Audio adjustments

Adjusting source levels

SLA (source level adjustment) lets you adjust the volume level of
each source to prevent radical changes in volume when switch-
ing between sources.
p Settings are based on the FM tuner volume level, which
remains unchanged.
p This function is not available when the FM tuner is selected
as the AV source.
1 Compare the FM tuner volume level with the
level of the source you want to adjust.
2 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
3 Touch [Source Level Adjuster].
4 Touch or to adjust the source volume.
p If you directly touch the area where the cursor can be moved,
the SLA setting will be changed to the value of the touched
point.
p "+4" to "–4" is displayed as the source volume is increased
or decreased.
p The default setting is "0".

Adjusting loudness

This function compensates for deficiencies in the low-frequency
and high-frequency ranges at low volume.
p This function is not available while you make or receive a call
using the hands-free function.
1 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
2 Touch [Loudness].
3 Touch the item.
The following items are available:
Off (default), Low, Mid, High.

Using the subwoofer output

This product is equipped with a subwoofer output mechanism,
which can be turned on or off.
1 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
2 Touch [Subwoofer] to switch "On" (default) or
"Off".
24
Adjusting the subwoofer
settings
p This function is available only when "Subwoofer" is "On".
 Using the subwoofer output on page 24
1 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
2 Touch [Subwoofer Settings].
3 Touch or to turn the subwoofer phase
to normal or reverse.
4 Touch or to adjust the subwoofer level
between -24 and 6.
5 Touch or to adjust the subwoofer
frequency.
The following items are available:
80Hz(default), 50Hz, 63Hz, 80Hz, 100Hz, 125Hz.
Switching the rear speaker
output
1 Turn the source off.
2 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
3 Touch [Rear Speaker Output].
4 Touch to switch "Full" (default) or
"Subwoofer".
 When this function is set to "Subwoofer
Settings", "Preout" is fixed to "Subwoofer
Settings".

Switching the RCA rear output

When "Rear Speaker Output" is set to "Subwoofer Settings",
this setting is fixed to "Subwoofer Settings".
1 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
2 Touch [Preout] to switch "Subwoofer
Settings"(default) or "Rear".

Boosting the bass

1 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
2 Touch [Bass Booster].
3 Touch to select the bass boost level from 0 to
+6.

Setting the high pass filter

1 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
2 Touch [High Pass Filter].
3 Touch the item.
The following items are available:
Off(default), 50Hz, 63Hz, 80Hz, 100Hz, 125Hz.

Using the equalizer

Recalling equalizer curves
There are seven stored equalizer curves that you can easily recall
at any time. Here is a list of the equalizer curves:
●
S.Bass is a curve in which only low-pitched sound is boosted.
●
Powerful is a curve in which low- and high-pitched sounds
are boosted.
●
Natural is a curve in which low- and high-pitched sounds
are slightly boosted.
●
Vocal is a curve in which the midrange, which is the human
vocal range, is boosted.
●
Flat is a flat curve in which nothing is boosted.
●
Custom1 is an adjusted equalizer curve that you create. If
you select this curve, the effect is applied to all AV sources.
●
Custom2 is an adjusted equalizer curve that you create. If
you select this curve, the effect is applied to all AV sources.
p The default setting is "Powerful".
1 Display the "Audio" setting screen.
 Displaying the "Audio" setting screen on page 23
2 Touch [Graphic EQ].
3 Touch the equalizer you want.
