Installation
1 Microphone lead
2 Groove
2 Attach the microphone clip to the sun visor.
1
2
1 Microphone clip
2 Clamps
Use separately sold clamps to secure the lead where neces-
sary inside the vehicle.
Install the microphone on the sun visor when it is in the up
position. It cannot recognize the driver's voice if the sun visor is
in the down position.
Installation on the steering
column
1 Detach the microphone base from the micro-
phone clip by sliding the microphone base
while pressing the tab.
1
2
1 Tab
2 Microphone base
2 Mount the microphone on the steering column.
1
2
1 Double-sided tape
2 Clamps
Use separately sold clamps to secure the lead where neces-
sary inside the vehicle.
Keeping it away from the steering wheel.
Adjusting the microphone
angle

Appendix

Troubleshooting

If you have problems operating this product, refer to this sec-
tion. The most common problems are listed below, along with
likely causes and solutions. If a solution to your problem cannot
be found here, contact your dealer or the nearest authorized
Pioneer service facility.
Problems with the AV screen
The screen is covered by a caution message and the video
cannot be shown.
 The parking brake lead is not connected or applied.
— Connect the parking brake lead correctly, and apply the
parking brake.
 The parking brake interlock is activated.
— Park your vehicle in a safe place and apply the parking
brake.
The audio or video skips.
 This product is not firmly secured.
— Secure this product firmly.
No sounds are produced. The volume level will not rise.
 Cables are not connected correctly.
— Connect the cables correctly.
The picture is stretched, with an incorrect aspect ratio.
 The aspect setting is incorrect for the display.
— Select the appropriate setting for that image.
iPod cannot be operated.
 The iPod is frozen.
— Reconnect the iPod with the USB interface cable for iPod /
iPhone.
— Update the iPod software version.
 An error has occurred.
— Reconnect the iPod with the USB interface cable for iPod /
iPhone.
— Park your vehicle in a safe place, and turn off the engine.
Turn the ignition key back to off (ACC OFF). Then restart
the engine, and turn the power to this product back on.
— Update the iPod software version.
 Cables are not connected correctly.
— Connect the cables correctly.
Sound from the iPod cannot be heard.
 The audio output direction may switch automatically when
the Bluetooth and USB connections are used at the same
time.
— Use the iPod to change the audio output direction.
33
