KCT DSP-40 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Perfect Safety! Easy Operation! Low Price!
Stand-alone Quad DVR
DSP-40
User's Manual
Korea Computer Technologies co., ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSP-40 and is the answer not in the manual?

Questions and answers

Summary of Contents for KCT DSP-40

  • Page 1 Perfect Safety! Easy Operation! Low Price! Stand-alone Quad DVR DSP-40 User’s Manual Korea Computer Technologies co., ltd.
  • Page 2 1) This Manual is made for user of DSP-40. 2) This Manual includes features, handling method and setup of DSP-40. 3) This Manual must be read before using DSP-40. 4) If you have any question or have any difficulty in using, please contact your agency.

  • Page 3: Table Of Contents

    CONTENTS 0. Warning ··························································································2 1. Introduction·····················································································3 ■ Features ········································································································ 3 ■ Mainly Functions ··························································································· 4 ■ Names of each parts ····················································································· 5 2. Installation ······················································································7 3. Using Method ··············································································· 11 ■ Booting ········································································································ 11 ■ Bypass········································································································· 12 ■ Recording ···································································································· 17 ■...

  • Page 4: Warning

    DSP-40 WARNING Thank you for choosing DSP-40. Before installation and use, please read and understand following instructions for your safety. Please install the product only after finding a suitable installment place. Please install on a flat surface. Please install in place with good ventilation...

  • Page 5: Introduction

    Korea Computer Technologies, co., ltd Introduction 1. Features 1) This system is developed the first of the world that can record 4-channel at the same time, and display moving-image in quad screen. 2) Each channel can be displayed up to 30fps, and maximum 120fps totally. 3) Using Wavelet algorithm, this system realizes compression/extraction in high resolution.

  • Page 6: Mainly Functions

    DSP-40 2. Mainly Functions ■ various bypass display (realtime quad, single sequential, auto switching, freezing) ■ 4 channel recording at the same time. Recording max 120fps totally ■ Various recording method by record button, reservation, sensor, motion detection ■ Fast and easy search for recording data ■...

  • Page 7: Names Of Each Parts

    Korea Computer Technologies, co., ltd 3. Names of each parts The Front side Enter SETUP mode or select item ENTER Cancel selection or return to previous item Move cursor up/down/left/right Direction Recording / Recording stop Zoom the specific area in ZOOM the screen Play...
  • Page 8 DSP-40 The Rear side Camera input Connect camera cable Monitor input Lan led Connect monitor cable Emit light when lan connection and working LAN port Connect Lan cable Sensor led Emit light when sensor in Connect sensor and digital out...

  • Page 9: Installation

    Korea Computer Technologies, co., ltd Installation 1. Contents of product 1) Main system (Embedded HDD, optional max 4EA) 2) Power cable 3) User’s manual, host program CD 1EA - If you have shortage or defects of parts, please contact your agency. 2.
  • Page 10 DSP-40 1) Camera connection Connect camera to CAMERA INPUT of backward of system. 2) Monitor connection Connect monitor to MONITOR OUTPUT of backward of system. 3) Sensor connection (optional) Connect sensor to SENSOR IN of backward of system. 4) Network connection (optional) Construct RS232C, Modem and LAN connection referring to below network connection diagram.
  • Page 11 Korea Computer Technologies, co., ltd 2) Modem(PSTN) connection PSTN TEL. line RS232C TEL. line External Modem 25pin 9pin Femal e Male 3) LAN connection ※ Use cross cable when direct connection between PC and DVR using LAN cable. 2. Installation...
  • Page 12 DSP-40 4. After installation 1) Bypass, recording, replay, sensor test Confirm if bypass screen is displayed well. Then record and replay some data referring to in this manual. And confirm if sensor record is possible by making any event. If any problem, contact your agency.

  • Page 13: Using Method

    Korea Computer Technologies, co., ltd Using Method Booting 1) When system is booting, the follow screen is displayed. PLEASE WAIT VIDEO INITIALIZE NTSC QUAD INITIALIZE ENCODER INITIALIZE DECODER INITIALIZE RTC INITIALIZE VOICE INITIALIZE LAN INITIALIZE NONE SYSTEM BIOS VERSION 20011008-20010928 STARTING SYSTEM…...

  • Page 14: Bypass

    DSP-40 Bypass Principle of operation method ▶ User can display camera input to screen immediately, and can select 1-screen mode or split-screen mode. ▶ Auto Switch, Freeze, Zoom mode available ▶ Current time, camera name, and system status (i.e., Recording, Zoom, Freeze, Sensor) is displayed into screen.

