- Page 1 AT&T ® SPlRIT Communications System SPIRIT Attendant ConnecT/R Owner’s Manual...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce risk of injury from fire or electric shock, always follow bask safety precautions when using this product. The safety symbol (exclamation point inside a triangle) on the Attendant ConnecT/R alerts you to the Important operat- ing and maintenance instructions below. -
Page 3: Save These Instructions
manual. If you cannot resolve the problem, or if the product is damaged, Call the AT&T Helpline at 1-800-628-2888. Do not open the product. Opening the product may expose you to dangerous voltages or other risks. thunderstorms, avoid using tele- 10. -
Page 4: Table Of Contents
Table of Contents Introduction Installation Step 1— Mount the SPIRIT Step 2—Connect the SPIRIT Attendant ConnecT/R Step 3—Test the Equipment Troubleshooting Appendix A—Wiring Requirements Appendix B—Warranty While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing, AT&T assumes no responsibility for any errors. -
Page 5: Introduction
Introduction The following descriptions define important terms used in this manual. ® The SPIRIT Communications System Attendant ConnecT/R provides you with the ability to add a SPIRIT Attendant to your SPIRIT System. It connects to the controller. The controller is the central processor through which all SPIRIT calls in your company are processed. - Page 6 Figure 2. SPIRIT Attendant ConnectT/R Applications...
-
Page 7: Installation
Installation INSTALLATION INSTRUCTIONS Never install telephone wiring during a Iightning storm. Never install telephone jacks in wet loca- tions unless the jack is specifically designed for wet locations. Figure 3. SPIRIT Attendant ConnecT/R with Attached SPIRIT Attendant NOTE: The switches on the SPIRIT Attendant ConnecT/R are not used. They have been removed to prevent accidental incorrect installations. -
Page 8: Step 1- Mount The Spirit
Step 1 — Mount the SPIRIT Attendant ConnecT/R (optional). The SPIRIT Attendant ConnecT/R is designed to be placed on your desk or mounted on any vertical surface. Do not place it on the floor. Hardware has been included to mount the SPIRIT Attendant ConnecT/R on the wall: two plastic wall-mount tabs, two anchors, and two #6 screws. - Page 9 studs or cross members), partially screw the two screws into the wall at the marks, remove them, hang the tabs on the screws, and then tighten the screws. For plaster, plasterboard, cinder block, or brick surfaces, drill a 3/16" hole at each mark and insert an anchor into each of the holes.
-
Page 10: Step 2-Connect The Spirit Attendant Connect/R
Connect the SPIRIT Attendant ConnecT/R to the Controller. Using 4-wire cord, plug one end into the CTRLR jack on the back of the SPIRIT Attendant ConnecT/R and connect the other end into the STATION jack on the controller. Connect the SPIRIT Attendant to the SPIRIT Attendant ConnecT/R. -
Page 11: Step 3-Test The Equipment
Use only a UL Listed wall plug-in NOTE: power transformer that has Class 2 outputs and the following characteristics: Input rating: 99-127 V AC rms 60 llz 150 mA maximum 27-35 V DC at 200 mA 0utput rating: 14-18 V DC at 200 mA The power transformer ConntecT/R has these characteristics. -
Page 12: Troubleshooting
Troubleshooting This section should help you determine the cause of problems you might encounter and help you resolve them. Remember that the way your SPIRIT System was customized may influence how a particular Operational Difficulty Ringing SPIRIT Attendant doesn’t respond to outside calls SPIRIT Attendant doesn’t respond to intercom calls SPIRIT Attendant ConnecT/R is very warm to the touch Check with the person in your organization responsible for the SPIRIT System. -
Page 13: Appendix A - Wiring
Appendix A — Wiring Note the following cabling requirements before connecting the equipment. If these limits (which are the same ones that apply to our current SPIRIT System) are exceeded, Attendant ConnecT/R may not work properly. The total wire length from the controller to the SPIRIT Attendant cannot exceed a total of 1000 feet of 24- gauge DIW (twisted-pair copper) wire or 22-gauge D station wire,... - Page 14 Appendix B — Limited Product AT&T warrants that the product will be free from defects in material and workmanship for one year from the date of purchase. If the product becomes defective and such defect reported to AT&T within the one-year warranty period, AT&T will repair or replace the product, at its option, without charge.
- Page 15 Index AT&T Helpline 8 Controller C T R L R j a c k 6 Installation Connect the ConnecT/R 5 Connect the SPIRIT Attendant Mount the ConnecT/R 4 Test the equipment 7 POWER jack 6 Power Transformer 6 Safety Instructions 3 SPIRIT Attendant 1 STATION jack 5 TEL DEVICE jack 6...
-
Page 16: Fcc Warning Statement
FCC Warning Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful Interference when the equipment is operated in a commercial environment. - Page 17 518-453-712...
