motor: AXI 2826/10.
62.20 in.
Battery: 4-5 Cells-Li-Poly-14.8-18.5v- 5.000 mAh - 20 c .
49.81in.
Speed Control:
5.50lbs.
Propeller :
Recommended R.C: 4 channels with
60A.
13 x 6.
4-5 servos.
Made in Vietnam.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BH67 and is the answer not in the manual?

Questions and answers

Related Manuals for arf BH67

Summary of Contents for arf BH67

  • Page 1 Instruction Manual book SPECIFICATION Electric Motor: AXI 2826/10. Wingspan : 1,580mm. 62.20 in. Battery: 4-5 Cells-Li-Poly-14.8-18.5v- 5.000 mAh - 20 c . Length : 1,265 mm. 49.81in. Speed Control: 60A. Weight 2.5kg. 5.50lbs. Parts Listing required (not included). Propeller : 13 x 6.
  • Page 2 ANGEL- Instruction Manual ITEM CODE: BH67 This instruction manual is designed to help you build a great flying aeroplane. Please read this manual thoroughly before starting assembly of your ANGEL. Use the parts listing below to identify all parts. WARNING.

  • Page 3: Safety Precaution

    ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. SAFETY PRECAUTION. + This is not a toy + Be sure that no other flyers are using your radio frequency. + Do not smoke near fuel + Store fuel in a cool, dry place, away from children and pets.
  • Page 4 ANGEL- Instruction Manual ITEM CODE: BH67 3. Drill 1,5mm pilot holes through the block of wood for each of the four mounting screws provided with the servo. Install servo into ai- leron servo tray as same as picture below. C/A glue Bottom side 4.
  • Page 5 ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. 2 x 10 mm. Control horn of Aileron 1. Using a ruler & pen to draw a straight line as below picture. 2. Locate nylon control horn, nylon con- trol horn backplates . Bottom side Repeat the procedure for the other wing 3.

  • Page 6: Installing The Aileron Linkages

    ANGEL- Instruction Manual ITEM CODE: BH67 Aileron control horn. Bottom side INSTALLING THE AILERON LINKAGES. 1. Working with the aileron linkage for now, thread one clevis onto one of the threaded wires. M2 lock nut. Snap keeper. M2 clevis. Bottom side 2.

  • Page 7: Installing The Engine Mount

    ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. 4. Locate one nylon servo arm, and using wire cutters,remove all but one of the arms. Using a 2mm drill bit, enlarge the third hole out from the center of the arm to accommo- date the aileron pushrod wire.
  • Page 8 ANGEL- Instruction Manual ITEM CODE: BH67 Secure Tie wrap OPTION 2: ENGINE MOUNT. 4 x 25mm Tie wrap...
  • Page 9 ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. FUEL TANK. INSTALLING THE STOPPER ASSEMBLY 1. The stopper has been pre-assembled at the factory. 2. Using a modeling knife, cut one length of silicon fuel line (the length of silicon fuel line is...

  • Page 10: Installing The Engine

    ANGEL- Instruction Manual ITEM CODE: BH67 9. To secure the fuel tank in place, apply a bead of silicon sealer to the forward area of the tank, where it exits the fuselage behind the engine mounting box and to the rear of the tank at the forward bulkhead.

  • Page 11: Nose Gear Installation

    ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. Right side 3 x 20mm Right side Secure Right side NOSE GEAR INSTALLATION. Pushrod wire Steering arm. 4 x 30mm Installing steering arm as follow Remove covering Adjust the nose gear steering arm until the Right side arm is parallel with the fire wall.
  • Page 12 ANGEL- Instruction Manual ITEM CODE: BH67 Right side Left side COWLING. Steering arm 1. Slide the fiberglass cowl over the en- gine and line up the back edge of the cowl with the marks you made on the fuselage. Secure...

  • Page 13: Installing The Spinner

    ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. Left side INSTALLING THE SPINNER. Right side Install the spinner backplate, propeller and spinner cone. The spinner cone is held in 2. While keeping the back edge of the place using two 3mm x 12mm wood screws.

  • Page 14: Installing The Throttle Pushrod

    ANGEL- Instruction Manual ITEM CODE: BH67 1) Assemble and mounting the wheel pants as shown in the following pictures. Secure 3) A drop of C/A glue on the wheel collar screws will help keep them from coming lose during operation.
  • Page 15 ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. Throttle servo Secure C/A glue ELEVATOR INSTALLATION. SERVO INSTALLATION. 1. Install the rubber grommets and brass collets into the elevator servo. Test fit the servo into the servo tray. C/A glue 2. Mount the servo to the tray using the mounting screws provided with your radio sys- tem.
  • Page 16 ANGEL- Instruction Manual ITEM CODE: BH67 Mark line C/A glue Top side See pictures below: 1. Draw a center line onto the horizontal stabilizer. Then slide the horizontal into the fuselage. Mark line Bottom side 4. Remove the stabilizer. Using the lines...

  • Page 17: Elevator Control Horn Installation

    ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. ELEVATOR CONTROL HORN INSTALLATION. Elevator control horn install as same as the way of aileron control horn. Please see pic- tures below. 5. When you are sure that everything is Nilon control clasp. aligned correctly, mix up a generous amount of 30 minute epoxy.
  • Page 18 ANGEL- Instruction Manual ITEM CODE: BH67 Drill a hole 6 mm diameter Elevator Elevator pushrod pushrod Secure...

  • Page 19: Vertical Installation

    ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. Elevator servo VERTICAL INSTALLATION. Rudder servo install as same as method of elevator servo. See picture below: Bend and cut after C/A glue...
  • Page 20 ANGEL- Instruction Manual ITEM CODE: BH67 Remove covering C/A glue 2. Slide the rudder into the fuselage as same as picture below. C/A glue 3. Mark the shape of the vertical on the left and right side on the rudder using a felt-tip pen.

  • Page 21: Rudder Control Horn Installa- Tion

    ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. C/A glue 5. Put the vertical stabilizer back in RUDDER CONTROL HORN INSTALLA- place. Using a triangle, check to ensure TION. that the vertical stabilizer is aligned 90 de- Rudder control horn install as same as the gree to the horizontal stabilizer.
  • Page 22 ANGEL- Instruction Manual ITEM CODE: BH67 Elevator Elevator pushrod pushrod Rudder pushrod Secure Bend and cut after...

  • Page 23: Installing The Switch

    ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. INSTALLING THE SWITCH. 1. Cut out the switch hole using a modeling knife. Use a 2mm drill bit and drill out the two mounting holes through the fuselage side. 2. Secure the switch in place using the two machine screws provided with the radio system.

  • Page 24: Wing Attachment

    ANGEL- Instruction Manual ITEM CODE: BH67 Battery Receiver WING ATTACHMENT. *** Test fit the aluminium tube dihedral brace Secure into each wing haft. The brace should slide in easily. If not, use 220 grit sand around the edges and ends of the brace until it fits prop- erly.
  • Page 25 ANGEL- INSTRUCTION MANUAL ITEM CODE: BH67. 3. Insert two wing panels as pictures BALANCING. below. 1) It is critical that your airplane be bal- anced correctly. Improper balance will cause your plane to lose control and crash. THE CENTER OF GRAVITY IS LOCATED 80MM BACK FROM THE LEADING EDGE OF THE WING.

  • Page 26: Control Throws

    ANGEL- Instruction Manual ITEM CODE: BH67 CONTROL THROWS. 1. We highly recommend setting up a plane using the control throws listed. 2. The control throws should be meas- ured at the widest point of each control sur- face. 3. Check to be sure the control surfaces move in the correct directions.