  • Page 15: Quad Screen

    Korea Computer Technologies, co., ltd 1. Quad Screen - If user press QUAD button in bypass status, the button emits light and quad screen is displayed. HDD-Status bar Display used quantity of HDD Current time Display current time 2001. 08. 01. 12:34:56 CAMERA 1 CAMERA 2 CAMERA 4...
  • Page 16 DSP-40 2. 1-Channel Screen - If user press camera button in bypass status, not in zoom or freeze mode, 1-channel screen is displayed. Display current time Current time SWITCHING Display switching on/off 2000. 01. 01. 12:34:56 Sensor In/Out Display Sensor...
  • Page 17 Korea Computer Technologies, co., ltd 3. Operation Method Freezing screen Auto Switching Cancel Zoom Screen Direction AUTO FREEZE QUAD DISPLAY ZOOM ENTER Each Camera Quad screen Enter / Setup ▶ Screen Auto Switching (1-Channel screen mode only) 1) If user press AUTO button in 1-channel screen mode, the screen is auto switched according to switching gap of configuration in SETUP mode.
  • Page 18 DSP-40 ▶zoom : selected area is zoomed (Quad screen mode only) 1) If user press zoom button, the button emits light and zoom area selection rectangle is displayed. 2) Using direction key, move zoom area. 3) Pressing enter key, selected area is zoomed and zoom-icon is displayed in up-left of each screen.

  • Page 19: Recording

    Korea Computer Technologies, co., ltd Recording Principle of operation method ▶ Recording method includes 1) button recording by user, 2) reserved recording by configured schedule, 3) recording by event of sensor. ▶ If motion detection function is valid, blue recording icon is displayed. If motion detection event occurs, blue changes to red.
  • Page 20 DSP-40 1. Recording by Button 1) If user press recording button, the button emits light, recording icon is displayed, and recording starts immediately. 2) Recording by button can be started in any status(bypass, replay and setup mode), but not in password input screen.

  • Page 21: Recording By Motion Detection

    Korea Computer Technologies, co., ltd 4. Recording by Motion Detection 1) In the setup mode, if RECORD MOTION DETECTION SENSITIVITY item is not "NONE"(p37), motion detection is valid and color of recording icon is blue. 2) Objects in the screen move more than motion detection sensitivity, recording by motion detection start.

  • Page 22: Replay

    DSP-40 Replay Principle of operation method ▶ In the bypass mode, pressing replay button, the screen changes to setting of replay start time screen. ▶ Select replay start time to play. ▶ And Pressing replay button again, replay starts. ▶ Search wanted screen by following method.
  • Page 23 Korea Computer Technologies, co., ltd 1. Setting of replay start time PLAY START FROM 2000. 01. 01. 00:00:00 RECORDED FROM 2000. 01. 01. 00:00:00 2000. 01. 01. 12:34:56 ▶ Start time of replay is ending time of last replay. (If it is the first time of replay, displayed start time is head of recording time.) ▶...
  • Page 24 DSP-40 2. Start of replay ▶ In the screen of replay start time setting, pressing PLAY button, then replay starts from the setting time. 3. Replay ▶Stop replay : Pressing STOP button in replay screen, replay stops and go back to the screen of replay start time setting.

  • Page 25: Setup

    Korea Computer Technologies, co., ltd SETUP Principle of operation method ▷ Pressing ENTER/SETUP button in the bypass mode, changes to setup mode. ▷ Using UP/DOWN selection key, select the item to set. ▷ Button is displayed in selected item. ▷ Pressing ENTER button, go to lower grade item of selected item. ▷...
  • Page 26 DSP-40 0. Input Password INPUT YOUR PASSWORD PASSWORD : USING DISPLAY KEY INPUT 8-DIGIT PASSWORD ▶User must input password to enter SETUP mode. ▶Password is composed of 8 digit number consisting integer from 1 to 4. (Factory default is 12341234. Do change password and use!) ▶Pressing display key from No.1 to No.4, input password.
  • Page 27 Korea Computer Technologies, co., ltd ※ Common operation method ▶ SETUP mode is composed of three part, SYSTEM, CAMERA, RECORD. Pressing ENTER at each part, lower grade is displayed. SETUP SYSTEM CAMERA RECORD ▶ In lower grade, - Using direction key, select item. - Pressing ENTER, selected item is changeable and flashing.

