Operation

IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet before assembling or
removing the accessories.
Tool required: Phillips head screwdriver
1. Slide the back panel onto the base. To secure, insert the
two (2) screws into the front of the back panel.
2. Slide the end of the lower hose onto the side connector.
3. Place the upper handle onto the upright back panel.
4
4. Insert locking part into slot.
5. Insert the screw into the back of the handle and screw it
into the locking part. Tighten until secure.
6. Clip the TurboTool onto the front of the TurboTool caddy.
AU: 1300 361 505 / NZ: 0800 800 900
Vax Service line
