- Page 1 Instruction Manual Atmos Pro Treadmill Product Code: 8989 -500...
-
Page 2: Table Of Contents
Index Safety Instructions Connect with the ground Instructions Voltage information User Safety Instructions Exercise Safety Precautions Facility Safety Precautions Safety key Warning stickers Assembly Preparing site Diagram Content listing Electrical power requirements Assembly Fold/Unfold the treadmill Setup options Configuration Testing the treadmill operation Specifications Operation User control symbols used... - Page 3 Maintenance Preventive maintenance activities Warning Other preventive maintenance Treadmill cleaning Treadmill balance 5 steps to lubricate the treadmill Treadmill lubrication Adjust running belt Adjust motor belt...
-
Page 4: Safety Instructions
Safety Instructions Please pay attention to the following instructions before operating this treadmill. Connect with the Ground Instructions During use: This treadmill must be earthed and plugged into an • Do not use for stretching and do not attach straps or other appropriate electrical outlet that is properly installed and devices. -
Page 5: Facility Safety Precautions
Store the safety clip on the storage tab located on the left or • Ensure all users wear proper footwear on Kettler equipment. right side of the handrail. • Set up and operate the treadmill on a level surface. DO NOT operate in recessed areas or on plush carpet. -
Page 6: Warning Stickers
Warning Stickers Warning: Warning stickers indicate a potentially hazardous situation which, if not avoided, could result in death or serious injury. 1. Do not leave the treadmill before ensuring the machine has been locked tightly and properly. Keep children away Carefully read and understand the following caution and from the folded machine. -
Page 7: Assembly
Assembly Preparing Site • To find the ideal location to set up this treadmill, ensure that: • Area is well illuminate and well ventilated • Surfaced is levelled. • Free area for access to unit and emergency dismount. If it is possible keep the following clearances: 0.5m at each side and 2.0 m at the back. -
Page 8: Diagram
Content Listing Warning: Heavy Equipment At least two people must lift, move or assemble it. Use safe lifting methods. Please stand on the side rails when starting this treadmill See content listing and diagram below for carton contents. See Customer Service for contact information if any parts are missing. -
Page 9: Assembly
Assembly The treadmill has been assembled and tested at the factory, so you shouldn’t have any problem putting all the parts together. Components are designed to fit together, and only Shock and electrocution hazard! basic tools are required for the assembly process. Inside the box you will find a tool pack (Allen key, screwdriver, spanner Connect unit to an earthed outlet. -
Page 10: Fold/Unfold The Treadmill
Assembly Fold/Unfold the treadmill Use the following instructions to set up the units settings Fold: Hold the end of the running deck, by the side frames/ rails, and lift it until the machine gets an upright position and Insert the safety key into the corresponding socket. you hear a click from the security lock clasp. -
Page 11: Configuration
Use the following instructions to test the full speed of the treadmill and to check the belt for proper operation. Kettler recommends that the treadmill is unplugged or the on/off power (I/O) is switched off (O) when not in use. -
Page 12: Specifications
Specification Store Foldable and easy transport Packing 205 cm x 92 cm x 44 cm Occupying area 187 cm x 81 cm x 138 cm Folded area 131cm x 81 cm x 152cm Running area 149 cm x 49.5 cm Weight of product 85kg Shipping weight... -
Page 13: Operation
Operation Read and understand all instructions and warnings before using the treadmill. Understand all the safety procedure Before starting any exercise located in the Safety chapter. program consult your doctor. User Control Symbols Used Set up Press SET to establish the parameters Press STOP once to stop the running belt, end the workout session, and start Stop the Workout Review. -
Page 14: Setup
Setup Distance Time Heart Rate Speed Calories / Weight Incline Set up parameter Pause/Stop The treadmill should be completely stopped. During the treadmill workout, press the STOP button once for stopping the treadmill and keep the data recorded so far. If 1. -
Page 15: Starting The Treadmill
Starting the Treadmill Emergency dismount: Maximum user weight If you experience pain, feel faint or need to stop your treadmill in an emergency situation. is up to 160 kg, 25.2 St. Hold handrails for support. Step onto the side frames. 1. -
Page 16: Entertainment
Click on SEARCH DEVICE. Search for ‘Atmos Pro’ device name and click on it for Connect iPod/iPhone/MP3 into the headphone connection connection. -
Page 17: Quick Operation Guide
Quick Operation Guide Maximum user weight is 160 kg, 25.2 St. Warning 1. Place your feet on the side frames located on each side of Please stand on the side rails when the running belt. starting this treadmill 2. Clip the safety key onto your clothing and test it as described under Safety Key in the Safety Chapter (page 5). - Page 18 Speed Program Choices Speed Program 7 Speed Program 8 Speed Program 9 Speed Program 10 Speed Program 11 Speed Program 12 Speed Program 13 Speed Program 14 Speed Program 15...
- Page 19 Speed Program Choices Speed Program 16 Speed Program 17 Speed Program 18 Speed Program 19 Speed Program 20 Incline Program Choices The incline will change every 200m. Time and distance can be determined before the start of each program. Incline Program 21 Incline Program 22 Incline Program 23...
-
Page 20: Heart Rate Control Program
Incline Program Choices Incline Program 24 Incline Program 25 Incline Program 26 Incline Program 27 Incline Program 28 Incline Program 29 Heart rate control program Incline Program 30 Treadmill in STANDBY mode and all data in the window are ZERO, except WEIGHT. -
Page 21: Speed Programs
Running Programs Speed Programs Program Section Speed Km/h Incline % change by user Speed Km/h Incline % change by user Speed Km/h Incline % change by user Speed Km/h Incline change by user Speed Km/h 16.0 16.0 16.0 16.0 Incline % change by user Speed Km/h 16.0... -
Page 22: Maintenance
• Keep water and liquids away from electrical parts. Preventive Maintenance activities • Electrical charge can remain in unit after unplugging. Every Kettler treadmill that comes from the factory is already lubricated. However, you just need to follow simple steps to Other Preventive Maintenance maintain it. -
Page 23: Treadmill Cleaning
Treadmill Cleaning 5 steps to lubricate the Treadmill Keep the running belt free of dust and debris for smooth 1. Unplug the treadmill. running and preventing injuries. They could damage the 2. Access to the deck by lifting electric motor and other moving parts. the belt on the treadmill up After every workout use a neat, dry cloth for cleaning the with your fingers or with... -
Page 24: Adjust Running Belt
Maintenance Adjust Running Belt Adjust the belt when it is not in the centre (Bear Left Or Right): After a period of time, the user will feel there is a pause Usually between the frames and the running belt there sensation whilst running. -
Page 25: Adjust Motor Belt
Adjust Motor Belt After a period of time, the user will feel there is a pause sensation whilst running. That may be due to a loose drive belt, so adjusting the motor belt would be necessary. First of all, you have to check if it is loose following the steps below: Check If The Motor Belt Is Loose 1. -
Page 28: Warranty Information
Frame & motor comes with a lifetime warranty, all other parts and labour are supplied with a 3 year warranty. Warranty covers manufacturing faults and does not cover damage incurred through misuse of the product. A member of the HEINZ KETTLER group of companies...