  • Page 28: Configuration System

    DSP-40 1. SYSTEM 1) SYSTEM ID SYSTEM SYSTEM ID TIME SET COMMUNICATION DISK INFO ALARM LIST CHANGE PASSWORD DIGITAL OUTPUT SET ▶ Using several systems at the same time, user can set ID. ① Value from 0 to 99 can be used.
  • Page 29 Korea Computer Technologies, co., ltd 2) TIME SET SYSTEM SYSTEM ID TIME SET COMMUNICATION DISK INFO ALARM LIST TIME SET CHANGE PASSWORD DIGITAL OUTPUT SET TIME DISPLAY CURRENT TIME SET 2001. 07. 06. 09:00 FRI 2-1) TIME DISPLAY ▶ Set up if current time up-left of bypass screen displays or not. ①...
  • Page 30 DSP-40 3) COMMUNICATION SYSTEM SYSTEM ID TIME SET COMMUNICATION DISK INFO ALARM LIST COMMUNICATION CHANGE PASSWORD COMMUNICATION DIGITAL OUTPUT SET BAUD RATE 1152 SERIAL DEVICE PAN/TILR PROTOCOL 3-1) BAUD RATE ▶ Set velocity of serial communication. Two figures, '00' at the tail of displayed value is omitted.
  • Page 31 Korea Computer Technologies, co., ltd 3-2) SERIAL DEVICE ▶ This system have 1 RS232C port. The port is made for PC and MODEM communication, and PAN/TILT control. ① Refer to explanation of Network(p8) and PAN/TILT(p63) in this manual. 3-3) PAN/TILT PROTOCOL ▶...
  • Page 32 DSP-40 4) DISK INFO SYSTEM SYSTEM ID TIME SET COMMUNICATION DISK INFO ALARM LIST DISK INFO CHANGE PASSWORD DIGITAL OUTPUT SET DISK 1 20.5GB 22.5% USED DISK 2 NO DISK DISK 3 NO DISK DISK 4 NO DISK SELECT DISK AND PRESS ENTER TO FORMAT ▶...
  • Page 33 Korea Computer Technologies, co., ltd 4-1) DISK FORMAT ▶Using UP/DOWN direction key, select disk to be formatted. ▶Pressing ENTER button, confirm message is displayed, and pressing again, disk formatting starts. ▶Formatting procedure is displayed by the ratio of formatted storage to total storage. ▶When the formatting finishes, the information of disk is displayed.
  • Page 34 DSP-40 6) CHANGE PASSWORD SYSTEM SYSTEM ID TIME SET COMMUNICATION DISK INFO CHANGE PASSWORD ALARM LIST CHANGE PASSWORD CURRENT PASSWORD -------- DIGITAL OUTPUT SET NEW PASSWORD -------- NEW PASSWORD AGAIN -------- ▶Change current password to new password. ▶Pressing ESC button while input, input value is invalidated, and return to previous screen.
  • Page 35 Korea Computer Technologies, co., ltd 7) DIGITAL OUTPUT SET SYSTEM SYSTEM ID TIME SET COMMUNICATION DISK INFO DIGITAL OUTPUT SET ALARM LIST CHANGE PASSWORD SENSOR DIGITAL OUTPUT SET BUZZER TIME OUTPUT TIME ▶When sensor on, buzzer embedded in the system or output device in the digital output port works.

  • Page 36: Configuration Camera

    DSP-40 2. CAMERA 1) INSTALLED CAMERA CAMERA INSTALLED CAMERA CC-- CAMERA 1 NAME STREET CAMERA 2 NAME DOOR CAMERA 3 NAME DESK 1 CAMERA 4 NAME DESK 2 CAMERA NAME DISPLAY SWITCHING TERM ▶ Set up channel which is really installed camera among valid 4 channel. And classify Black/White camera and color camera.
  • Page 37 Korea Computer Technologies, co., ltd 2) CAMERA NAME CAMERA INSTALLED CAMERA CC-- CAMERA 1 NAME STREET CAMERA 2 NAME DOOR CAMERA 3 NAME DESK 1 CAMERA 4 NAME DESK 2 CAMERA NAME DISPLAY SWITCHING TERM ▶Set up camera name to be displayed in screen. ①...

