User Guide
Vax Careline: AU: 1300 361 505
NZ: 0800 800 900
Robotic Cleaner
Get Cleaning...
What ' s your Vax ' s model number?
V
X
2
What ' s your serial number?
(Located on the base of the robotic cleaner)
Note these down in case you need them in future. Please keep instructions for further use.
vax.com.au
VX2
vax.co.nz
Advertisement
Table of Contents
Related Manuals for Vax Odessey VX2
Summary of Contents for Vax Odessey VX2
- Page 1 NZ: 0800 800 900 Robotic Cleaner Get Cleaning... What ’ s your Vax ’ s model number? What ’ s your serial number? (Located on the base of the robotic cleaner) Note these down in case you need them in future. Please keep instructions for further use.
-
Page 2: Machine Overview
Machine Overview 1. Remote control 5. AC adapter plug 2. Robotic cleaner 6. Docking station 3. AC adapter 7. Virtual wall 4. AC adapter cord 8. Batteries (2x type C, 1.5V) Vax Careline: AU: 1300 361 505 NZ: 0800 800 900... - Page 3 - indicate if the bumper got stuck - if triggered constantly for 5 seconds or longer the - indicate if the motor is overloaded robot will stop automatically - Also see Troubleshooting on page 19 vax.com.au vax.co.nz...
- Page 4 1. Upper cover • Hidden: battery compartment cover 2. Dust bin cover • Hidden: battery pack in battery compartments located next to the dust bin 3. Filter 4. Dust bin Vax Careline: AU: 1300 361 505 NZ: 0800 800 900...
-
Page 5: Docking Station
6. Power switch - ashes during charging process 7. LED (lights up if switched on) 2. Front button 8. Receiver 3. Charging Pins 9. Battery cover 4. Socket for AC adapter plug • Hidden: 4 rubber feet underneath vax.com.au vax.co.nz... -
Page 6: General Safety Information
Danger of injury and explosion due to improper handling of the batteries provided. 12. Do not replace the battery pack with other batteries or rechargeable batteries. 13. Only use the original battery pack contained in the robotic cleaner and only replace with a genuine Vax battery pack suitable for this model only. -
Page 7: Operation
22. Do not put objects on top of the appliance. 23. Do not modify or repair the appliance yourself. Please contact Vax for details of an authorised repair agent. 24. Do not use robotic cleaner to vacuum: a. Water and any other liquid b. -
Page 8: Prohibited Use
6. Have the AC adapter cable placed behind the station (Fig. 3) so that it does not obstruct the robot’s ability to dock. NOTE: Also remember not to locate the virtual wall near the docking station. Otherwise your robot may be obstructed from docking to the station. Vax Careline: AU: 1300 361 505 NZ: 0800 800 900... -
Page 9: Connecting The Docking Station
2. Insert the 2 supplied batteries (type C, 1.5 V) as indicated and make sure you position them correctly (Fig. 6). NOTE: When changing batteries, be sure not to mix batteries of di erent types or of those that are fully charged with those that are partly charged. vax.com.au vax.co.nz... -
Page 10: Charging Battery Pack For First Time
NOTE: When its battery capacity becomes low, your robot automatically returns to the docking station for charging. If it for any reason, does not succeed in docking onto the docking station, you will need to manually place it onto the docking station, as described above. Vax Careline: AU: 1300 361 505 NZ: 0800 800 900... -
Page 11: Preparing The Room
It may also be worthwhile to clear the room of potential obstacles, cables, mats, carpet runners and similar items. SHORT-PILE CARPETS NOTE: Short-pile carpets (up to 1 cm) can be cleaned with the robotic cleaner. NOTE: Use on long-pile carpet (longer than 1 cm) is not recommended. vax.com.au vax.co.nz... - Page 12 NOTE: Alternatively, you can activate the cleaning patterns you prefer via remote control. Just press one of the following keys: “ “, “ “, “ “. Note that best cleaning results are achieved, if your robot combines all 4 cleaning patterns automatically. Vax Careline: AU: 1300 361 505 NZ: 0800 800 900...
