SPECIFICATIONS
Dimensions
Overall Length
Overall Width
Overall Height:
Wheelbase
Seat Height
Weights
Wet Weight
Maximum Payload
Engine
Type
Displacement
Bore x Stroke
Compression Ratio
Cylinder Numbering
Cylinder Sequence Number
Firing Order
Starting System
Sprint ST Sprint GT
83.2 in (2, 1 14 mm) 88.9 in (2,260 mm)
29.3 in (745 mm) 37 in (940 mm)
47.8 in (1,215 mm) 47.6 in (1,210 mm)
57.4 in (1,457 mm) 61.6 (1,565 mm)
32.3 in (820 mm) 32. 1 in (815 mm)
531 lbs (241 kg) 590 lbs (268 kg)
473 lbs (215 kg) 473 lbs (215 kg)
In-line 3 cyl. In-line 3 cyl.
64 cu in (1050 cc) 64 cu in (1050 cc)
3. 1 1 - 2.81 in (79 x 3. 1 1 - 2.81 in (79 x
71.4 mm) 71.4 mm)
12.0:1 12.0:1
Left to Right Left to Right
1 at left 1 at left
1-2-3 1-2-3
Electric Starter Electric Starter