  • Page 38: Configuration Record

    DSP-40 3. RECORD RECORD RECORD FRAME QUALITY AUTO DELETE RECORD ON BOOT UP MOTION DETECTION SENSOR TIMEOUT RESERVED RECORDING 1) RECORD FRAME ▶ Set up compression rate of image to be recorded Set up record frame per second. ① From 1 to 30 can be used. Default value is 30.
  • Page 39 Korea Computer Technologies, co., ltd 4) RECORD ON BOOT UP ▶ Set up if recording starts by itself on boot up or not. ① Selecting ON, recording starts automatically on boot up. ② Default selection is OFF. 5) MOTION DETECTION RECORD RECORD FRAME QUALITY...
  • Page 40 DSP-40 6) SENSOR TIMEOUT ▶ Set up duration time(sec) of recording in case of sensor event. ① from 1 to 10 can be used. Default value is 10. 7) RESERVED RECORDING RESERVED RECORDING WEEKDAYS 00:00 - 00:00 SATURDAY 00:00 - 00:00...
  • Page 41 Korea Computer Technologies, co., ltd 7-2) SATURDAY ▶ Set up schedule of recording during Saturday. ① Set up method of this function is similar to recording during weekdays. 7-3) SUNDAY ▶ Set up schedule of recording during Sunday. ① Set up method of this function is similar to recording during weekdays. 7-4) SPECIFIC DAYS SPECIFIC DAYS 1 : ON...

  • Page 42: Outline Of Setup Items

    DSP-40 ※ The Outline of SETUP menu SETUP SYSTEM SYSTEM ID TIME SET TIME DISPLAY CURRENT TIME SET COMMUNICATION BAUD RATE SERIAL DEVICE PAN/TILT PROTOCOL DISK INFO FORMAT GATEWAY ALARM LIST SUBNETMASK CHANGE PASSWORD PORT DIGITAL OUTPUT SET BUZZER OUTPUT...

  • Page 43: Network

    Korea Computer Technologies, co., ltd NETWORK Principle of operation method ▷ If user set up host program(“DVR ETHERNET”, "DVR DIALUP") in PC, between local system and host PC user can transmit moving image and can print specific frame. Microsoft Windows 98/ME have to be installed in the Host PC. ▷...

  • Page 44: Dvr Ethernet' Program For Lan

    4) Select location to install, Then click NEXT button. 5) Select location to make at “start-program”. 6) Confirm information, Then click NEXT button. Installation is progressing. 7) With finishing installation, Program group “KCT” and execution file “DVR ETHERNET” is formed. 1. Set up DVR ETHERNET 1) Setup IP ADDRESS ①...
  • Page 45 Korea Computer Technologies, co., ltd 2) Setup Save path ① Clicking "Save" menu, sub menu “Setup”, below screen is displayed. ② Set the directory path to save screen, when you capture bypass or recorded screen. 2. Transmission method though LAN using "DVR ETHERNET” 1) Preparation of transmission ①...
  • Page 46 DSP-40 2) Transmitting bypass image. ① Clicking "Live Mode" button, bypass image will be transmitted. ② During transmission, "Live Mode" button is changed to "Stop" button. Clicking this, transmission stops. ③ If the Camera connected the DVR supports Pan, Tilt, Zoom, Focus function, you can use that function through this program in the remote area.
  • Page 47 Korea Computer Technologies, co., ltd 3) Transmitting recorded image ① Clicking "Replay Mode" button, setting screen of play back start time is displayed Record start time and end time in the Remote DVR PAUSE STOP PLAY Play speed Start time ②...
  • Page 48 DSP-40 3. Capture image ① Click the right button of the mouse on the each camera screen you want to capture. ② Clicking ‘capture’, displaying screen(bypass or recorded image) is captured. Captured image is saved in selected directory(referring to ‘1.setup DVR ETHERNET’) as ‘c#_yyyy_MM_dd-hh_mm_ss’...

  • Page 49: Dvr Dialup' Program For Serial Port, Modem

    4) Select location to install, Then click NEXT button. 5) Select location to make at “start-program”. 6) Confirm information, Then click NEXT button. Installation is progressing. 7) With finishing installation, Program group “KCT” and execution file “DVR ETHERNET” is formed. 1. Set up "DVR DIALUP"...
  • Page 50 DSP-40 ③ Clicking “Phonebook”, sub menu of “Setup” menu, you can set up remote name and telephone number using in modem communication. ④ Clicking "Update" after inputting name and telephone number, system registers that automatically. If you want to modify name or number, click "Update" after modify. When updating, confirm message as below is displayed.
  • Page 51 Korea Computer Technologies, co., ltd ③ Double clicking the transmitted frame, “Title” window is displayed, in which you can fix the name of that frame. Fixed name is displayed in the status bar. ④ Clicking “Save as”, sub menu of “File” menu, you can save that frame as BMP format. ⑤...
  • Page 52 DSP-40 3. Transmission, save, print image through MODEM 1) Preparation of transmission ① Construct network referring to page 8 in this manual, and execute "DVRDIALUP.EXE". ② Referring to previous "1. Set up “DVR DIALUP", set up "DEVICE" and "BAUD RATE". In the status bar, message "online"...