- Page 13 NOTE: Cli sensors detect stairs and other cli s to avoid falling. A height di erence of 7 cm or more would be judged as a cli . When a cli is detected, your robot will move backwards to avoid falling. Your robot will stop immediately if all 3 cli sensors detect a cli simultaneously. vax.com.au vax.co.nz...
- Page 14 2. Make sure the light beam does not shine into the room to be cleaned (Fig. 16-18). 3. Position the virtual wall such that the light beam does not shine on re ective walls or surfaces. Vax Careline: AU: 1300 361 505...
- Page 15 NOTE: To deactivate the smart virtual wall function, press the “ “ key again. You will hear two short beeps. vax.com.au vax.co.nz...
- Page 16 - You will hear eight beep sounds. - The appliance will start cleaning after 8 hours. NOTE: To deactivate this timer, press the “ “ key for 2 to 3 seconds. Vax Careline: AU: 1300 361 505 NZ: 0800 800 900...
- Page 17 However, in the case the appliance is not switched off (blue LED flashing slow, red LED ashing fast) switch o your robot via the “On/O ” key ) or the “ “ key on the remote control. The error will be deleted. You can start your robot again. vax.com.au vax.co.nz...
-
Page 18: Maintenance
Maintenance (Keep your Vax as good as new) Transport and storage CAUTION: Never store the appliance next to heat sources (e.g. heater, oven). Avoid exposing it to direct sunlight. Heat can damage the appliance. Always carry the appliance carefully; ideally use both hands. - Page 19 Maintenance (Keep your Vax as good as new) Cleaning dust bin and lter If the dust bin can no longer be completely emptied (Refer to, “Emptying the dust bin module”, on page 17) or if you can no longer remove dirt on the filter by hand: 1.
-
Page 20: Troubleshooting
Remove the side brush, refer to “Removing and cleaning the main brush” on page 22 and free it and its receptacle of dirt. If necessary, carefully use scissors or tweezers. Vax Careline: AU: 1300 361 505 NZ: 0800 800 900... - Page 21 “Removing and cleaning the main brush” on page 22. If necessary, carefully use scissors or tweezers. we’re here to help For troubleshooting please call or visit our website: AU: 1300 361 505 vax.com.au NZ: 0800 800 900 vax.co.nz vax.com.au vax.co.nz...
-
Page 22: Ordering Accessories And Spare Parts
2 side brushes 029791003002 1 virtual wall 029791003006 1 remote control 029791003003 1 AC adapter 029791003007 1 battery pack (rechargeable) 029791003004 1 lter 029791003008 1 main brush 1 support brush Vax Careline: AU: 1300 361 505 NZ: 0800 800 900... - Page 23 NOTE: If the brush is excessively dirty, it might be useful to replace it; see “Ordering accessories and spare parts” on page 21. 7. Re-insert the main brush as indicated (Fig. 32). 8. Put the support brush back into place. 9. Screw in the 3 screws (Fig. 33). vax.com.au vax.co.nz...
-
Page 24: Changing The Side Brush
If the appliance has been dropped or damaged in another way and has obvious signs of damage, only have it repaired by a Vax authorised dealer. Vax Careline: AU: 1300 361 505... -
Page 25: Removing/Replacing The Battery Pack
2. Run the robot until the battery pack is completely empty and the robot switches itself o . 3. Switch the toggle switch underneath the robot to “o ” (Fig. 36, “0” position). 4. Forcefully pull o the upper cover. 5. Remove the dust bin (Fig. 37). vax.com.au vax.co.nz... - Page 26 “Ordering accessories and spare parts” on page 21. - Dispose of the worn out battery pack. 10. Reinstall new battery pack, battery compartment cover and battery compartment cover screws. 11. Reinstall dust bin and upper cover. Vax Careline: AU: 1300 361 505 NZ: 0800 800 900...
-
Page 27: Other Information
8.30am to 5.00pm If you have queries or concerns about using your Vax, call the Vax Careline. Calls are charged at the standard local rate. Please make a note of the serial number and model number of the vacuum cleaner before calling. - Page 28 Distributed by Techtronic Industries Australia Pty. Ltd. Level 1, 660 Doncaster Road, Doncaster, Australia 3108. www.vax.com.au Careline: AU: 1300 361 505 www.vax.co.nz Careline: NZ: 0800 800 900 vax.com.au vax.co.nz...