  • Page 53: Dvr Confirm' Program For Verify Captured Image

    Korea Computer Technologies, co., ltd “DVR CONFIRM” for Verify Captured Image forged or not. 1) Install the ‘DVR Confirm’ program in the software CD and execute it. 2) Open image to verify. (If it is not the image captured by our DVR, “This is NOT the image captured by our DVR!”...
  • Page 54 DSP-40 3) Then click ‘Verify’ button. 4) If it is the original image captured by our DVR, “This is the ORIGINAL image captured image” message is displayed. 5) If it is forged image, “This is forged image” message is displayed and forged area is filled...

  • Page 55: Specifications

    Korea Computer Technologies, co., ltd Specifications System DSP-40 Operation type Stand-alone, Self operation system Save Max 4 EA available Camera input 4CH (NTSC/PAL) Video output 1CH (NTSC/PAL) 320 × 240, 640 x 480, true color Resolution Recording speed 30fps, MAX 120fps, Available for change...

  • Page 56: Recording Time Table

    DSP-40 Recording Time Table In case of recording in 4channel at the same time (Quality=1) 40GB 347 h 115 h 69 h 34 h 23 h 11 h 80GB 694 h 230 h 138 h 68 h 46 h 22 h...

  • Page 57: Appendix

    Korea Computer Technologies, co., ltd APPENDIX Selection of NTSC/PAL User can selects NTSC/PAL type by setting jumper. But user need not change that except special case, because factory set the correct jumper for selling region. The Rear Side MONITOR OUT CAMERA IN NTSC POWER...

  • Page 58: Installation Of Additional Hdd

    DSP-40 Installation of additional HDD 1. Embedded HDD 1) HDD is embedded in this system. 2) Max 4 HDD can be installed in each system. User must format new HDD before use that. Warning! 2. Installation of additional HDD 1) Turn off the system, and disconnect attached cable.
  • Page 59 Korea Computer Technologies, co., ltd 3) You can see installed HDD. Additional HDD can be installed in specified position as this picture. The rear side HDD2 HDD4 (Slave) (Slave) POWER HDD1 HDD3 (Master (Master The front side 4) Connect data cable and power cable to additional HDD. ▶...

  • Page 60: Pan/Tilt, Zoom, Focus

    DSP-40 5) Put together case again. 6) Confirm HDD information ▶ Put on the system and press SETUP button, select system item. ▶ Using UP/DOWN direction key, select DISK INFO item. ▶ Confirm if new HDD is displayed, and using ratio is 0% or not.
  • Page 61 Korea Computer Technologies, co., ltd 2. Pan/Tilt 1) In 4-CH bypass screen, press REW button, user can enter Pan/Tilt mode. 2) Use direction key, select camera to be applied, and press ENTER button. 3) Press LEFT/RIGHT direction key, the camera move left/right. (Pan) 4) Press UP/DOWN direction key, the camera move up/down.

  • Page 62: Many Dvr Connected To One Ip

    DSP-40 Many DVR connected to One Static IP 1) You can connect many DVR to one static IP by setting each ‘SYSTEM ID’ at each DVR. So if you have only one static IP, you can watch many DVR in the remote PC.
  • Page 63 Korea Computer Technologies, co., ltd 4) Install “DVR ETHERNET” program in the remote PC. Set up not virtual IP but static IP (case of above example : not 192.168.123.xxx but 61.78.64.163) and select SYSTEM ID of DVR you want to connect.(referring to p.42) 5) But first of all, you must set up PORT FORWARDING in your ROUTER.

  • Page 64: Troubleshooting

    DSP-40 ♠ Troubleshooting ♠ Continuous warning sound, “beep~” ☞ If camera cable is unplugged from DVR, beep sound. Check this. (p34) ☞ If sensor in, beep sound. Check sensor in or not. (p33) Blank screen (or Shaking screen). ☞ Check connection camera and monitor. (p8) ☞...

  • Page 65: Digital Video Recorder

    Digital Video Recorder DSP-40 Korea Computer Technologies ADDRESS KCT B/D 111-3 YANGJAE-DONG, SEOCHO-GU, SEOUL, KOREA TEL. +82-2-575-2331 +82-2-575-5450 Web site http://www.kct21.com/...
